Tai zhou huangyan Jaci mould factory

Taizhou, China

• MOQ 1 Set(s)
• Mould cavity:1cavity

JACI MOULD for pail made of PP or HDPE, withwithout monolithic handle of different colour and material, suitable for IML process (electrostatic and not). -Moldmax material application in mould core&cavity pail mould-Multi-cavity mould design and tooling ability -fast&optimal cooling system design for high speed injection Product name:10Lpainting bucket mould Product description:Seal proof systen design Mould cavity:1cavity Mould size:480*480*680mm Suitable machine:380T haitian machine Mould material:DIN1.2738, core top using Coper Berylium Mould life:2M Runner system:1points YUDU hot runner , point gate Ejection system:stripper plate Mould running:Full automaticity Mould features: The application of Copper Beryllium leads to best cooling effect Stroke switch controls ejection process precisely Oil and water integrator is more convenient for application and operation Copper guide bush, abrasion resistance and prolong the mould life Injection cycle time:22seconds(high speed injection machine) Delivery time:45days The country of mould'client:South Africa

• MOQ 1 Set(s)
• Mould cavity:16cavity

Jaci mould is professional tableware mould manufacture in China, such as spoon mould , knife mould, fork mould. we can make 14-32cavity tableware mould with smoothness verge. Excellent quality with best price Product name: 16caivty plastic Knife Mould Mould cavity:16cavity Mould size:400*400*400mm Suitable machine:200T Haitian machine Mould material:DIN1.2714 Mould base:S136 harden to 52-55Made in China Mould life:3M Runner system:1hot runner +submarine gate Ejection system:stripper plate Mould running: Full automaticity Injection cycle time:6seconds Delivery time:35days The country of mould'client:Egypt

• MOQ 1 Set(s)
• mould cavity:32cavity

We are offering cutlery mould-spoon mould, made in jaci mould. Jaci mould is professional tableware mould manufacture in china, such as spoon mould , knife mould, fork mould. We can make 14-32cavity tableware mould with smoothness verge. Excellent quality with best price product name: 32caivty plastic spoon mould mould cavity:32cavity mould size:400*400*400mm suitable machine:200t haitian machine mould material:din1.2714 mould base:s136 harden to 52-55made in china mould life:3m runner system:1hot runner +submarine gate ejection system:stripper plate mould running: full automaticity injection cycle time:6seconds delivery time:35days the country of mould'client:egypt

• MOQ 1 Set(s)
• Mould Cavity4 cavities

We are offering plastic injection cap mould. Cap mould jaci mould specialized in designing and manufacturing plastic mould for cap mould cap mould -optimal cooling system to get he fast cycle time. -the spare part of each mould will be inserted with durable parts, which can be interchangeable conveniently. -core, cavity using imported steel s136, the hardness is hrc48-50 after heating treatment, each cavity self-locks independently to ensurelow decent ration and precision of the products, and the cavity can be interchangeable with each other. product name:flip top cap mould mould cavity:4 cavities mould size:496*446*480mm suitable machine:200t haitian machine mould material:din1.2083harden to 45-52hrc mould base:lkm2312 mould life:5m runner system:4points yudo hot runner point gate ejection system:stirpper plate mould running:ejection automatic flip top close, fully automatic drop injection cycle time:10seconds delivery time:45days the country of mould'client:portugal

• MOQ 1 Set(s)
• cavity4

We are offering in-mould-label mould. Description: jaci mould is very professional in thin wall food container moulds manufacturing.the container wall thickness can be 0.4mmto 0.55mm for multi-cavities, we can also make thin wall container mould suitable for label, in which the prefabricated plastic label is positioned directly into the mould by a special handling robot. Guarantee the moulds life 1million, using steel s136 with hardness 42-48 after vacuum heating treatment. In-mould-label mould, hardened steel enriched with chromium enabling fast cycling, mould long life and reliability.long-lasting final product high-quality for large production product name :1 liter iml container mould product introducion:%100 leakage proof container prodce with iml (in mould labeling) technology. I-m-l mould application:.food package iml system injection moldmould cavities:4cavity mould steel:sweden s136 pretreat52-55hrc avaliable mould base:lkm din1.2312 standard: copydme, hasco hot runner:4point yudo hot runner valve system life time:>:5m time. Delivery time:60days injection cycle time:6seconds the country of mould'client:south africa
