UNIPRETEC CERAMIC TECHNOLOGY

XIAMEN, China

• MOQ 100 Piece(s)
• MaterialAlumina
• Brand NameUNIPRETEC
• Water Absorption0%
• Moh's Hardness9
• Density3.65 - 3.90 g/cm3
• Model NumberUPT-ALC-a15071504
• Thermal Shock Resistance180 - 220 T(°C)
• Max. Working Temperature1500 - 1800 °C
• Number Of FlowerInsulating Ceramics
• Country of OriginChina

Aluminium oxide, al2o3 is the most widely applied and cost effective technical ceramic material. It offers a combination of superior mechanical strength and electrical properties, wear resistance and corrosion resistance. The maximum working temperature is up to 1700 °c with relatively high thermal conductivity. It is also an electrically insulating material with a high electrical resistivity. The good corrosion resistance makes it insoluble in water and slightly soluble in strong acid and alkaline solution. unipretec manufactures and provides alumina ceramic components for a wide range of application like mechanical equipment, electronic & electrical, oil drilling, medical, chemical industry etc. According to actual application and customer's requirement, the purities vary from 95%-99.7% and the forming methods will be different. The forming methods applied in our plant include dry pressing, isostatic pressing, injection moulding, extrusion moulding. With experienced engineers and talented workers, we are confident to offer high quality, high precision, complex components for customers worldwide.

• MOQ 100 Piece(s)
• MaterialAlumina
• Brand NameUNIPRETEC
• Country of OriginChina
• Density3.65 - 3.90 g/cm3
• Max. Working Temperature1500 - 1800 °C
• Flexural Strength280 - 300 Mpa
• Model NumberUPT15120701
• Corrosion ResistanceHight
• Water Absorption0%
• Moh's Hardness9
• Number Of FlowerInsulating Ceramics
• Compressive Strength2000 - 2500 Mpa

Alumina ceramic ( aluminum oxide or al2o3 ) is an excellent electrical insulator and one of the most widely used advanced ceramic materials. Additionally, it is extremely resistant to wear and corrosion. Alumina components are used in a wide range of applications such as electronics & electrical, pump components and automotive sensors, medical, semiconductor, furnace parts.. unipretec offers a variety of alumina compositions, typical grades that are used for modern industrial applications are of high purity from 90% to 99.7%. alumina components can be formed by a variety of manufacturing techniques such as dry pressing, cold isostatic pressing, injection molding and extrusion. Finishing can be accomplished by precision grinding and lapping, laser machining, metallizing and a variety of other processes.

• MOQ 100 Piece(s)
• MaterialAlumina Ceramic
• Brand NameUNIPRETEC
• Density3.65 - 3.90 g/cm3
• Model NumberUPT-ALC-a15081002
• Number Of FlowerCeramic Tubes
• Country of OriginChina
• Flexural Strength280 - 300 Mpa
• Compressive Strength2000 - 2500 Mpa
• Max. Working Temperature1500 - 1800 °C
• Moh's Hardness9
• Water Absorption0%
• Thermal Shock Resistance180 - 220 T(°C)

• MOQ 10 Piece(s)
• MaterialSilicon Nitride
• Density> 3.20 g/cm3
• Brand NameUNIPRETEC
• Thermal Conductivity25 W/m.K
• Model NumberUPT15092506
• Compressive Strength2200 Mpa
• Flexural Strength650 Mpa
• Number Of FlowerStructure Ceramics
• Vicker's Hardness18 - 20 Gpa
• Country of OriginChina
• Water Absorption0%
• Max. Working Temperature1200 °C

Silicon Nitride has the most versatile combination of mechanical, thermal, and electrical properties of any technical ceramic material. It is a high performance technical ceramic that is extremely hard and has exceptional thermal shock and impact resistance. It surpasses most metals high temperature capabilities and has a superior combination of creep and oxidation resistance and high strength. Additionally, its low thermal conductivity and high wear resistance make it an excellent material that can withstand the toughest of conditions in the most demanding industrial applications. Silicon Nitride is an excellent choice when high-temperature and high-load abilities are needed.

• MOQ 10 Piece(s)
• MaterialSilicon Nitride
• Brand NameUNIPRETEC
• Density> 3.20 g/cm3
• Model NumberUPT15092501
• Water Absorption0%
• Compressive Strength2200 Mpa
• Country of OriginChina
• Vicker's Hardness18 - 20 Gpa
• Thermal Conductivity25 W/m.K
• Max. Working Temperature1200 °C
• Electrical InsulationExcellent

• MOQ 100 Piece(s)
• Brand NameUNIPRETEC
• Max. Working Temperature1200Deg.C
• TypeInsulating Ceramics
• ColorBlack & Grey
• MaterialSilicon Nitride, Si3N4 Silicon Nitride
• Electrical InsulationExcellent
• Country of OriginChina
• Model NumberUPT16090605
• Density3.20g/cm3

Ceramic welding parts made of silicon nitride significantly increase service life and enable high levels of precision and greater accuracy over extended periods in projection welding. Metal welding pins often need to be replaced several times a day due to wear and adhering slag, whereas centering pins made of silicon nitride ceramics only need to be replaced about once a month. And generally these welding parts made of silicon nitride ceramic only require replacement when damaged by mechanical force. This not only provides more economical production thanks to a reduction in costs, but also makes the entire process more robust, which in turn results in consistently high product quality.

• MOQ 100 Piece(s)
• MaterialSilicon Nitride, Si3N4 Ceramic
• Density3.20g/cm3
• Electrical InsulationExcellent
• Max. Working Temperature1200Deg.C
• ColorBlack & Grey

Ceramic welding parts made of silicon nitride significantly increase service life and enable high levels of precision and greater accuracy over extended periods in projection welding. Metal welding pins often need to be replaced several times a day due to wear and adhering slag, whereas centering pins made of silicon nitride ceramics only need to be replaced about once a month. And generally these welding parts made of silicon nitride ceramic only require replacement when damaged by mechanical force. This not only provides more economical production thanks to a reduction in costs, but also makes the entire process more robust, which in turn results in consistently high product quality.

• MOQ 10 Piece(s)
• MaterialSilicon Nitride
• Water Absorption0%
• Number Of FlowerStructure Ceramics
• Max. Working Temperature1200 °C
• Country of OriginChina
• Vicker's Hardness18 - 20 Gpa
• Thermal Conductivity25 W/m.K
• Electrical InsulationExcellent
• Flexural Strength650 Mpa
• Model NumberUPT15092509
• Compressive Strength2200 Mpa
• Brand NameUNIPRETEC
• Density> 3.20 g/cm3

• MOQ 100 Piece(s)
• MaterialAlumina
• Brand NameUNIPRETEC
• Moh's Hardness9
• Country of OriginChina
• Corrosion ResistanceHigh
• Compressive Strength2000 - 2500 Mpa
• Max. Working Temperature1500 - 1800 °C
• Water Absorption0%
• Number Of FlowerInsulating Ceramics
• Density3.65 - 3.90 g/cm3
• Model NumberUPT-ALC-a15092801
• Flexural Strength280 - 300 Mpa

Material introduction: Aluminium Oxide, Al2O3 is the most widely applied and cost effective technical ceramic material. It offers a combination of superior mechanical strength and electrical properties, wear resistance and corrosion resistance. The maximum working temperature is up to 1700 °C with relatively high thermal conductivity. It is also an electrically insulating material with a high electrical resistivity. The good corrosion resistance makes it insoluble in water and slightly soluble in strong acid and alkaline solution. Available shapes: Our Alumina Ceramic products can be made into different shapes like ceramic rods, ceramic bars, ceramic tubestubings, ceramic bushingsceramic bushing, ceramic sleeves, ceramic seal rings, ceramic washers, ceramic ball valves, ceramic pistons, ceramic disks, ceramic spacers, ceramic platessheetssubstrates or other customized shapes. According to actual application and customer's requirement, the purities vary from 95%-99.7% and the forming methods will be different. The forming methods applied in our plant include dry pressing, isostatic pressing, injection moulding, extrusion moulding. With experienced engineers and talented workers, we are confident to offer high quality, high precision, complex components for customers worldwide.

• MOQ 100 Piece(s)
• MaterialZirconium Oxide
• Density6.0g/cm3
• Brand NameUNIPRETEC
• UsageEmpty Hard Gelatin Capsules Cutting
• Country of OriginChina
• Number Of FlowerEmpty Capsule Cutting Parts
• Model NumberCustomized
• Max. Working Temperature600 Deg. C
