Wenzhou Zhuding Machine Co.,Ltd.

• MOQ 1 Set(s)
• Brand NameZHUDING
• Dimension(L*W*H)1200*1100*2100mm
• Weight550KG

• MOQ 1 Set(s)
• Brand NameZHUDING
• Availability9000KG
• Dimension(L*W*H)10800*2050*2720MM

• MOQ 1 Piece
• Brand NameZHUDING
• Voltage380/220V
• Power(W)280kw

We manufacutres series of spunbonded , melt-blown complete sets of non woven machines, combining installation, commissioning and after-sales service. Base on continous innovation and improvement, we can make full use of new technologies and materials to ensure product's stablity and reliablity, and continunously meet our customers' requirements. Undertaking projects: non-woven machinery manufacture, pp spunbond nonwoven fabric We offer a packing deal of spunbond production line, which includes the desighingproducing.installing and testing.(Turnkey projects) We offer a packing deal of SMS in production line, which include the designingproducinginstalling and testing.(Turnkey projects) Major characteristics: The whole line is well-structured and easy to operate The whole line highly automated Control elements are of well-known make, high performance and reliable technologies. The whole line are controlled by PLC and operated with touch -scree. The allocation of the main frame and auxiliary equipment can be special designed and configurated according to customer's requirements . PP Spunbond Production Line Technical Parameter: The TY of Die Effective width GSM Annual capacity Embossing pattern 1 1600mm 10-250GSM 1500T Diamond, oval, cross , and line 1 2400mm 10-250GSM 2400T Diamond, oval, cross , and line 1 3200mm 10-250GSM 3000T Diamond, oval, cross , and line SS 1600mm 10-250GSM 2400T Diamond, oval, cross , and line SS 2400mm 10-250GSM 4000T Diamond, oval, cross , and line SS 3200mm 10-250GSM 5000T Diamond, oval, cross , and line

• MOQ 1 piece
• Brand NameZHUDING
• Availability6000KG
• Dimension(L*W*H)10*8*3M

We are offering pp non woven fabric laminating machine. non woven fabric laminating machine: sj-fmf1000-2400 this non woven fabric laminating machine making use of the good adhesive property of polypropylene performance and characteristics this nonwoven fabric laminating machine making use of the good adhesive property of polypropylene &polyethylene at melting status, the machine adheres and laminated paper or color-printed opp &cpp film to nonwoven fabric, non woven bag under pressure, and through cut-off and the extruder with helical gear reducer of 20crmoaia alloy steel and done treatment of nitrogenation. the double-die can do single or double-face coating, width of coating& laminating can be regulated, and stepless speed regalation in to control coating thickness and laminating speed, 6 wind-up station for material feeding. The gas-liquid edge correcting for rewinder assures the accuracy of coating. Pneumatic roller can assure even pressure. Automatic edgecutting, edge-blowing, cutting-off and winding devices are applied. main technical parameters typeitem diameter of extruder screw ld ratio of screw number of die width of die gross power(kw) power of extruder motor(kw) heating power of extruder(kw) power of driving motor(kw) sj-fmf901000b 90 26:1 2 1000 58 15 32 5.5 sj-fmf1101200b 90 26:1 1 1450 60 18.5 33 5.5 sj-fmf1101900b 110 26:1 1 1900 65 18.5 35 5.5

• MOQ 1 Set(s)
• Brand NameZHUDING
• Availability800KG
• Dimension(L*W*H)2.6*2.35*1.4M

We are offering full automatic non woven fabric slitting machine. nonwoven fabric slitting and rewinding machine characteristic this nonwoven fabric slitting and rewinding machine is special for separate and cut the nonwoven fabric from big roll to small roll. The width can make according customer request. technical parameters slitting and rewinding speed 120mmin max. Unwinding diameter 1000mm max rewinding diameter 1000mm max width of roller 1000-2400mm(customaerized) gross power 2.2kw frenquency control weight 600kg

• MOQ 1 Set(s)
• Brand NameZHUDING
• Availability2800KG
• Dimension(L*W*H)4600*2300*4200MM

We are offering two colors two layers co extrusion hdpe and ldpe film blowing machine. characteristics: the cylinder and the screw are made of high quality alloy steel with optimum hardness and strong corrosion resistance after precise processing and nitrogen treatment , the auxiliary machine has a platform which makes operation easy , the rewinding unit adopts torque motor to keep proper tension and make rewinding even and roll changing easy. it is used to blow the various pe thermal shrink film , which is applied extensively to food , medicine, bottel , .material bottle, box, case.cloth reel.floor.glass , tray, pottery and tissue, etc. main technical parameter: typeitem sj-45*2fm600 sj-55*2fm800 sj-60*2fm1000 sj-65*2fm1200 sj-80*2fm1500 diamerter of screw 50mm 55mm 60mm 65mm 80mm ld ratio of screw 28:1 28:1 28:1 28:1 28:1 rotational speed of screw 10-100rmin 10-100rmin 10-100rmin 10-100rmin 10-100rmin power of main motor 11kw 15kw 18.5kw 22kw 33kw maximun output 35kgh 50kgh 50 kgh 80 kgh 120 kgh max.folding width of film 600mm 800mm 1000mm 1200mm 1500mm single-side thickness of film 0.01-0.10mm 0.01-0.10mm 0.01-0.10mm 0.01-0.10mm 0.01-0.10mm gross power 22kw 26kw 30kw 36kw 46kw weight of machine 2000kg 2800kg 2800kg 3300kg 4300kg installing dimensions(l*w*h) 4000*1800*3600mm 4200*2000*4000mm 4600*2300*4200mm 4800*2500*4500mm 5200*2800*5000mm.

• MOQ 1 Set(s)
• Brand NameZHUDING
• Weight2600kg
• Dimension(L*W*H)6.3*1.5*1.8M

We are offering full automatic nonwoven bag making machine. performance and characteristics this machine is suitable for non woven fabric matreial, it is desighned to produce non woven box type bag, vest bag, d-cut type bag, rope through type bag, indifferent specifications and shapes. it combine the mechanical and electrical together as a whole, use ultrasonic sealing type and operation by touch screen, machine install punching device automatic counting, setting counting alarm available either, it is an ideal equipment for making non woven bag. configuration machine use industrial control level plc mitsubishi japanese touch screen use mitsubishi japanese transmission are drived and controlled by yaskawa japanese main motor siemens unwinder equipped with magnetic tension unwinder equipped with two photocell for tracking, sensor use german sick brand edge guider for unwinding unit air cylinder loader material omron brand temperature control schneider brand switch air component use taiwan airtack bearing use japanese nsk brand main technical parameter bag making type box type(three side gusetting) vest type d-cut type, shoes bag rope though type flat bag, loop handle bag type tension control 2.5kg magnetic brake raw material nonwoven farbic capacity 40-110p0csmin bag making width 100-500mm bag making length 120-560mm weight of the cloth 20-130gsm diameter of material 900*1200mm servo motor 1.5kw main motor 0.75kw electric heat 0.6kw motor for epc 0.1kw ultrasonic 2.6kw feeding motor 0.4kw gross power 15kw frequency and voltage 50hz 220v dimension 6.3*1.5*1.8m

• MOQ 1 Set(s)
• Brand NameZHUDING
• Weight2500kg
• Dimension(L*W*H)6.0*9.0*1.8M

We are offering nonwoven fabric bag making machine. performance and characteristic this machine is for nonwoven fabric bag making, with automatic bottom sewing and side sewing two japanese newlong sewing head, plc control, touch-screen operation, servo motor for making exactly size, withg auto tension and edge guider device. Pneumatic take-up raw materical roller. It is our factory latest machine product.very popular in maket for making non-woven fabric heavy duty bag(80-150gsm non-woven fabric). If we set 2 program in plc and use special cut blade, this machine can make woven sack at same time. main technical parameter model nwscd650 max. Dia of cloth roller 1200mm fabric max. Width 1300mm folding width 650mm cutting length 1200mm max cutting width 680mm gross power 8kw production capacity 25-30pcsmin cutting precision ±4mm weight 2500kg dimension of machine 6*9*1.8

• MOQ 1 Set(s)
• Brand NameZHUDING
• Dimension(L*W*H)4800*2000*2800mm

We are offering wenzhou flexo printing machine roll paper. 1. Easy operation, accurate color register, high quality can be sure long time use 2. Adopts taiwan motor, japanese inverter, save power, smooth running. 3. Automatic stop ink pump motor when down printing roller, automatic run ink pump motor when lift printing roller. 4. Adopts closed doctor blade 5. Bevel wheel transmission makes accurate printing size 6. Use blower and heating double drying device, constant temperature control device set inside the heating device, control every unit , cool blower fixed shape. 7. Germany special iron material make the roller, after special treatment, electroplate 100mic thickness hard-chrome protection layer 8. Aluminum guid roller get treatment of rigid oxidation, moving balance, motionless balance. 9. Taiwan air shaft load material( optional) 10. Tension control for rewinding and unwinding unit ( optional)

• MOQ 1 Set(s)
• CertificationCE/ISO/SGS
• Brand NameZHUDING

We are offering flexo printing plate mounting machine. characteristics 1. Employed up-and-down adjustable precise screw unit, japanese sinco high grade amplified lens, ccd camera, hf liquid crystal monitor for displayer. 2. Adopted upper and down adjustable japanese sinco high-grade amplifier, ccd camera and hd liquid crystal monitor for its displayer. 3. The cameta can be adjusted in all directions. Higher precision of printing plating adhesion and accurate registering. 4. The printing plate can be stuck in telescope. 5. Faster sticking the printing plate, ease of operation, higher production capacity. 6. Applied to printing the relief printing materials like oft rotary and resin printing main technical variable model wq-16 wq-25 wq-43 wq-50 wq-65 plate material felxo plate felxo plate felxo plate felxo plate felxo plate plate thickness 1-5mm 1-5mm 1-5mm 1-5mm 1-5mm plate cylinder width max 260-450mm 450-700mm 810-1050mm 850-1350mm 1050-1650mm plate cylinder repeat 178-660mm 190-660mm 203-760mm 203-760mm 760-1280mm air supply 0.4mp 0.4mp 0.4mp 0.4mp 0.4mp.
