Sanxing, the highly acclaimed manufacturer, exporter and supplier of roll forming machines, molds a machine that ratifies special technology (similar to Lippo Germany) for spiral Steel silo Making Machine, and helix steel silo. This machine has the potential to replace the traditional welding machine. It can join steel with very tight seems to increase resistance.
Benefits :
- Ensures excellent resistance
- Durable output
- Speedy construction
- Reliable performance
- High quality
Parameter :
- Size : Forming machine:1500mm × 1200mm × 150
- Curving machine : 1500mm× 1200mm ×1000mm
- Total Weight : about 3000kg
- Press wheels : carbon steel, high-frequency quenching HRC48 - 52
- Gears : carbon steel , high-frequency quenching HRC48 - 52.
- Sprocket wheel : carbon steel , high-frequency quenching HRC48 - 52.
- Thickness of the coil : max 3 mm
- Suitable diameter : ≥4m
- Electric Standard : 380V / 50 HZ / 3 Phase
- Raw material and thickness :
- Galvanized steel : 2-4mm
- Chromium-nickel steel : 2-3mm, anti-corrosive
- Plastic-coated steel : 2-4mm
- Carbon steel : 2-4mm
- Width of raw material : 500mm
- Dia meter range of finished silo : 2.5-50m
- Height of finished silo : usually less than 30m
- Feed speed : 3.5-4.5m/min
Features :
- This machine adopts special technology for spiral steel silo, helix steel silo by very strong seaming, not welded or assembled. The technology is same to Lippo Germany. Such steel silo can replace concrete silo in most projects, with much shorter production period and less project cost.
- The steel storage producing line and silo making machine join several steel sheets together that will replace the traditional welding method. It's convenient to be repaired and it saves time and costs for installation and production. The silo will have good sealing with five-layer spiral crimped. The steel storage production line and silo making machine put together steel with very tight seams and this way the silo will have excellent resistance to even contain chemicals or fumigating products.
- This machine can form 1.5-4mm thick, 500mm wide galvanized steel, stainless steel or special steel materials into spiral /helix steel silos in diameter 4-50m, for storing corn, paddy, grain, cement, water, chemical materials, etc.
- The steel storage producing line is capable of make silos in short construction period, around eight days to build a 2000 ton steel. The results are high quality products, matching several sheets together warranty silos with service life up to 30 years.
Use :
- The steel silo ( pool wall) are widely used as :
- Material shape (storage): granular material, powder material, liquid material.
- Industry: grain, feedstuff, Brewing, oil, medicine, food, cement, water treatment, etc.
- Varieties in detail (storage): wheat, soybean, maize, sorghum wheat flour, bulk cement, fly ash, sewage, water, chemical syrup, etc.
- Ordinary black steel sheets, galvanized steel sheets, nickeling steel sheets, high strength steel sheets, stainless steel sheets, aluminum alloy sheets, sandwich panels, plastic coated metal sheets. Among them, the steel sheets, galvanizd steel sheets, aluminum plate sheets, aluminum alloy sheets, chromium plate sheets, nickeling steel sheets, sandwich panels can be curved in double layers.
In a word, these metal containers are widely used in our country. it can replace the traditional welding metal containers. So the excellent construction speed , reliable performance and quality assurances of Rx4.0m/m steel belt forming andseaming machine become the preferred choice of the investment professionals
