Yongjia Goole Valve Co., Ltd

Wen zhou, China

• MOQ 1 Set(s)

The cage adopts the press-in type seat design, which solves the problems of difficult disassembly and high leakage of the traditional thread screw-in type seat and prolongs the service life. The flow to open design is adopted, and the medium flow direction tends to the opening direction of the valve with good controllability of small opening and low flow characteristic distortion. Special cages with noise reduction and anti-cavitation functions can be offered according to the requirements in different service conditions. Parameters of control valves： Trim features： top guided unbalanced trim structure quick disassembly type structure Body type： straight-through type angle type Bonnet type： bellows type Flow characteristic： equal percentage linear quick open Size： DN15-300(12”-8”) Pressure class： PN1.6、4.0、6.3Mpa（ANSI 150、300、600LB） Leakage class： ASME B16.104 Ⅴ（standard type metal seat） ASME B16.104 Ⅵ（shut-off soft seat） Pipe connection type： flange type butt welding type Applicable temperature range： -196C°～ 550C° Actuator type： pneumatic diaphragm actuator pneumatic piston actuator electric actuator

• MOQ 1 Set(s)

The cage adopts the press-in type seat design, which solves the problems of difficult disassembly and high leakage of the traditional thread screw-in type seat and prolongs the service life. The flow to open design is adopted, and the medium flow direction tends to the opening direction of the valve with good controllability of small opening and low flow characteristic distortion. Special cages with noise reduction and anti-cavitation functions can be offered according to the requirements in different service conditions. Parameters of control valves： Trim features： top guided unbalanced trim structure quick disassembly type structure Body type： straight-through type angle type Bonnet type： standard type heat dissipation type cryogenic type bellows type Flow characteristic： equal percentage linear quick open Size： DN15-200(12”-8”) (small flow control valve DN1-DN10) Pressure class： PN1.6、4.0、6.3Mpa（ANSI 150、300、600LB） Leakage class： ASME B16.104 Ⅴ（standard type metal seat） ASME B16.104 Ⅵ（shut-off soft seat） Pipe connection type： flange type butt welding type Applicable temperature range： -196C°～ 550C° Actuator type： pneumatic diaphragm actuator pneumatic piston actuator electric actuator

• MOQ 1 Set(s)

The 10P50F Series single-seat fluorine lined control valve adopts full fluorine lined body and trim structure to effectively prevent the corrosion of metal materials in the valve by corrosive media. The metal body cavity is subjected to serrated machining treatment so as to make the lining materials fully fit into the metal and prolong the service life and performance of lining materials. The stem seal is the compound seal of F46 bellows seal and V PTFE packing, which can eliminate the possibility of media leaking from the stem to the outside. The unbalanced full lined control valve is especially suitable for very corrosive media under low pressure and normal temperature service conditions. Parameters of control valves： Trim features： unbalanced plug lined seat Body type： straight-through type Bonnet type： bellows type Flow characteristic： equal percentage linear quick open Size： DN15-300(12”-12”) Pressure class： PN1.6、4.0Mpa（ANSI 150、300LB） Leakage class： ASME B16.104 Ⅴ（standard type seat） Pipe connection type： flange type Applicable temperature range： -45C°～ 200C° Actuator type： pneumatic diaphragm actuator pneumatic piston actuator electric actuator

• MOQ 1 Set(s)

The cage adopts the press-in type seat design, which solves the problems of difficult disassembly and high leakage of the traditional thread screw-in type seat and prolongs the service life. The flow to open design is adopted, and the medium flow direction tends to the opening direction of the valve with good controllability of small opening and low flow characteristic distortion. Special cages with noise reduction and anti-cavitation functions can be offered according to the requirements in different service conditions. Compared with the 10P00 Series, the 10P60 Series valves are of heat insulation jacket type, mainly used in applications where media such as paraffin may easily coagulate at normal temperature. Fill the heat insulation jacket with steam to heat the medium and maintain its flow. Parameters of control valves： Trim features： top guided unbalanced trim structure quick disassembly type structure Body type： straight-through type Bonnet type： heat insulation jacket type Flow characteristic： equal percentage linear quick open Size： DN15-200(12”-8”) Pressure class： PN1.6、4.0Mpa（ANSI 150、300LB） Leakage class： ASME B16.104 Ⅴ（standard type seat） Pipe connection type： flange type Applicable temperature range： -45C°～ 550C° Actuator type： pneumatic diaphragm actuator pneumatic piston actuator electric actuator
