Our Products
We are leaders in the market for providing best range of IOP Grade Bentonite Lumps, Calcium Bentonite Lumps, China Clay Lumps, Animal & Poultry Feed Bentonite Powder and Sodium Bentonite Powder
Specifications
| Properties | Unit | Insta Bond |
|---|---|---|
| Free Swelling Volume 2 gm/100ml | Ml | 15-18 |
| Montmorillonite | mg/gm of clay % | 80-90% |
| Methylene Blue Absorption Value | mg/gm of clay | 350 |
| Moisture Content % by weight | % | 10 – 12 % MAX |
| Passing 200 mesh If Powder | % | 85 min |
| Loose Bulk Density | gm/ml | 0.85 - 1.0 |
Specifications
| PROPERTIES | PROTOCOL | UNIT | REQUIRED | RESULT |
|---|---|---|---|---|
| Viscometer Dial Reading at 600 rpm | API Spec. 13A:2004/ ISO 13500: 1998 | r/min | 30 | 34 |
| Yield Point / Plastic Viscosity Ratio | API Spec. 13A:2004/ ISO 13500: 1998 | - | 3 Max | 2.85 |
| Filterate Volume | API Spec. 13A:2004/ ISO 13500: 1998 | ML | 15 Max | 14.4 |
| Moisture Content | API Spec. 13A:2004/ ISO 13500: 1998 | % by weight | 10.0 max. | 10 |
| Dry Screen Analysis(Residue Greater than 75 Microns)% | API Spec. 13A:2004/ ISO 13500: 1998 | % by weight | 4.0 max. | 3.0 - 4.0 |
Specifications
| PROPERTIES | PROTOCOL | Pilling Normal Bond | Pilling Insta Bond | Pilling Super Bond | Pilling High Bond |
|---|---|---|---|---|---|
| Liquid Limit | ml | 400-450 | 450-500 | 550-600 | 600-650 |
| Methylene Blue Absorption Value | mg/gm of clay | 325-350 | 375-400 | 375-450 | 400-450 |
| Gel Time 2.5gm/25 ml | second | 1 min | Instant. | Instant. | Instant. |
| Gelling Index | ml | 80-90 | 80-90 | 85-90 | 85-90 |
| Moisture Content % by weight | % | 12%MAX | 12%MAX | 12%MAX | 12%MAX |
| PH Value 2% slurry | pH | 9.0 - 10.0 | 9.0 - 10.0 | 9.5 - 10.0 | 9.5 - 10.0 |
| Loose Bulk Density | Gm/Ml | 0.85-1.0 | 0.85-1.0 | 0.85-1.0 | 0.85-1.0 |
| Passing 200 mesh | % | 83-85 min | 83-85 min | 83-85 min | 83-85 min |
Specifications
| PROPERTIES | PROTOCOL | Normal Bond | Insta Bond | Super Bond | High Bond |
|---|---|---|---|---|---|
| Free Swelling Volume 2 gm/100ml | ml | 20-22 | 24-25 | 28-30 | 32-35 |
| Methylene Blue Absorption Value | mg/gm of clay | 325-350 | 375-400 | 375-450 | 400-450 |
| Gel Time 2.5gm/25 ml | second | 1 min | Instant. | Instant. | Instant. |
| Gelling Index | ml | 80-90 | 80-90 | 85-90 | 85-90 |
| Moisture Content % by weight | % | 12%MAX | 12%MAX | 12%MAX | 12%MAX |
| PH Value 2% slurry | pH | 9.0 - 10.0 | 9.0 - 10.0 | 9.5 - 10.0 | 9.5 - 10.0 |
| Green Compression Strength Bentonite : Water :10:4 55-60 A.F.S Sand | psi | 12 | 12 | 12.5 | 12.5 |
| Passing 200 mesh | % | 75-80 min | 75-80 min | 75-80 min | 75-80 min |
Specifications
| Properties | Unit | IOP Insta Bond | IOP Super Bond | IOP High Bond |
|---|---|---|---|---|
| Free Swelling Volume 2 gm/100ml | Ml | 28-30 | 30-32 | 32-35 |
| Methylene Blue Absorption Value | mg/gm of clay | 350-375 | 375-400 | 400-450 |
| P.W.A. | 550-650 | 600-700 | 650-750 | |
| Moisture Content % by weight | % | 12%MAX | 12%MAX | 12%MAX |
| Passing 200 mesh If Powder | % | 85 min | 85 min | 85 min |
