EDiscovery Automation Private Limited Bangalore, Karnataka

Polymorphism has become a serious concern in today's pharmaceutical research as it affects a number of issues in pharmaceutical systems varying from processing characteristics & shelf life, to bioavailability. To reduce "surprises" and secure potential product patents, polymorph screening is considered at a very early stage in the drug discovery process. At this stage, since a large number of candidates with very small sample volumes have to be tested, only an automated system could cope with the requirements. Zinsser Analytic developed CRISSY®, an automatic workbench for salt pre-screening and polymorph screening studies.   Experimental planning Precise gravimetrically controlled distribution of API Liquid handling of solvent arrays Controlled heating and cooling cycles pH measurement and adjustment Special blocks for direct analysis without any additional sampling steps Customised import and export functions

TraySy "X" a newly developed X-Y distributor and the proven peristaltic dispenser Perifill® IQ 3000 form a unique automatic filling system for small and medium size batches. TraySy "X" is a fast, computer controlled precision X, Y-system with a stainless steel workbench. Vials, ampoules, tubes in racks or packing trays can be placed on the workbench and automatically filled. It takes less than 2 seconds to fill a 4ml vial. The systems are used for sterile and non-sterile serial dispensing in drug dispensories, bacteriology labs, pharmaceutical and diagnostic batch production. Two speed recycling to reservoir when not dispensing Stirring for slurries and suspensions Accurate temperature control for hot or cold liquids Fast or slow dispensing Full control for viscous materials Programmable slow start and slow finish - no splashing Stores 9 user defined programmes Volume range 0.1 ml to 1000 ml Dispense and calibration setting retained in memory when switched off Easy calibration Easy to clean

QUAATRO is a high performance, fully automated instrument that uses the principles of segmented flow analysis to achieve complete reaction, high reproducibility and ultra-low detection limits. QUAATRO uses microflow hydraulics, enabling high sample rates with low sample and reagent consumption. QUAATRO is ideal for water and seawater analysis when high throughput and ultra-low detection limits are required. QUAATRO is a microflow SFA system, the internal diameter of all glassware being 1mm. This reduces reagent consumption and increases throughput, with most methods running at 100 - 120 samples hour. QUAATRO has many unique features to increase ease of use and reduce ownership costs. The integrated enclosed manifold and detector are heated to 37° C. Flow stability is ensured as the optimal bubble frequency for each method is programmed by silent air valves. Automatic start-up, method changeover and shutdown allows true unattended operation and overnight running. QUAATRO checks its own performance, with automatic monitoring of noise, drift, bubble pattern and light energy, before and during a run. QUAATRO high resolution digital photometer, with optimized optics and 24-bit resolution, provides higher sensitivity at ultra-low concentrations, wider dynamic ranges and lower detection limits. LED light sources are available for high performance applications, such as use on research vessels. Various flowcells are available, all with bubble-through technology. The enclosed heated chemistry manifold on QUAATRO means there is no need for heating baths. Microflow hydraulics allows faster analysis rates, lower reagent consumption and results in less waste. The inert glass components allow easy visual check for correct operation and easy cleaning. Four chemistries can be run simultaneously on one console. 5 channel seawater QUAATRO is available. The heart of the system, the high precision three-speed peristaltic pump, ensures regular, reproducible dosing of liquid. Optional reagent valves allow automatic start up, method switching and shut down. QUAATRO autosamplers are fast, robust and available with various rack sizes to meet your sample requirements. Samples can be added at any time during the run. Instrument control and data acquisition is carried out through the intuitive, easy to use AACE software package. AACE is LIMS compatible and both standard and GLP versions are available. QUAATRO is used to analyze nutrients in a wide variety of sample types: Drinking Water Water and Wastewater Seawater Soil and plants

The  AA3 HR's high resolution digital photometer , with optimized optics and 24-bit resolution, provides high sensitivity at ultra-low concentrations, wider dynamic ranges and lower detection limits. Air bubbles pass through the flow cell without affecting the signal, increasing sampling rate. LED light sources are available for high performance applications, such as use on research vessels. Other detectors, such as flame photometer and UV spectrophotometer are available for special applications. The  chemistry manifold  is comprised of close-tolerance glass components, which are chemically inert and allow for easy visual check of operation. Multi-test manifolds are available, where different analyses can be run - with no hardware or pump tube changes. Complex procedures, such as distillation, dialysis and UV digestion, can also be incorporated. High precision multi-speed peristaltic pumps  ensure regular, reproducible dosing of liquid. High speed is available for fast start-up and wash-out and low speed is available to conserve reagents following a run. Electronically controlled air valves provide precise air bubble injection. The  AA3 HR's random access autosamplers  are fast, robust and have various rack sizes to meet your sample requirements. Samples can be added at any time during the run. Instrument control and data acquisition is carried out through the intuitive, easy to use AACE software package.  AACE  is LIMS compatible and both standard and GLP versions are available. SEAL has more than 1, 000 documented methods and new applications are regularly being developed in our laboratories. USEPA, ASTM, ISO, AOAC, DIN, CORESTA  and other international regulatory compliant methods are available. Wide dynamic range Ultra-low detection limits Modular design - high flexibility Multi-test manifolds allow for easy method change-over - with no change of hardware Run up to eight channels simultaneously Easily upgradable Reliable unattended operation Low reagent consumption Typical Applications include: Seawater Water and Wastewater Drinking Water Fertilizer Soil and Plants Animal Feed

The rinse pump, liquid level sensor control and BOD probe stirrer control are built into one compact module.A MANTECH interface is used with the system. The interface connects to the PC. The dissolved oxygen meter connects to the interface. The autosampler connects direct to the PC.The seed and inhibitor pumps run at 12mlmin as they are set to deliver 3-10ml of reagent. If a customer requires less seed, we recommend that the reagent be diluted to deliver larger volumes.The dilution water pump runs at 620mlmin and is controlled as a volume addition pump andor controlled by liquid level sensor meeting the requirements of all methods.

Syringes for Dosage of Gas and Liquids Syringes for Headspace Analysis Syringes for On-Column Injection Syringes for HPLC & GC Autosamplers HPLC-Syringes Syringes for TLC & HPTLC Syringes for Robbins Hydra Syringes for Automatic Liquid Handling Syringes with PEEK-Tubing Connectors Syringes with Adjustable Internal Stopper Custom Made Products Accessories for Connectors
