technical data : eminent bs-900w

vertical type continous band sealing machine (wide conveyor)

model:eminent-bs-900w

machine type - vertical type continuous band sealer(m.s body)

• packing weight - 5kg carrying load and 15kg conveyor load
• voltage(v/hz) - 240/50
• power (w) - 750
• heat sealing power(w) - 220x2
• sealing speed (m/min) -0-12
• sealing width -8-12mm
• temp range(deg.c) -0-300
• distance from sealing centre to conveying table(mm) :-150-270
• conveyor size(l x w) -840 x 300
• film thickness(mm) -0.08
• single conveyor loading(kg) -5kg
• over all conveyor loading -15kg
• dimension of machine(l*w*h) - 850x380x290
• weight - 32kg

Tray Sealer Machine

cartonsealer(mini)
voltage(v/hz) 220/50
maximum carton size(lxwxh)mm400x400
minimum carton size (lxwxh)mm 100x100
speeddm/min) 20
available adhesive tape pvc adhesive tape
height of table(mm) 580x780
width of adhesive tape(mm)36, 48
size (lxwxh)mm 1730x950x(960-1550)
weight(kg) 115
air compressor na
power 200

Shrink Tunnel Packaging Machine

Sticker Labeling Machine

strapping machineis the machine suitable for strapping cartons of various heights very quickly without the need for bothersome strapping tools & metal

Inductioncapsealing machineis a non contact process machine where in the seal is applied to the opening of the container

round bottle motorized labelling machine with facility with hot ribbon batch coding together

various brands available

Single Chamber economical Vacuum Machine,
Tea Vacuum machine
Model:250
voltage:220/50hz
Power:120
Electric Current:5
External Size:380 x 320 x 360 mm
Weight:25kg

Semi Automatic Capping Machine

_{This Is Mechanical type FFS Machine and it is customized for Garlic Paste, pickles and souces.
The filling system in this machine is spool valve type which is desiegned for Paste but it can also be customized for any kind of liquid product as well as paste type product
depending upon product charracteristics.}

Special Category Machine

Handy Coder, Handy Marker, Ink Stamping,

strapping machineis the machine suitable for strapping cartons of various heights very quickly without the need for bothersome strapping tools & metal

Motorized Round bottle Labelling machine, operated manually, This Machine is synchronised with Sensor, Pusher and auto label Pasting on bottles.

m/s eminent engineering services manufacture fully automatic flow wrap machine, which is a very versatile machine which can wrap cylindrical, cubical and irregular shaped solid products like rusk/biscuits/soap / bottle / bearing / cake / disposable syringe / pencil cells / ice cream / piston rings / spark plug / pre-filled pouches and similar product in pillow pack pouch.
the machine is equipped and controlled by plc (programmable logic control) and hmi (human machine interface) keywords, which makes this machine operator friendly if required.
the machine can be provided with customized in-feed system in synchronization with the manufacturing process of the customer.
this machine is suitable for a wide range of heat sealable film as a packing material such as pet+poly, pet+met+poly; laminates with aluminum foil and heat sealable bopp etc.
the wrapper packages product by wrapping it in film. the wrapper has an infeed conveyor, a film feed assembly, a forming area, a cutting head, and a discharge area.product is placed on the infeed conveyor. as the infeed conveyor delivers product to the forming area, film is drawn from the film.
m/s eminent believes in providing the best quality products available in the market to meet the globalneed.
the machine can be provided with various optional attachments (at an extra cost) like nitrogen
flushing and batch-cutting device, batch coding device etc.
since continuous development is a process at m/s eminent and tailor made solutions are provided to
the customers, some of the features shown are subjected to change without prior notice.

Solid Ink Dry Batch Coding machine is basically used for high production to print Batches mrp etc on Preformed heat sealable printed and laminated pouches as well as papers and laminated labels before to pack .

This Machine is Half Pneumatic type with cup Filling System, basically this is for large pouches upto 450mm roll width for low budget customer.

It is desiegned for namkken, bhujia, snacks or any type of granules and free flow products.

This Machine is called L-Seader and its application is to make Pouches(3Side Seal) of product before to shrink application. This machine is with Shrink chamber.

It has two clasification one manual type and auto type for roll unwinder.

This is ink type batch coding machine for high quality printing, basically its installed on all kind of FFS MACHINES, All details with manual is attached in profile where you can see the complete details .

This is printed and laminated rolles and customized as per customer requirement .
It May be in Two Layer, 3layer and Four layers customization as per product charracteristics.

descriptions:

fully automatic collar type form fill and seal machine which is customized as an intermittent motion machine and designed for the efficient packing of the varieties of products like rice, seeds, tea, namkeen, bhujia, sugar, spices, snacks foods, wafers, detergent, henna powder, salt, wrapper candies, cheese biscuits etc. in center seal pouches.

the machine is equipped and controlled by plc panel (programmable logic control) and hmi (human machine interface) keywords, which makes this machine operator friendly.

the web path of roll systemized as which keeps on feeding the laminate to the pouch forming tube without much pulling tension to enable the machine to form wrinkle free pouch formation.

this machine is suitable for a wide range of heat sealable film as a packing material such as pet+poly, pet+met+poly; laminates with aluminum foil and heat sealable bopp etc.

it is a versatile machine and the pouch width can be changed very easily by replacing theforming tube and collar.changing of the pouch length does not require any change parts.m/s eminent believes in providing the best quality products available in the market to meet the globalneed.the machine can be provided with various optional attachments (at an extra cost) like nitrogen

flushing and batch-cutting device, batch coding device etc.since continuous development is a process at m/s eminent and tailor made solutions are provided to the customers, some of the features shown are subjected to change without prior notice.

specifications:

product to be packed - snacks

machine ffs collar type pneumatic

control plc panel (programmable logic control)

temperature controller pid/digital type

gusset mechanism can customize

unwinding system -simplex/motorized/cantilever type air operated

sealing system heat sealers

roll width-450 mm (max.) 140 mm (min.)

pouch size -65mm (width) x 65mm (repeat) [min.]::220mm (width) x 300 mm (repeat) [max.].

model : eminent-ffs-sm

machine type :- schute based pneumatic f. F. S machine

filling system :-cup filler

packing weght :- 10-100gms

product to be pack:- snacks/tea

covering :- full stainless steel

speed :- upto 50 ppm

special :-digital temperature controller with pouch counter meter.and all pneumatic system is janatic /festo etc make.motor :- 1/2 h. P single phase-01 no:: 1-1/2h. P 3phase-01 no:1h. P 3phase-01noclutch brake-15 torque-01no: all motors are crompton makeweight :-400 kgs (approx)

filling accuracy :- +/- 2% depending upon product and its density

specifications:pouch width-(min=20mm/max=130mm)pouch length-(min = 50mm/max = 250mm)film width-(min = 50mm/max = 400mm)

salient features:automatic and compact machinesimple operation and low maintenancetop quality components and best workmanshipall contact parts are made of stainless steel ss304/306easy pouch length adjustabilitymachine mounted on coaster wheels for easy movement

technical data : eminent bs-900w

vertical type continous band sealingmachine ( wide conveyor)

model:eminent-bs-900w

• packing weight - 5kg carrying load and 15kg conveyor load
• voltage(v/hz) - 240/50
• power (w) - 750
• heat sealing power(w) - 220x2
• sealing speed (m/min) -0-12
• sealing width -8-12mm
• temp range(deg.c) -0-300
• distance from sealing centre to conveying table(mm) :-150-270
• conveyor size(l x w) -840 x 300
• film thickness(mm) -0.08
• single conveyor loading(kg) -5kg
• over all conveyor loading -15kg
• dimension of machine(l*w*h) - 850x380x290
• weight - 32kg

Horizontal type Band sealing machine of 3kg, This is very economical and fast moving product. Coveyor Load Capacity is 3kg and Best Suitable for Sealing 1kg Pouches in domination of three packet at a time.There are many variety and prices as per quality.

technical details on request .Mini Hand Stacker. Stacker is ideal for lifting and transporting loads in your shop or warehouse

Have Proven record for accuracy and consistance quality machine, sutible for you any kind of granules type product weighing and filling

This is heavy duty machine used for lifting and placing the goods from one place to other within factory or warehouse.please contact for more details .

This machine is customized for Small sachets of Powder (Gul, masala etc).This is mechanical type in Half SS Covering Form Fill Seal Machine with proven Record .
It Can Be customized for any Granules type product or powder type product in small sachet depending upon product Charracteristics.
It Can also be customized for pillow pouches, centre seal pouches, three side seal pouches, four side seal pouches made of heatsealable laminate.

This is high accuracy 10 head and fourteen head Multi Head weigher .

We also offer Yamato, Ishida and ganton brand Multi head weigher.

This is used for any kind of regular or irregular granules product to fullfill the accuracy in weight through automatic packing machine,

This is basically used for chips, namkeen, bhujia, tea, seeds, kurkure, granul spices and many more.

semi automatic liquid/paste filling machines - gcg-bl

features
pneumatically activated piston with step less adjustment for volume, simple and compact structure, ss construction - easy to wash, outlet nozzle equipped with valve to avoid tripping , ss storage hopper , manual and auto modes
technical data
power -240 vac/50 hz./100 w
dispensing range -100-1000 ml
speed -10-15 doz/min
acuuracy -+ /- 1% of rated capacity

technical data : eminent ffs-ctm with auger filler
fully automatic collar type form fill and seal machine
model:eminent-ffs-ctm (pneumatic)product to be packed-powder, atta, basan, maida etc.

machine- ffs collar type pneumatic(mini)

control - plc panel (programmable logic control)

temperature controller- digital temperature control/pid type

unwinding system- simplex

sealing system - heat sealers

roll width - 400 mm (max.) 120 mm (min.)

pouch size- 55mm (width) x 55mm (repeat) [min.190mm (width) x 300 mm (repeat) [max.]

pouch type- centre seal pouch

filling system- cup filler/multi head weigher /auger filler(optional)

all product contact parts and covering -stainless steel and half ss covering

power consumption- 4 kw.

power supply- 3 phase/440 v + 2% with neutral ac supply at 50 hertz.

compressed air- 6 - 8 cfm @ 4-6 pressure bar

speed-up to 60ppm(depending upon the product and quantity to be packed)output & accuracy depends on following:filling system, characteristics of product to be packed, quantity of product to be packed, consistency in bulk density of the product, consistent level of product in machine hopper, maintaining rh in packing room if the product is hygroscope in nature,

brief details of ffs-ctmm/s eminent engineering services manufacture fully automatic collar type form fill and seal machine which is customized as an intermittent motion machine and designed for the efficient packing of the varieties of products like rice, seeds, tea, namkeen, bhujia, sugar, spices, snacks foods, wafers, detergent, henna powder, salt, wrapper candies, cheese biscuits etc. in center seal pouches.
the web path of roll systemized as which keeps on feeding the laminate to the pouch forming tube without much pulling tension to enable the machine to form wrinkle free pouch formation.it is a versatile machine and the pouch width can be changed very easily by replacing theforming tube and collar.changing of the pouch length does not require any change parts.
