Our Products
Part# | Rated Capacity (Ton) | Max. Pipe Diameter (inches) | Belt Width (inches) |
FLC-5 | 5 | 10, 12, 14, 16, 18, 20, 24 | 8″ |
FLC-10 | 10 | 20, 24, 26, 28, 30, 36, 40, 42, 48, 50 | 8″/10″ |
FLC-15 | 15 | 28, 30, 36, 40, 42, 48, 50, 56, 60 | 12″ |
FLC-20 | 20 | 28, 30, 36, 40, 42, 48, 50, 56, 60 | 8″×2 |
FLC-25 | 25 | 28, 30, 36, 40, 42, 48, 50, 56, 60 | 10″×2 |
FLC – 45 | 45 | 50, 56, 60, 65, 70, 72, 75, 80 | 10″x2/ 12″x2 |
We manufacture web ladders upto 300 meters long with connectors to make the ladder flexible to go upto any length required. Different variety of rungs of Aluminum alloy or Carbon fiber makes them upto 3 times lighter in weight compared to pp rope ladders. The non slip and load bearing pattern makes it best product to be used in confined spaces, mine access, scaffolding roofing, oil and gas and lowering purpose. The weight carrying capacities can go upto 2 tons so it is most ideal ladder for rescue operations, paramilitary forces and mountaineering usages. We manufacture the same in bright colors for distant locations and camouflage prints for army applications. |
Advantages:Lightweight Staggered rungs Rigid and reinforced Easy anchorage Easy installationWater and acid proof Spark resistant for gas chambers available on request. |
We manufacture great range of webbing produced from tested high strength polyester yarn. We produce complete range of polyester webbing for cargo straps, lashing & lifting slings from 13mm to 300 mm width. The webbing is manufactured as per American and European Standards and is available in rolls of 100m or any cut length as per customer requirements. We have state of art facilities for manufacturing, Dyeing, finishing , customized printing and stretching facilities for webbings.
We offer several products with increased cut resistance and/or abrasion resistance properties including our patented SUPEREDGE polyurethane impregnated premium tie-down. In addition to our current product line, we have the capabilities to offer specialized treatments/coatings to enhance the overall performance of the webbing. We also offer the services of our internal R&D Department for all customers to help construct just the right material to meet your needs.
Model | WLL (ton) | Jaw opening (mm) | A | B | C | D | E | F | G | H | Weight (kg) |
VPLC-1 | 1 | 0-16 | 55 | 12 | 16 | 45 | 40 | 140 | 60 | 155 | 4.54Kg |
VPLC-2 | 2 | 0-22 | 54 | 16 | 23 | 55 | 55 | 180 | 80 | 190 | 7.19Kg |
VPLC-3 | 3 | 5-30 | 72 | 20 | 25 | 60 | 58 | 190 | 100 | 230 | 9.34Kg |
VPLC-5 | 5 | 16-50 | 82 | 20 | 80 | 65 | 58 | 212 | 117 | 255 | 12.36Kg |
VPLC-8 | 8 | 40-80 | 118 | 20 | 40 | 80 | 80 | 295 | 145 | 355 | 32.12Kg |
VPLC-10 | 10 | 45-85 | 120 | 20 | 42 | 85 | 80 | 300 | 168 | 385 | 36.50Kg |
VPLC-12 | 12 | 50-90 | 120 | 20 | 45 | 90 | 80 | 325 | 180 | 400 | 39.90Kg |
Model | WLL (ton) | Jaw opening (mm) | A | B | C | D | E | F | G | H | Weight (kg) |
VPLC-1 | 1 | 0-16 | 55 | 12 | 16 | 45 | 40 | 140 | 60 | 155 | 4.54Kg |
VPLC-2 | 2 | 0-22 | 54 | 16 | 23 | 55 | 55 | 180 | 80 | 190 | 7.19Kg |
VPLC-3 | 3 | 5-30 | 72 | 20 | 25 | 60 | 58 | 190 | 100 | 230 | 9.34Kg |
VPLC-5 | 5 | 16-50 | 82 | 20 | 80 | 65 | 58 | 212 | 117 | 255 | 12.36Kg |
VPLC-8 | 8 | 40-80 | 118 | 20 | 40 | 80 | 80 | 295 | 145 | 355 | 32.12Kg |
VPLC-10 | 10 | 45-85 | 120 | 20 | 42 | 85 | 80 | 300 | 168 | 385 | 36.50Kg |
VPLC-12 | 12 | 50-90 | 120 | 20 | 45 | 90 | 80 | 325 | 180 | 400 | 39.90Kg |
Model | WLL [Ton] |
Opening mm |
A mm |
B mm |
C mm |
D mm |
E mm |
F mm |
G mm |
PLCTC 3 | 1.5 | 40 | 120 | 70 | 50 | 185 | 16 | 41 | 25 |
PLCTC 6 | 3 | 40 | 120 | 70 | 50 | 185 | 16 | 41 | 25 |
PLCTC 8 | 4 | 50 | 140 | 70 | 58 | 204 | 26 | 41 | 25 |
PLCTC 12 | 6 | 50 | 140 | 70 | 58 | 204 | 26 | 41 | 25 |
PLCTC 16 | 8 | 70 | 140 | 70 | 58 | 224 | 26 | 45 | 25 |
PLCTC 20 | 10 | 70 | 140 | 70 | 58 | 224 | 26 | 85 | 45 |
PLCTC 24 | 12 | 70 | 140 | 70 | 58 | 224 | 26 | 85 | 45 |
PLCTC 30 | 15 | 70 | 155 | 70 | 76 | 250 | 26 | 100 | 60 |
PLCTC 40 | 20 | 70 | 155 | 70 | 76 | 250 | 26 | 100 | 60 |
Description | WLL | Webbing Color | Size | Photo |
4″ Winch Strap with Flat Hook | 5,400 lbs | Yellow/as per need | 4″ x 27′ & 4″ x 30′ | |
4″ Winch Strap with D-Ring | 5,400 lbs | Yellow/as per need | 4″ x 27′ & 4″ x 30′ | |
4″ Winch Strap with Chain Anchor | 5,400 lbs | Yellow/as per need | 4″ x 27′ & 4″ x 30′ |
Description | WLL | Webbing Color | Size | Photo |
3″ Winch Strap with Flat Hook | 5,000 lbs | Yellow/ as per need | 3″ x 27′ & 3″ x 30′ | |
3″ Winch Strap with D-Ring | 5,000 lbs | Yellow/ as per need | 3″ x 27′ & 3″ x 30′ | |
3″ Winch Strap with Chain Anchor | 5,000 lbs | Yellow/ as per need | 3″ x 27′ & 3″ x 30′ |
Model | WLL (ton) | Jaw opening (mm) | A | B | C | D | E | F | G | H |
VPLC-1 | 1 | 0-16 | 55 | 12 | 16 | 45 | 40 | 140 | 60 | 155 |
VPLCS-1 | 1 | 0-25 | 55 | 12 | 16 | 45 | 40 | 140 | 60 | 155 |
VPLC-2 | 2 | 0-22 | 54 | 16 | 23 | 55 | 55 | 180 | 80 | 190 |
VPLC-3 | 3 | 5-30 | 72 | 20 | 25 | 60 | 58 | 190 | 100 | 230 |
VPLC-5 | 5 | 16-50 | 82 | 20 | 80 | 65 | 58 | 212 | 117 | 255 |
VPLC-8 | 8 | 40-80 | 118 | 20 | 40 | 80 | 80 | 295 | 145 | 355 |
VPLC-10 | 10 | 45-85 | 120 | 20 | 42 | 85 | 80 | 300 | 168 | 385 |
VPLC-12 | 12 | 50-90 | 120 | 20 | 45 | 90 | 80 | 325 | 180 | 400 |
Model | WLL (ton) | Jaw opening (mm) | A | B | C | D | E | F | G | H | Weight (kg) |
VPLC-1 | 1 | 0-16 | 55 | 12 | 16 | 45 | 40 | 140 | 60 | 155 | 4.54Kg |
VPLC-2 | 2 | 0-22 | 54 | 16 | 23 | 55 | 55 | 180 | 80 | 190 | 7.19Kg |
VPLC-3 | 3 | 5-30 | 72 | 20 | 25 | 60 | 58 | 190 | 100 | 230 | 9.34Kg |
VPLC-5 | 5 | 16-50 | 82 | 20 | 80 | 65 | 58 | 212 | 117 | 255 | 12.36Kg |
VPLC-8 | 8 | 40-80 | 118 | 20 | 40 | 80 | 80 | 295 | 145 | 355 | 32.12Kg |
VPLC-10 | 10 | 45-85 | 120 | 20 | 42 | 85 | 80 | 300 | 168 | 385 | 36.50Kg |
VPLC-12 | 12 | 50-90 | 120 | 20 | 45 | 90 | 80 | 325 | 180 | 400 | 39.90Kg |
Model | WLL (Ton) | Jaw Opening (mm) | T (mm) | U (mm) | V (mm) | L (mm) | Net Weight (Kg) |
HPLCSP-1 | 0.5 | 0-25 | 235 | 122 | 54 | 44 | 3.2 |
HPLCSP-2 | 1 | 0-25 | 262 | 155 | 60 | 50 | 5.3 |
HPLCSP-4 | 2 | 0-30 | 280 | 177 | 72 | 56 | 7.9 |
HPLCSP-6 | 3 | 0-38 | 315 | 209 | 88 | 58 | 10.5 |
HPLCSP-10 | 5 | 0-40 | 380 | 261 | 104 | 60 | 27.6 |
HPLCSP-16 | 8 | 0-50 | 488 | 290 | 139 | 100 | 48.5 |
HPLCSP-20 | 10 | 0-50 | 488 | 290 | 139 | 100 | 52.1 |
Model | WLL (ton) | Jaw opening (mm) | A | B | C | D | E | F | G | H | Weight (kg) |
VPLC-1 | 1 | 0-16 | 55 | 12 | 16 | 45 | 40 | 140 | 60 | 155 | 4.54Kg |
VPLC-2 | 2 | 0-22 | 54 | 16 | 23 | 55 | 55 | 180 | 80 | 190 | 7.19Kg |
VPLC-3 | 3 | 5-30 | 72 | 20 | 25 | 60 | 58 | 190 | 100 | 230 | 9.34Kg |
VPLC-5 | 5 | 16-50 | 82 | 20 | 80 | 65 | 58 | 212 | 117 | 255 | 12.36Kg |
VPLC-8 | 8 | 40-80 | 118 | 20 | 40 | 80 | 80 | 295 | 145 | 355 | 32.12Kg |
VPLC-10 | 10 | 45-85 | 120 | 20 | 42 | 85 | 80 | 300 | 168 | 385 | 36.50Kg |
VPLC-12 | 12 | 50-90 | 120 | 20 | 45 | 90 | 80 | 325 | 180 | 400 | 39.90Kg |
