GATHA Products and Services LLP.

Bibwewadi, Pune, Maharashtra

Description:

• Double disc variable speed, backed up by high torque, noiseless D.C. motors of 1/2 HP, with D.C drives, driving discs independently.
• Disc dia. - 200 mm. Continuous stepless variable speed up to 1400 r.p.m., with digital R.P.M. indicators.
• Complete Metallography Polishing set up. Double disc variable speed, backed up by high torque, noiseless D.C. motors of 1/2 HP, with D.C drives, driving discs independently.
• Continuous stepless variable speed up to 1400 r.p.m., with digital R.P.M. indicators.
• Anticorrosive- Thick - F.R.P. TOP Water faucet, built-in sink arrangement.
• Specimen storage drawer, paper (independent) storage cupboard.
• Etching reagent, Consumable storage front racks.
• Heavy duty warm air drier for immediate specimen drying, mounted on front. Quick paper change clamping ring.

PENETROMETER WITH BATH FOR BITUMEN & TAR(Analog Version) Penetrometer with bath for Bitumen &Tar Test : As per IS: 1203/1978

Use: Used for the determination of penetration of asphaltic bitumen and fluxed asphalt and blown type bitumen, Petroleum wax & jelly.

Description: Bath Unit consists of container of 20cm (H) x20cm (W) x35cm (L) Argon welded, needle, SS Cup 55mmdiax35mm (H) 8No. Transfer dish4No., Water bath Inner of SS304 and outer powder coated finish with motorized stirrer cum pump and a flange type hot+cold zone immersion SS304 heater of 1.5 Kw rating to maintain desired temp.

Temp. Range: 0°C-95°C, having cooling & heating arrangement controlled by a Digital Temperature controller cum indicator with PT-100 Sensor, Continuous duty Kirloskar compressor for cooling, electrically operated DC 230V plunger, penetration indicator between 225&350, Needle with 50 gms. and 100 gms. weights and timing device. Digital penetrometer for direct readout of penetration having Encoder & Decoder arrangement with digital timer 9.9 sec Max. The whole unit is mounted on castor wheels for easy movability.

Impact Testing Machines As per BS, ASTM and ISO Standard for Metal, Nonmetal and plastics range 2.71 Joule to 500 Joule capacity.

Features:

• For charpy tests on various materials.
• Strictly conforms to ASTM-E-23-2007 specifications.
• Works on pendulum principle. Difference between height of drop of pendulum before rupture and height of rise after rupture of specimen is directly proportional to impact energy absorbed by specimen and is indicated by a pointer on a large dial for Model-ASTM & on Digital Display for Model- ASTM (D).
• Single stand design which facilitates fast and easy positioning and centering of specimen which is a basic requirement of sub-zero testing.
• Unique spring loaded braking system for smooth and jerk free braking.
• NIST approval of machine with samples from NIST-USA. Can be arranged.
• Digital version of ASTM model will be available soon.

OPTIONAL ACCESSORIES:

• Self centering tong for Charpy test specimen (useful particularl for carrying out tests at sub zero temperature).
• Sub zero temperature bath with digital temperature indicator.
• Go: No-Go gauges for conforming the following parameters of specimen-within the limits specified by the standard.
• Center line of notch from both ends.
• Angle of V notch.
• Depth below standard V notch
• Cross section of 10x10 mm specimen.
• Milling cutter for V notch.
• Charpy & Izod notch (V&U) broaching machines.
• Lateral expansion gauge as per ASTM-E-23.
• Standard impact specimen for verifivcation of machine from NIST-USA (we also undertake calibration of the machine as per ASTM-E-23 including approval from NIST-USA).

Compliance with following International Standards: As per IS: 516, IS: 9399, BS: 1881, ASTM C78 100 kN Capacity flexural machine with Digital Load Indicator cum controller.
