Our Products
Our company is a renowned Manufacturer, Supplier and Exporter of Drill Hammer Assembly. We provide Drill Hammer Assembly in varied specifications. We make our range of Drill Hammer Assembly available at the best prices. We provide a design of Drill Hammer Assembly that is extremely durable and efficient.
Air Consumption
PSI | CFM |
---|---|
100 | 200 |
150 | 270 |
200 | 340 |
250 | 410 |
Specifications
Hole Dia | mm | 115 - 127 |
---|---|---|
Hammer Dia | mm | 98.0 |
Cylinder Bore | mm | 80.0 |
Piston Stroke | mm | 82.0 |
Piston Weight | Kg | 9.0 |
Hammer Length without bit | mm | 1040 |
Weight without Bit | Kg | 37.5 |
Connection | - | 2 3/8 API Reg./PIN |
Hammer Length with Bit Extend | mm | 1162 |
Hammer Length with Bit Retracted | mm | 1115 |
Wrench flat thickness of Top Sub | mm | 61.5 |
Suitable Bit | - | Mach 44 |
We are a renowned Manufacturer, Supplier and Exporter of Shank Adaptors. The variety of Shank Adaptors available with us is designed to be durable and efficient. We provide Shank Adaptors under the model name of "Deepex". Our Shank Adaptors are extensively appreciated for their precision engineering, compatible designs and low maintenance.
Highlights :
Specifications
Model | Pilot dia (mm) | Reamed dia(mm) | Casing OD/ID(mm) | Guide device shank |
---|---|---|---|---|
Deepex 90 | 90 | 123 | 115/102 | DHD3.5 |
Deepex 115 | 115 | 152 | 142/128 | DHD340,SD4,PANTHER |
Deepex 140 | 140 | 181 | 171/157 | DHD350,SD5 |
Deeepex 165 | 165 | 209 | 196/183 | DHD360,SD6 |
Deepex 190 | 190 | 237 | 222/205 | DHD360,SD6 |
Deepex 240 | 240 | 306 | 237/260 | DHD380,SD8 |
We have earned a name of repute as a Manufacturer, Supplier and Exporter of a varied range of Drilling Bit Faces. The range of Drilling Bit Faces provided by us is used in various drilling machines and equipment for drilling and mining purposes. We provide Drilling Bit Faces at the best rates in the market. The Drilling Bit Faces provided by us are of three types :
