Mac-Flow Engineers
gstGST : 27BCMPC1294B1ZW 5.0/5

Industrial Seals

We offer a complete product range of Metal Bellow inside Mounted Seal, Hook Type Metal Bellow Seal, Rotating Metal Bellow Seal, PTFE Bellow Replaceable and PTFE Bellow Seal

Metal Bellow Inside Mounted Seal

  • Pressure 18 Bars(max)
  • Shaft Diameter 19 To 100 Mm
  • Temperature -20 To +350°C
  • Seal Ring Face Carbon, SiC & T.C
  • Seat Face SiC & T.C
  • Elastomer Viton, PTFE, FEP, EPDM, FFKM
  • MOC SS 316 / SS 304, Hast-C
  • Product Code MF-MB 001

Applications :

  • Chemicals
  • Petrochemicals & Petroleum Reneries
  • Hot Oil
View Complete Details

Hook Type Metal Bellow Seal

  • Pressure 18 Bars(max)
  • Shaft Diameter 19 To 100 Mm
  • Temperature -20 To +350°C
  • Velocity Up to 20 m/sec / 3000 r.p.m
  • Seal Ring Face Carbon, SiC & T.C
  • Seat Face SiC & T.C
  • Seat Face Viton, PTFE, FEP, EPDM, FFKM
  • MOC SS 316 / SS 304, Hast-C
  • Product Code MF-MB 002

Applications :



Chemicals

Petrochemicals & Petroleum Reneries

Hot Oil

View Complete Details

Rotating Metal Bellow Seal

  • Pressure 16 Bars(max)
  • Shaft Diameter 19 To 100 Mm
  • Temperature -40 To +220°C
  • Seal Ring Face Carbon, SiC & T.C
  • Seat Face SiC & T.C
  • Elastomer Viton, PTFE, FEP, EPDM, FFKM
  • MOC SS 316 / SS 304, Hast-C
  • Product Code MF-MB 003

Applications :

  • Process industry
  • Oil & gas industry
  • Chemical Industry
  • Pharmaceutical industry
  • Pulp & Paper industry
  • Food & beverage Industry
View Complete Details

PTFE Bellow Replaceable

  • Velocity Up To 20 M/sec / 3000 R.p.m.
  • Replaceable Face GFT, CFT, SiFT
  • Shaft Diameter 18 to 100 mm
  • Pressure 8 Bars(max)
  • Temperature -40 to +160°C
  • Seal Ring Face GFT, CFT & SiC
  • Seat Face Ceramic & SiC.
  • Elastomer PTFE & GFT
  • MOC SS 316 / SS 304, Hast-C
  • Product Code MF-51
View Complete Details

PTFE Bellow Seal

  • Velocity Up To 20 M/sec / 3000 R.p.m.
  • Non Replaceable Face GFT & CFT
  • Shaft Diameter 18 to 100 mm
  • Pressure 8 Bars(max)
  • Temperature -45 to +160°C
  • Seal Ring Face GFT, CFT & SiC
  • Seat Face Ceramic & SiC.
  • Elastomer PTFE & GFT
  • MOC SS 316 / SS 304, Hast-C
  • Product Code MF-52
View Complete Details

Close Type Rubber Bellow Seal

  • Shaft Diameter 10 to 70 mm
  • Pressure 5 Bars(max)
  • Temperature -20 to +100°C
  • Velocity Up to 20 m/sec / 3000 r.p.m.
  • Seal Ring Face Carbon, SiC & T.C
  • Seat Face Ceramic, SiC & T.C
  • Elastomer Viton, Neoprene, EPDM, NBR and Buna-N
  • MOC SS 316 / SS 304
  • Product Code MF-32
View Complete Details

Multiplespring Mechanical Seal

  • Pressure 8 Bars(max)
  • Shaft Diameter 16 To 70 Mm
  • Temperature Up To 120°C
  • Velocity Up To 20 M/sec / 3000 R.p.m.
  • Seal Ring Face Carbon, SiC & GFT
  • Seat Face Ceramic & SiC
  • Elastomer Viton, EPDM, TTV, FEP & FFKM
  • MOC SS 316 / SS 304
  • Product Code MF-91

Applications :

  • Chemical
  • Hot Oil Pumps.
View Complete Details

Multiplespring Mechanical Seal With Clamp

  • Pressure 8 Bars(max)
  • Shaft Diameter 16 To 70 Mm
  • Temperature Up To 120°C
  • Velocity Up To 20 M/sec / 3000 R.p.m.
  • Seal Ring Face Carbon, SiC & GFT
  • Seat Face Ceramic & SiC
  • Elastomer Viton, EPDM, TTV, FEP & FFKM
  • MOC SS 316 / SS 304
  • Product Code MF- 92

Applications :

  • Chemical
  • Hot Oil Pumps.
View Complete Details

Conical Spring Seals

  • Shaft Diameter 12 to 90mm
  • Pressure 10 Bars(max)
  • Temperature -20 to +180°C
  • Seal Ring Face Carbon, SiC & T.C
  • Seat Face Ceramic, SiC & T.C
  • Elastomer Viton, Neoprene, EPDM, NBR
  • MOC SS 316 / SS 304
  • Product Code MF-34
View Complete Details

Single Spring Seals

  • Shaft Diameter 14 to 120 mm
  • Pressure 8 Bars(max)
  • Temperature -23 to +180°C
  • Seal Ring Face Carbon, SiC & T.C
  • Seat Face Ceramic, SiC & T.C
  • Elastomer Viton, PTFE, TTV, EPDME, NBR
  • MOC SS 316 / SS 304
  • Product Code MF-41/42
View Complete Details

Multi Spring Seal (Balance)

3,000 - 4,500 / Piece Get Latest Price
  • Min. Order (MOQ) 10 Piece
  • Pressure 35 Bars(max)
  • Shaft Diameter 16 To 100 Mm
  • Temperature -40 To +180°C
  • Velocity Up To 20 M/sec/3000 R.p.m
  • Seal Ring Face Carbon, GFT, SiC & T.C
  • Seat Face Ceramic, SiC & T.C
  • Elastomer Viton, PTFE, TTV, EPD, NBR, FFKM
  • MOC SS 316 / SS 304
  • Product Code MF 43b

Applications :



  • Petrochemicals
  • Reneries
  • General Chemicals
  • Light Hydrocarbon.
View Complete Details

Multi Spring Seal ( Unbalance)

  • Pressure 10 Bars(max)
  • Shaft Diameter 10 To 100 Mm
  • Temperature -20 To +260°C
  • Velocity Up To 20 M/sec/3000 R.p.m
  • Seal Ring Face Carbon, GFT, SiC & T.C
  • Seat Face Ceramic, SiC & T.C
  • Elastomer Viton, PTFE, TTV, EPD, NBR, FFKM
  • MOC SS 316 / SS 304
  • Product Code MF-43u

Applications :



  • Water Pumps
  • Circulating Pumps for Central Heating
  • Chemical Pumps
  • Sewage & Submersible Pumps.
View Complete Details

Multi Spring Pusher Seals

2,000 - 40,000 / Piece Get Latest Price
  • Min. Order (MOQ) 10 Piece
  • Pressure 25 Bars(max)
  • Shaft Diameter 1” To 4.5”
  • Temperature -20 To +180°C
  • Velocity Up To 20 M/sec / 3000 R.p.m
  • Seal Ring Face Carbon, SiC & T.C
  • Seat Face Ceramic, SiC & T.C
  • Elastomer Viton, PTFE, TTN, EPDM, NBR
  • MOC SS 316 / SS 304
  • Product Code MF- 47

Applications :



  • Food Industry
  • Sugar Industry
  • Water Treatment
  • Media Containing Slurry
  • Chemical Industry
  • Mining Industry
View Complete Details

Wave Spring Seals

  • Shaft Diameter 18 to 100 mm
  • Pressure 60 Bars(max)
  • Temperature -45 to +180°C
  • Velocity Up to 20 m/sec / 3000 r.p.m
  • Seal Ring Face Carbon, SiC & T.C
  • Seat Face Ceramic, SiC & T.C
  • Elastomer Viton, PTFE, TTN, EPDM, NBR
  • MOC SS 316 / SS 304
  • Product Code MF- 48

Applications :



  • Light Abrasive Slurry
  • Light Sewage Water
  • High Viscosity Fluids
  • General and Light Chemicals & Hydrocarbons.
View Complete Details

Semi Cartridge Seal (Inside Mounted)

  • Size 25mm To 80mm / 1” To 3”
  • Pressure 07 Bars(max)
  • Temperature -30 to +260°C
  • Seal Ring Face Carbon, T.C & SiC
  • Seat Face SiC. & T.C.
  • Elastomer Viton, TTV, PTFE, FEP & FFKM
  • MOC SS 316 / SS 304, Hast-C
  • Product Code MF 61d/ Mf61s

Applications :



  • Pulp Pumps
  • Sludge Pumps
  • Syrup Pumps
  • Slurry Pumps.
View Complete Details

Cartridge Seal ( Balance)

  • Pressure 25 Bars(max)
  • Temperature -20 to +350°C
  • Velocity Up to 20 m/sec / 3000 r.p.m.
  • Seal Ring Face Carbon, T.C & SiC
  • Seat Face SiC. & T.C.
  • Elastomer Viton, TTV, PTFE, FEP & FFKM
  • MOC SS 316 / SS 304, Hast-C
  • Product Code MF- 62

Applications :



  • Pulp Pumps
  • Sludge Pumps
  • Syrup Pumps
  • Slurry Pumps.
View Complete Details

Wet Seal With Bearing

  • Size 25 to 150mm
  • Pressure Vac to 8 Bars(max)
  • Temperature Ambient to +180˚C
  • Seal Ring Face Carbon & SiC
  • Seat Face SiC. & T.C.
  • Elastomer Viton, TTV, FEP & FFKM
  • MOC SS 316 / SS 304
  • Product Code MF-410

Applications :



  • Corrosive Chemicals
  • Hydrocarbons
  • General & light Chemical
  • Mixers & Agitators.
View Complete Details

Double Seal (SS Reactor)

  • Temperature Ambient to +200˚C
  • Velocity Up to 320 RPM
  • Barrier Fluid Pressure Vessel Pressure + 1.5 Bar
  • Seal Ring Face Carbon & SiC
  • Seat Face SiC. & T.C.
  • Elastomer Viton, TTV, FEP & FFKM
  • MOC SS 316 / SS 304
  • Product Code MF- 430d

Applications :



  • Petrochemicals
  • General Chemicals
  • Light Hydrocarbons
  • Emitting Vapour
  • Pharma Industry
View Complete Details

Reactor Dry Seal

  • Size (Inches) 20 To 150mm
  • Velocity Up To 320 RPM
  • Seal Ring Face Carbon & SiC
  • Seat Face SiC. & T.C.
  • Elastomer Viton, TTV, FEP & FFKM
  • MOC SS 316 / SS 304
  • Product Code MF- 610

Applications :



  • Food Products
  • Pharmaceutical Products
  • Mixers
  • Agitators.
View Complete Details

Single Spring Seal (Unbalance)

  • Shaft Diameter 12 to 100mm
  • Pressure 10 Bars(max)
  • Temperature -60 to +200°C
  • Seal Ring Face Carbon, GFT, SiC & T.C
  • Seat Face Ceramic, SiC & T.C
  • Elastomer Viton, PTFE, GFT, TTV, EPDM, NBR, FFKM
  • MOC SS 316 / SS 304
  • Product Code MF- 45/46
View Complete Details
