Filters #4106067

Rainy Filter - FL 100Technical Specifications & Parameters of Model FL 100 Overall Dimension On Site Installation Suitable up to area: 110 SQMTRSMax: Intensity of Rainfall: 75 mmhrWorking Principle : Cohesive Force & Centrifugal forceOperating Pressure: Less than 2 feet of head (0.060kgcm2)Capacity: 105 LPMFilter Element: SS-304 ScreenMesh Size: 250 MicronsInlet: 90 MMClean Water Outlet: 63 MMDrain Outlet: 90 MMHousing: High Density PolyethyleneEfficiency of Filter: Above 90%Source of Power: GravityThe characteristic features of FL Series Dual Intensity RWH Filter is its capacity to take up the load up to 10 to 110 square meters of Roof area with variable intensity of rainfall of 5 to 75 mm hour with a discharge capacity of 10 to 105 Liters per minute. This filter can be conveniently used for Harvesting Rainwater for Individual households, Schools, and Smaller Roof area Buildings.

The characteristic features of fl series dual intensity rwh filter is its capacity to take up the load up to 10 to 225 square meters of roof area with variable intensity of rainfall of 5 to 75 mmhour with a discharge capacity of 10 to 225 liters per minute. This filter can be conveniently used for harvesting rainwater for individual households, schools, apartments, institutions, and commercial buildings of medium sizes.

The characteristic features of fl series dual intensity rwh filter is its capacity to take up the load up to 10 to 350 square meters of roof area with variable intensity of rainfall of 5 to 75 mm hour with a discharge capacity of 10 to 340 liters per minute. This filter can be conveniently used for harvesting rainwater for individual households, schools, apartments, institutions, hospitals and commercial buildings of medium and small sizes.

The characteristic features of fl series dual intensity rwh filter is its capacity to take up the load up to 10 to 500 square meters of roof area with variable intensity of rainfall of 5 to 75 mm hour with a discharge capacity of 10 to 480 liters per minute. This filter can be conveniently used for harvesting rainwater for apartments, institutions, hospitals, commercial buildings, industries, corporate houses of medium and large sizes.
