Our Products
We offer the best product range of Order Picker Stacker, Walkie Reach Stacker, Gear Box Jack, Mono Strand Jack and Multi Strand Jack.
We bring forth a compact design Walkie Reach Stacker that is widely used for stocking different types of goods in various small scale and large scale industries. Our Walkie Reach Stacker is known for its operation efficiency and excellent load capacity, i.e., 1300 kgs. Walkie Reach Stacker is easy-to-operate as it is run by electricity.
Specifications
| Model | MTWRS1316 | MTWRS1330 | MTWRS1330 | |
|---|---|---|---|---|
| Drive / Type of Operation | Electric / Pedestrain | |||
| Load capacity | Kgs | 1300 | ||
| Load center | Mm | 600 | ||
| Service weight | Kgs | 1820 | 2020 | 2460 |
| Tyres | Polyurethane | |||
| Lowest mast height | Mm | 2076 | 2100 | 2096 |
| Free Lift | Mm | 1550 | 1520 | 1520 |
| Lifting height | Mm | 1600 | 3000 | 4500 |
| Extemted mast height | Mm | 2463 | 3863 | 5395 |
| Fork lowered height | Mm | 50 | ||
| Over all length | 1 (mm) | 2265 | 2290 | 2400 |
| Length of face fork | I2(mm) | 1115 | 1140 | 1250 |
| Over all width | Mm | 1104 | ||
| Fork dimentions | Mm | 35/100 950 (1150) | ||
| Width over forks | Mm | 200 740 | ||
| Reach Distance | Mm | 550 | 580 | |
| Ground clearnce | Mm | 60 | ||
| Turining radius | Mm | 1593 | 1689 | |
| Service brake | Electro magnetic | |||
| Drive Motor rating | Kw | 1.8 | ||
| Lifting motor rating | Kw | 2.2 | 3 | |
| Battery voltage | v/Ah | 24/270 | 24/400 | |
We are reckoned as one of the prime Manufacturers and Suppliers of Hydraulic Bolt Tensioning. Precisely engineered, Hydraulic Bolt Tensioning features composite material seals for easy piston retraction. Its light weighted construction and rich ergonomics ensure easy usage to work. They can be offered in customized sizes to fit any size of bolt and deliver any load requirement.
PDF Details :
Our Order Picker Stacker is widely in demand owing to its ease of operation and perfection in handling the bulk material. With the aid of our Order Picker Stacker, the materials get easily stacked at any place desired. Order Picker Stacker that we offer is used in warehouses and appreciated for its low maintenance and longer functional life.
Technical Specifications
| Model | -- | MTOPL14 | MTOPL25 |
|---|---|---|---|
| Drive | -- | Electric | Electric |
| Load capacity | Kg | 1400 | 2500 |
| Load center | Mm | 600 | 600 |
| Wheelbase | Mm | 2032 | 1965 |
| Service weight | Kg | 1300 | 1200 |
| Lift height min | Mm | 715 | 140 |
| Overall length | Mm | 2735 | 2580 |
| Overall width | Mm | 796 | 996 |
| Length of face of fork | Mm | 1585 | 143/ |
| Fork dimension | Mm | 60/180/1150 | 60/180/1150 |
| Travel speed | 8.5/9.5 | 7.5/9.0 |
