Nathan Industries Coimbatore, Tamil Nadu

Double column rigidly designed, maintenance free gearing unit, with case hardened Shafts and Gears and heavy duty ball bearings, at all points, are superior by virtue of their easy handling, simpler means of changing gears. We can provide 3 roller drafting arrangements with 45Degere and 60 degrees for Ring frames and for speed frame with 3 roller drafting system or 4 roller drafting system with 15degerees.   We also provide spare for draft gearing unit separately like:- Middle roller support brackets- Right hand side & Left hand side, Back roller support brackets - Right hand side & Left hand side, Swivel Bracket

Drive Studs are manufactured out of special graded steel material to suit its requirement. All type of studs are induction hardened and ground to the required hardness at various places.   We manufacture the Gear end drive pieces, Pinion’s with various number of teeth’s like 10 teeth, 11 teeth, 16 teeth etc., and Off end pieces to your needs as per your Sample or Drawings. We can also provide you ground gears for your requirement

We manufacture bottom rollers of high quality standards. The optimal groove angles and groove profile, along with special surface finish provide friction free smooth running and better fiber control over the rollers. We provide Cold Rolled Alternate Helical fluted rollers and Knurled rollers which provides more number of nipping points for better control of fiber and better cot life, precisely ground flutes to give better yarn quality and free from peak problems. Our rollers suits for 100% Cotton, Blends of Cotton and man made fiber or 100% man made fiber. We manufacture fluted rollers for various processes as mentioned below from 25mm diameter to 40mm diameter.   1. Gauge from 63.5mm to 130mm 2. Number of spindles between roller stands are 8, 6, 4 spindles. Fluted Rollers – Bottom Rollers – Drafting Rollers – Knurled rollers : 1. Diameters : 25mm, 25.4mm, 27mm, 28mm, 28.5mm, 30mm, 32mm,    35mm, 38mm, 40mm. 2. Flute length : 32mm, 35mm, 40mm, 45mm, 52mm   Laxmi Rieter LR G5/1   Laxmi Rieter LR-6   Laxmi Rieter LR-63   Laxmi Rieter 6A   Laxmi Rieter 6S   Laxmi Rieter 6AX   KTTM RXi 240   Suessen Finomax 1000   Textool 4A   Textool 5A   Textool 5HS   Textool 5HRS   Textool Narrow Width   Textool DJ-50   Textool DJ-500   Textool Worsted WS-60   Texmaco K2   Texmaco Hi-Spin   Texmaco Howa NMM - MEI -   Mark-I NMM - MEI -   Mark-II NMM - MEI -   Mark III   MMC Marzoli   Jeets - JSA   Jeets - JS 1   Jeets - JS 2   Jeets - JS 3   United Machine Works (UMW)   United Machine Works (UMW) worsted   Sathish Ring Frame   Sathish Worsted   Retex   RKI   Zinser 68 i   Marzoli   Toyoda RY-5   Platts   Platts Sacolowal   Rieter   NMM Worsted   NSC Worsted

Wind mill Brake pad and Friction material : Friction materials are utilized in the braking systems of automobiles, commercial vehicles, aircraft, motorcycles, trains and off-road vehicles and in other industrial applications. In simple terms, these materials help stop vehicles as a part of the brake pad or drum brake lining. The exact composition of a brake lining is often a closely guarded secret, and the process of achieving it almost as much an art as a science. Iron powder is a key ingredient in semi-metallic brake linings, enhancing both the performance and the long-term reliability and durability of the product.

Nathan Industries Traverse Motion gearing unit along with other devices extends the life of the Top Roller Cots and also the life of Top and Bottom Aprons. The Travers can be adjusted according to the bottom Apron width. The movement of the traverse motion can be adjusted from 6mm to 15mm according to your requirement. If necessary we can provide extra traverse ( movement )width as per your requirement.

We manufacture Cast Iron Roller Stand which are made out of high grade induction melt Cast Iron, Most precisely machined, perfect in all aspect suitable for Ring Frame and Speed Frame and Doubling Machine as per your requirement of various center height and various drafting angles like 45°and 60° for Ring Frame and 15/ 10° for Speed Frame. We provide both Needle Bearing type Roller Stand and Bush Bearing type Roller Stand   1. We provide Roller Stand with and without slides for Middle and Back Lines.   2. We provide slides separately.
