steel diesel tanks is fabricated using MS (IS2062), SS (SS304 304L, 316316L), CS (SA516) Features: • Leakage proof • Corrosion resistant • High efficiency • Sturdy

Lamella plate separators (LPS) consists of two main components, the upper tank containing the lamella plates inclined at 55 degree and the lower conical or cylindrical sludge tank. The feed for the LPS enters through vertical chambers on either side of the lamella packs and passes into each plate gap through slotted feed ports. Clarification takes place above the suspension inlet so there is no mixing of the clarified fluid with the incoming feed. Above each pack is a full-length overflow launder fitted with throttling holes to create a slight hydraulic back pressure on the incoming feed stream. This method of feed control guarantees equal distribution to all lamella chambers with minimum turbulence at the entry points. The solids settle onto and slide down each lamella plate to the sludge tank where the solids are further thickened and compressed with the assistance of the raking system. Advantages: • Heavy duty construction of tank, sludge hopper and lamella plate packs, as well as the rake system. Rake lifting mechanism as option. • Positioning of specifically designed feed ports for optimum ratio between clarification and thickening area • Wide spacing of lamella plates to handle high density feed pulps and coarse solid particles. • No short circuiting or surface turbulence • Integrated flocculator with variable speed stirrer Lower Installation Costs: • Delivered as one-piece unit or in prefabricated sections • Smaller foundations • less floor space • Square outline for easier planning and construction. Flexibility For Plant Changes Or Extension: • Can be installed in any system • Easy to relocate to adapt to process changes Simplified In Plant Installation: • Shorter pipe work runs. • High level installation for gravity feed to downstream Processes • Easier supervision. Small Internal Volume And Surface Area: • Easily insulated against heat loss or toxic fume emissions • Evaporative losses are minimized. Simple Construction Of Sheet Steel And Standard Profiles: • Special materials and coatings can easily be incorporated • Easy to maintain

We offer one of the finest engineered dosing systems manufactured with a mixture of materials such as carbon steel or stainless steel for base support frames, and pipe work in stainless steel or high alloys. These dosing systems are suitable for use in on and off shore industries including petrochemical, pharmaceutical, oil and gas, paper, food, nuclear power and bio-technology. Our range of HP dosing systems and LP dosing systems incorporate suction and discharge pipes which swiftly and safely deliver the chemicals to their destination and help our clients to reduce or prevent corrosion and deposition of the fluids being carried. These chemical dosing skids are manufactured to meet individual requirements and are both accurate and durable for all industrial applications. Product types include mixing, chemical dosing. Our chemical dosing skids can also be used in a range of applications where vessels, pipe work, valves, controls and filters among others combine. Key Features: • Meet international quality standards • Cost efficient and ensure the highest quality standards • Maximum dimensions per section • All products are fully welded and tested

We offer sewage treatment plants that is designed for reprocessing of water for gardening, irrigation flushing purpose. The waste water of commercial and residential complex is treated by these sewage treatment plants. We install these sewage treatment plants as per the specification of client. Features: • Safe and sturdy • High performance • Easy to operate • Corrosion resistant

We offer sand filters and carbon filters which uses a natural media based filtration technology, which treats water or wastewater with turbidity, odor & color. In this different layers of graded sand & pebbles are used for filtration. In activated carbon filters surface area OS anthracite is increased to many folds by special process. this helps to trap unwanted odor, color & gases in water. Both PSF (Pressure Sand Filter) & ACF (Activated Carbon Filter) are offered in manual & automatic modes. Applications: •Industries(textile, dying, chemical, pharmaceutical etc.) • Hospitals • Schools & Colleges • Shopping malls • Housing colonies • Theaters

Our mixed bed is based on latest technology and widely used in water purification industry. The mixed bed consists of strong acid cation exchange and strong base anion exchange resin that is used for purification of water. Features: • Long functional life • High efficiency • Corrosion resistant

We install UF skid and piping system in accordance with clients specification. Developed using SS (SS304 / 304L, 316/316L), the UF skid and piping system is extensively used in water purification industry. Features: • Easy to operate • High efficiency • Corrosion resistant • Sturdy

We offer one of the finest engineered dosing skids manufactured with a mixture of materials such as carbon steel or stainless steel for base support frames, and pipe work in stainless steel or high alloys. These dosing skids are suitable for use in on and off shore industries including petrochemical, pharmaceutical, oil and gas, paper, food, nuclear power and bio-technology. Our range of dosing skids incorporate suction and discharge pipes which swiftly and safely deliver the chemicals to their destination, and help our clients to reduce or prevent corrosion and deposition of the fluids being carried. These chemical dosing skids are manufactured to meet individual requirements and are both accurate and durable for all industrial applications. Product types include mixing, scrubbing, filtering, reactors, stripping, chemical dosing and cooking. Our chemical dosing skids can also be used in a range of applications where vessels, pipe work, valving, controls and filters among others combine. Key Features: • Meet international quality standards • Cost efficient and ensure the highest quality standards • All products are fully welded and tested
