Prabhat Electronics

Tughlakabad, Delhi

Details

• 8 CH dmx booster/splitter
• 220 volt 50Hz main input
• Power input by PC socket
• Each ch output indicators after data receiving.
• Data input by male xlr socket
• Output by Female xlr socket
• Data out put lenght 200 mtr. 14/36 SWG Wire.
• Each way /ch load 10-15no.

Details

• 8 CH DMX booster/splitter
• 180-220 Volt Ac 50Hz main input
• Power input by PC socket
• Each ch output indicators
• Data input by male xlr locking socke Output by Female xlr locking socket
• Data receiving lenght 200 mtr. 14/36
• Each way /ch load 15-20no
• Fully Isolated output.
• Use in Side 5 Transformer.
• Each Socket Locking Feature
• One Supply for Pre Amp.
• 4 Supply for 8 Output

Details

• 8 CH dmx booster/splitter
• 220 volt 50Hz main input
• Power input by PC socket
• Each ch output indicators
• Data input by male xlr locking socket
• Output by Female xlr locking socket
• Data output length 200 mtr. 14/36 SWG Wire
• Each way /ch load 15-20no.

Details

• 12 CH dmx booster/splitter
• 220 volt 50Hz main input
• Power input by PC socket
• Each ch output indicators
• Data input by male xlr socket
• Output by Female xlr socket
• Data output length 100 mtr. 14/36 SWG Wire
• Each way /ch load 10-15no.

Details

• 5 Pin XLR Splitter
• 4 CH dmx booster/splitter
• 220 volt 50Hz main input
• Power input by PC socket
• Each ch output indicators
• Data input by male xlr socket
• Output by Female xlr socket
• Data receiving lenght 200 mtr. 14/36
• Each way /ch load 15-20no.
• Each ch Locking Feature
• Data Polarity
• Charging Switch
• Inner Side 2 L Type Mounting Clamp
• One Cord of 1 Mtr.

Details

• 3 Pin XLR Splitter
• 4 CH dmx booster/splitter
• 220 volt 50Hz main input
• Power input by PC socket
• Each ch output indicators
• Data input by male xlr socket
• Output by Female xlr socket
• Data receiving lenght 200 mtr. 14/36
• Each way /ch load 15-20no.

Details

• Prabhat Electronics DMX splitter Booster, isolate and protect console DMX output.
• The device operates from AC 180-240 volt .
• Power supply 1 amp. 2 Transformer internal use.
• The Truss splitter is 8 way output. Each output isolated ic use.
• This Truss dmx splitter is 124mm Round shape.
• One C Clamp Available for truss mounting.
• 8 no. F male xlr for output and one F for Thro.
• One M Xlr For dmx input, Power on indicators and dmx input indicators.
• Each chn. output idicators.
• One computer cord free with this product each no.
• Each chn. 15 no.dmx equipment or 300 feet distance working capacity.
• Fully Isoelted From Chesisss
