Resolution
1024 * 768 (XGA)
-
BIOS
SPI AMI EFI BIOS
-
Chipset
HM65, HM67, QM67
-
Operating Temp
-10℃~60℃
-
Display
VGA, HDMI, LVDS(Dual 8)
-
USB
4 x USB 2.0 , 2 x USB 3.0,
-
Brightness
500 (cd/m2)
-
Size/Type
15’’ TFT LCD
B TECH RPC-151P series is a low power-consumption, Fan-less designed, enhanced stability and reliability 15-inch Industrial Touch Panel PC product. It adapts Intel Core i7-2620M 2Core 4Threads processor. RPC-151P series storage can support 2.5 SATA and mSATA interface, HDD or SSD. The design uses a multi-point (10- points) projective capacitive touch screen (Optional with high-temp. five-wires resistive touch, or No touch), and it can fulfill front panel NEMA/IP65 dust-proof and water-proof standards. The RPC-151P uses full-sealed box construction, and it can prevent dust from entering the device system. The RB TECH RPC-151P is compatible with Win8, Win10, Win 11, Linux OS, and it also has a good compatibility with customized applications and software programs Key Features: 15 Projective Capacitive Multi-point Touch; Intel Core i7-2620M Processor 4M Cache, up to 3.40 GHz Impact, Fan-less Design, Finned Heat Sink; 2 * GLAN, And 1* 2.5 Sata + 1* Msata; Wide-temp Range, Support -10+70 ; Optional Precision High-temp. Five Wires Resistive Touch; Optional No-touch Function, With Glass Option HSUPA/GPRS/GSM, Wi-Fi and Bluetooth Built-in GPS function Built-in OBD-II/CAN 2.0
