Our Products
We offer a complete product range of Radicon-Trinocular Tissue Culture Fluorescence Microscope (RTTC-616 Max Plus FL), Radicon Travelling Microscope with Two Motion (Model RTM-60), Radicon Travelling Microscope with Three Motion (Model RTM60 Deluxe), Radicon-Advance Dissecting Microscope (Model RDM42A) and Radicon Dissecting Microscope (Model RDM-42 )
Observation: Trinocular head, 45 inclined, interpupillary distance adjustment range 54 – 75mm, one eyepiece tube with +5 diopter adjustment light splitting ratio: binocular 100%, binocular 0% Trinocular 100%.
Objective
Long working distance infinity plan fluorescence objective. LWD 4X/0.13/WD18.52, LWDPH10X/0.30/WD7.11, LWDPH20X/0.45/WDS.91, LWDPLF40X/0.65/WD1.61. Phase contrast kit with centering telescope and green filter.
Stage and accessories: 160 x 250mm platform; Mechanical stage, move range 120 x 78mm; auxiliary stage 70 x 180mm; Slide Glass Holder; Metal stage with slot; Terasaki holder; Holder for Ø35mm petri dish vessel.
Microscope Body: Co – axial focus system, coarse focus distance 25mm, fine focus precision 0.002mm, with degree of tightness adjustment, built – in 90 – 240V wide voltage transformer.
Illumination: Centering objective for mercury lamp. Optical band pass filter cubes: UV1/B1/G130ND25 attenuation pad. The light – filter system of main body: 2 excitation light waves, B (blue filter), G (green filter) and O (transmitted light).
Consists of a heavy cast iron base with machined- Vee-top surface and is fitted with three leveling screws. A metallic carriage, clamped to a spring loaded bar slides with its attached vernier and reading lens along an inlaid strip of metal scale. The scale is divided in half millimeters. Fine adjustments are made by means of a micrometer screw for taking accurate reading. Both vernier reading to 0.01mm or 0.02mm. Microscope tube consists of 10x Eyepiece and 15mm or 50mm or 75mm objectives. The Microscope, with its rack and pinion attachment is mounted on a vertical slide, which too, runs with an attached vernier along the vertical scale. The microscope is free to rotate n vertical plane. The vertical guide bar is coupled to the horizontal carriage of the microscope. For holding objects a horizontal stage made of a milky sheet is provided in the base. Packed in wooden box.
Consists of a heavy cast iron base with machined- Vee-top surface and is fitted with three leveling screws. A metallic carriage, clamped to a spring loaded bar slides with its attached vernier and reading lens along an inlaid strip of metal scale. The scale is divided in half millimeters. Fine adjustments are made by means of a micrometer screw for taking accurate reading. Both vernier reading to 0.01mm or 0.02mm. Microscope tube consists of 10x Eyepiece and 15mm or 50mm or 75mm objectives. The Microscope, with its rack and pinion attachment is mounted on a vertical slide, which too, runs with an attached vernier along the vertical scale. The microscope is free to rotate n vertical plane. The vertical guide bar is coupled to the horizontal carriage of the microscope. For holding objects a horizontal stage made of a milky sheet is provided in the base. Packed in wooden box.
Boom stands used with stereo microscopes allow for adjusting the microscope head around three axes (x, y and z) and to precision adjust the microscope to point at a specimen in any direction. Double arm boom stands with ball bearing slide mechanisms are appropriate for use with heavier microscopes and in commercial applications where the microscope head is adjusted often.
Illumition : LED ring ligh attachment for incident light illumination from the top of the microscope. Ring light should be detachable from the microscope body.
Mechanical Body
USB Digital Camera : 5.0 Megapixel Color CMOS sensor, Size 1/2“, Pixel size 2.2x2.2 micron Resolution 2592x1944 PC interface, 30 bit color depth, exposure time 1 Microsecond to 2 seconds. High Image Transmission convenient to use any standard Microscope. Digital Camera can change image into Digital signal & send it to your P.C.
Observation Head: Seidentopf Trinocular Head inclined 30 rotatable at 360 and diopter adjustment ring on ocular tube (+/-5) with inter pupillary distance from 48mm to 75mm.
Mechanical Body
Features :
Stage: Fixed square stage size 120 x 120 mm. with co-axial graduated Mechanical stage for X & Y movements up to 55mm to 75mm.
Objective 10x 45x 100x
Eye piece 10x wf.
Additional Information:
Payment Terms : T/T
Delivery Time : Ready stock
Observation Head: Siedentopf Trinocular Head inclined 30 rotatable at 360 and diopter adjustment ring on ocular tube (+/-5)with interpupillary distance from 48mm to 75mm.
Mechanical Body
Features:
Observation Head: Sliding Binocular Head inclined 30 rotatable at 360 and diopter adjustment ring on ocular tube (+/-5) with interpupillary distance from 48mm to 75mm.
Mechanical Body
USB Digital Camera: 5.0 Megapixel Color CMOS sensor, Size 1/2“, Pixel size 3.2x3.2 micron Resolution 2048x1536, PC interface, 30 bit color depth, exposure time 1 Microsecond to 2 seconds. High Image Transmission convenient to use any standard Microscope. Digital Camera can change image into Digital signal & send it to your P.C.
USB Digital Camera
5.0 Megapixel Color CMOS sensor, Size 1/2“, Pixel size 2.2x2.2 micron Resolution 2592x1944 PC interface, 30 bit color depth, exposure time 1 Microsecond to 2 seconds. High Image Transmission convenient to use any standard Microscope. Digital Camera can change image into Digital signal & send it to your P.C.
Mechanical Stage
Illumination
Magnification Range
7 to 45x (Standard) can be increased to 180x depending on different combination of eye piece & Auxiliary used.
Mechanical Body
Observation Head
Seidentopf Trinocular Head inclined 30 rotatable at 360 and diopter adjustment ring on ocular tube (+/-5) with interpupillary distance from 48mm to 75mm.
Mechanical Body
Epi - Fluorescence Illuminator
Ultra Hi - Voltage spherical HBO mercury Burner 100w, Mercury burner power supply unit. Input 220v AC 50hz. Protection Barrier to resist the ultra violet light. All electric systems are as per CE standards.
Observation Head: Seidentopf Trinocular Head inclined 30 rotatable at 360 and diopter adjustment ring on ocular tube (+/-5) with interpupillary distance from 48mm to 75mm.
Mechanical Body
Trinocular Observation Head
Mechanical stage
Excitation Filters
V Excitation (400 – 410nm) Light Source: Transmitted Kohler light source: 3W LED or 12V / 100W tungsten halogen bulb. Epi - Fluorescence light source: 100W high pressure mercury lamp.
Observation Head: Seidentopf Trinocular Head inclined 30 rotatable at 360 and diopter adjustment ring on ocular tube (+/-5) with interpupillary distance from 48mm to 75mm.
Mechanical Body
Illumination
Built in base transmitted from 6V – 20W Halogen lamp or LED 3W and incident from two lamps with variable separate control on front panel.
Trinocular Observation Head:
Mechanical Stage:
Illumination System
Epi – Fluorescence Illuminator : Ultra Hi – Voltage spherical HBO mercury Burner 100w, Mercury burner power supply unit. Input 220v AC 50hz. Protection Barrier to resist the ultra violet light. All-electric systems are as per CE standards.
Mechanical Stage: Mechanical stage size 150mm x 140mm. Moving range 80mm x 50mm. The mechanical stage has low positioned co-axial controls on ball bearing guide ways.
Focussing System:
Magnification Range
7 to 45x (Standard) can be increased to 180x depending on different combination of eye piece & Auxiliary used.
USB Digital Camera
5.0 Megapixel Color CMOS sensor, Size 1/2“, Pixel size 3.2x3.2 micron Resolution 2048x1536, PC interface, 30 bit color depth, exposure time 1 Microsecond to 2 seconds. High Image Transmission convenient to use any standard Microscope. Digital Camera can change image into Digital signal & send it to your P.C.
USB Digital Camera
5.0 Megapixel Color CMOS sensor, Size 1/2“, Pixel size 2.2x2.2 micron Resolution 2592x1944, PC interface, 30 bit color depth, exposure time 1 Microsecond to 2 seconds. High Image Transmission convenient to use any standard Microscope. Digital Camera can change image into Digital signal & send it to your P.C.
Observation Head: Seidentopf Trinocular Head inclined 30 rotatable at 360 and diopter adjustment ring on ocular tube (+/-5) with inter pupillary distance from 48mm to 75mm.
Objectives: (Anti fungus Coated). CCIS Plan Achromatic 2x, CCIS Plan Achromatic 4x, CCIS Plan Achromatic 10x, CCIS Plan Achromatic 20x (S.L.), CCIS Plan Achromatic 40xl (S.L.), CCIS Plan Achromatic 100x Oil (S.L.),
Mechanical Body
Illumination
Incident light through Epi – illuminator with field aperture diaphragm and filter slot. Continuously variable luminosity control though built in electronic transformer.
Illumination
Built in base transmitted from 6V – 20W Halogen lamp or LED 3W and incident from two lamps with variable separate control on front panel.
Digital Read Out System (DRO)
Condenser: Sub stage Abbe filter holder N.A. 1.25 condenser with Iris diaphragm and swing out filter holder focusable by rack & pinion.
Incident Illuminator: Reflected light incident illuminator consist of polarizing unit slot for filter & 6V – 20W Intensity control transformer.
Analyzer: Equipped with a Bertrand lens, which can be swung in and out of the microscope tube for conoscopy observation. Compensator slot at 45 accommodating 1/4 & 1/2 wave length retarding plates.
Focusing: Focusable condenser with rack & pinion is fitted under the stage and fine focusing knobs placed separately in a convenient position.
Condenser: Substage Abbe filter holder N.A. 1.25 condenser with Iris diaphragm and swing out filter holder focusable by rack & pinion.
Incident Illuminator: Reflected light incident illuminator consist of polarizing unit slot for filter & 6V – 20W Intensity control transformer.
Analyzer: Equipped with a Bertrand lens, which can be swung in and out of the microscope tube for conoscopy observation. Compensator slot at 45 accommodating 1/4 & 1/2 wavelength retarding plates.
Mechanical Stage
Illumination: Incident and transmitted light systems LED lamps. Both Lights are regulated with power supply and has separate brightness controls.
Stage
Compact ball bearing center able rotating stage 140mm diameter , graduated with vernier , lock and two specimen clips.
Condenser
Sub stage Abbe filter holder N.A. 1.25 condenser with Iris diaphragm and swing out filter holder focusable by rack & pinion.
Analyzer
Equipped with a Bertrand lens, which can be swung in and out of the microscope tube for conoscopy observation. Compensator slot at 45 accommodating 1/4 & 1/2 wave length retarding plates.
Additional Information:
Payment Terms : T/T
Delivery Time : 35 days
Trinocular Observation Head
Objectives
Mechanical Body
Additional Information:
Delivery Time : 1 to 15 days
Trinocular Observation Head
Mechanical Stage :
Light Source
Observation
Mechanical Body
Illumination System
