Re-atlantis Enterprise Co. Ltd

Taiwan

We are offering digital pressure gauge dpg-k4.0. Display 4 digits lcd display, size 52 x 28 mm, back light mode units selectable mpa, psi, kg/cm2 (mpa standard) proof pressure 150% of full range accuracy 1.0% f.s. And 0.5 f.s., 0.25 f.s. Also available measured media water and gas 80 case 4 inch ( 100 mm ), plastic and ss material connection 1/4pt or npt male thread, bottom, ss 304other sizes available upon request, ss 316 also available supply voltage standarddc 4.5 v battery (1.5vx3) zero offset display can be manually zeroed when it is not zero offset due to temp. Effect power saving backlight power off after 10 sec. temperature operation -10+70 working ranges 0-0.6mpa/0-1.0mpa/0-1.6mpa/0-3.0mpa, 0-40 mpa, 0-60 mpa, 0-100mpa available upon request

We are offering gg2000 differential pressure gauge. Indicate positive, negative and differential pressures accurate within 2% applicationsair, non-inflammable gas (optionnatural gas)

product specifications:*application: for corrosive or non corosive gas and liquid aggressive media which are not highly viscous and would crystallize. particularly used in chemical, petrochemical and food industry, biochemistry and any rush industries. for measuring points subject to vibrations and high dynamic pressure load. *specification: 1.case & ring:stainless steel 304. 2.window: acrylic(dial size:1-1/2"3") safety glass(dial size:4"6") 3.element & movement:stainless steel. 4.bourdon tube system:stainless steel 316 5.socket: stainless steel 6.pointer: aluminum alloy, black painted 7.connection: 1/8", 1/4", 3/8", 1/2", 3/4"(bsp(pf)/bspt(pt)/npt) 8.connection type: a type(botton connection), b type(botton connection with back flange for wall mounting) ad type(back connection without flange) bd type(back connection with front flange) ud type(back connection with clamp(w/o flange) for panel mounting) 9.dial size: 1.5", 2", 2.5", 3", 4", 6" 10.ambient temperature:-2060c 11.measured medium temperature: tmax.+100c 12.accuracy: (+/-)1.6% full scale(dial size:1.5"2.5") (+/-)1.0% full scale(dial size:3"6") 13.pressure range: depand on your order 14.type: standard pressure gauge;vacuum pressure gauge & compound pressure gauge *options: safety glass window for dial size: 2.5"&3" blow-out disk by back for dial size: 4" adjustable pointer available for dial size: 4"&6" special male or female thread connections measured medium tmax.+180c glycerine or silicone filling cleanness for oxygen service red pointer indicating max. pressure on dial

We are offering pressure gaugedial diameter:2.5 housing: pp, all-in-one, anti-impact black color for viton diaphragmmeasuring principle: bourdon tube brass diaphragm viton, suitable for acid chemical mediaconnection: female thread 1/2 pt(bspt) accuracy: 1.5% f.s. ranges:standard range 0 / 40 / 7 kg/cm2

We are offering 3" digital lcd pressure gauge. Accuracy 0.25% f.s. Display: 4 digits lcd display, size 30 x 14.5 mm, back light mode available units selectable: psi, bar, kg/cm2 range: 0-5000psi

product specifications:1. dial: 1.5". 2. connection: brass. 3. use no oil 4. for gas use

We are offering Electronic Contact Pressure Gauge product specifications:(diaphragm type) #ec series-ds type(ds-100) *applications: for aggressive gaseous and liquid media.can also be used in aggressive environments. with open connecting flange also suitable for viscous and polluted media. designed for measuring points which are subject to vibrations and high dynamic pressure loads. *specifications: 1.dial diameter: 4"(100mm), 6"(150mm). 2.case&bayonet bezel: stainless steel 304 (blow-out protection by back is optional) 3.lens: acrylic(glass are optional) 4.bourdon tube system: brass(stainless steel is optional) 5.element & movement: brass(stainless steel is optional) 6.upper flange materials: ss304, ss316, pp, pvc, ptfe, pvdf or others 7.lower flange materials: ss304, ss316, pp, pvc, ptfe, pvdf or others 8.diaphragm material: ss316l, ptfe(teflon), hastelloy c, monel or others 9.thread process connection: 1/4", 3/8", 1/2", 3/4", 1"pt(bspt)/pf(bsp)/npt (other connections available upon request) 10.temperature: ambient=>-2060c;process=>-2080c (for higher temperature available upon request) 11.accuracy: (+/-)3%-2%-3% of full scale 12.range: -76cmhg/0 to 0/60kg/cm2. (other scale units available) 13.wash type(optional): upper and lower housing removable;housing with wash hole 14.accessorized with capillary(remote mounting) available 15.contact mode: magnetic contacts or sliding contacts 16.wiring type: with open wire or with junction box 17.contact setting: removable key 18.contact arrangement: normally open or normally close single contact-1a or 1b double contacts-1a1b or 2a or 2b 19.waterproof or liquid filled available upon request #ec series-a/b/bd type *application: the electrical warning contacts are designed for opening or closing electric and pneumatic circuits in relation to the position of the pointer on the instrument. depends on the material, the gauge can be used for corrosive or non corrosive gas and liquid media not highly viscous and not crystallizing. *specifications: 1.connection type: bottom(ec-a) or back(ec-bd) 2.dial diameter: 4"(100mm) or 6"(150mm) 3.case&ring: stainless steel 304 4.windows: acrylic 5.wetted parts: stainless steel 316(for corrosive media) brass(for non corrosive media) 6.standard thread: 3/8", 1/2" bspt(pt)/npt/bsp(pf) 7.max.process temperature:60c (for 180c is available upon request) 8.range: -1/0.0/1000kg/cm2(other scale units are available) 9.accuracy: (+/-)1.5% full scale ((+/-)1.0% full scale available upon request) 10.contact mode: magnetic contacts or sliding contacts 11.wiring type: with open wire or with junction box 12.contact setting: removable key 13.contact arrangement: normally open or normally close high and low contacts(1a1b) high or low contacts(1a or 1b) double high or double low contacts(2a or 2b) 14.waterproof or liquid filled available upon request

product specifications:1. type: pressure gauge, vacuum pressure gauge, compound pressure gauge. 2. case material: black painted steel, stainless steel & plastic. 3. connection type: . a type (bottom) . ad type (center back) . ud type (u clamp) . bd type (center back with flange) . is only for 2" and 2.5" 4. dial dia.: 1.5", 2", 2.5", 3.5", 4.5" 5. connection size: 1/8"pt, 1/4"pt, 1/8"npt, 1/4"npt. 6. ring style: . snap-in lens w/o friction ring . snap-in lens with friction ring 7. scale range: . 30'hg, 76cmhg, -100kpa, 30'hg-760mmhg . 30'hg-1, 760mmhg-1kg/cm2, 30'hg-15psi, . 30'hg-30psi, 30'hg-60psi, 30'hg-100psi, . 30'hg-160psi, 30'hg-300psi 8. different from the traditional bourdon tube or gears. 9. diaphragm gauges-simple structure and accuracy, meets ansi standard b40. 1-1974 grade b requirement which error does not exceed 2% of span at any point between 25% and 75% of span. 10. for industrial machines for pump ideal for: various industrial pressure gauges i.e. frozen gauge, gas gauge, water pressure gauge, vacuum gauges, compound gauges and compression tester, etc, it also ideal for any tire pressure gauges and ball pressure gauges.

We offer Digital Pressure Gauge model/item no.: dpg-m2.5 series country of origin: taiwan brand: atlantisproduct specifications:1. features: . accuracy better than 1% f.s. . bottom, rear and panel installation available. . user can re-calibrated the gauge. . four units selectable . dual-polarity value display (only available for range above 100psi) . battery life indication . auto-off time selectable . always on & auto-off alternative. 2. functions: . display: 4 digits lcd display, size 46 x 15 mm . units selectable: pressure gauge: psi, bar, kg/cm2, kpa vacuum gauge: mbar, mmhg, inhg, kpa . proof pressure: 200% f.s. (vac 300 psi) 150% f.s. (1000 5000 psi) . accuracy: 0.3% f.s. 1 digit @ 25, thermal error max. 1% f.s. . measured media: brass connection type: extremely clean & non- corrosive gases only diaphragm type: all kinds of media according to diaphragm material . case size: 67 mm dia. (77 mm dia. with rubber shroud), plastic material (rubber shroud protection only for brass & bottom connection) panel installation type: flange dia. 80 mm, screw dia. 3.6 mm . connection: brass connection type: 1/4" pt or npt male thread, electroplate diaphragm type: standard 1/4" pt or npt male thread, ss304 (other size and material available) . supply voltage: standard: dc 9v battery (for more than 8000 times, each time 180 sec.) option: external dc 12v or dc 24v or ac 110v or ac 220v . zero offset: display can be zeroed when it is not zero offset due to temp. effect . peak hold mode: continuous reading & peak hold display alternative . power saving: auto-off time setting from 5 to 1200 sec. (factory setting 180 sec.) . temperature: operation: 0 45oc/32 115of storage: -10 75oc/15 165of
