Our Products
Our offered Product range includes 1/2 Inch AODD Aluminium Pump, 1.5 Inch AODD Aluminium Pump, 2 Inch AODD Aluminium Pump, 1/2 Inch AODD Polypropylene Pump and 1 Inch AODD Polypropylene Pump.
Pump M.O.C
| Wetted Parts | Aluminium |
|---|---|
| Lock nut | Aluminium |
| Holding Plate | MS Powder Coated |
| Air Valve | Polypropylene |
| Diaphragm | PTFE,Neoprene,Sentoprene |
| Valve Ball | PTFE |
| Valve Seat | Aluminium |
| O Ring | PTFE |
Tested Performance
| Suction Lift Dry | 1.5 m |
|---|---|
| Suction Lift Wet | 2 m |
| Maximum Flow Rate | 35 lpm |
| Maximum Size Solids | 2 mm |
| Maximum Air Pressure | 8.05 bar |
| Maximum Head | 10 m |
| Displacement Per Cycle | 0.10 Leter |
| Temprechure | -29'C to 105 C' |
| Noice Level | 75 db (70 PSI) |
Pump M.O.C
| Wetted Parts | Aluminium |
|---|---|
| Lock nut | Aluminium |
| Holding Plate | MS Powder Coated |
| Air Valve | Polypropylene |
| Diaphragm | PTFE,Neoprene,Sentoprene |
| Valve Ball | PTFE |
| Valve Seat | Aluminium |
| O Ring | PTFE |
Tested Performance
| Suction Lift Dry | 4 m |
|---|---|
| Suction Lift Wet | 5 m |
| Maximum Flow Rate | 210 lpm |
| Maximum Size Solids | 4.5 mm |
| Maximum Air Pressure | 8.05 bar |
| Maximum Head | 40 m |
| Displacement Per Cycle | 1.2 Leter |
| Temprechure | -29'C to 105 C' |
| Noice Level | 82 db (70 PSI) |
Pump M.O.C
| Wetted Parts | Aluminium |
|---|---|
| Lock nut | Aluminium |
| Holding Plate | MS Powder Coated |
| Air Valve | Polypropylene |
| Diaphragm | PTFE,Neoprene,Sentoprene |
| Valve Ball | PTFE |
| Valve Seat | Aluminium |
| O Ring | PTFE |
Tested Performance
| Suction Lift Dry | 5 m |
|---|---|
| Suction Lift Wet | 6 m |
| Maximum Flow Rate | 550 LPM |
| Maximum Size Solids | 6 mm |
| Maximum Air Pressure | 8.05 bar |
| Maximum Head | 60 m |
| Displacement Per Cycle | 1.5 Leter |
| Temprechure | -29'C to 105 C' |
| Noice Level | 75 db (70 PSI) |
Pump M.O.C
| Wetted Parts | Polypropylene |
|---|---|
| Lock nut | Polypropylene |
| Holding Plate | MS Powder Coated |
| Air Valve | Polypropylene |
| Diaphragm | PTFE,Neoprene,Sentoprene |
| Valve Ball | PTFE |
| Valve Seat | Polypropylene |
| O Ring | PTFE |
Tested Performance
| Suction Lift Dry | 4 m |
|---|---|
| Suction Lift Wet | 5 m |
| Maximum Flow Rate | 210 lpm |
| Maximum Size Solids | 4.5 mm |
| Maximum Air Pressure | 8.05 bar |
| Maximum Head | 40 m |
| Displacement Per Cycle | 1.2 Leter |
| Temprechure | -29'C to 105 C' |
| Noice Level | 82 db (70 PSI) |
Pump M.O.C
| Wetted Parts | Polypropylene |
|---|---|
| Lock nut | Polypropylene |
| Holding Plate | MS Powder Coated |
| Air Valve | Polypropylene |
| Diaphragm | PTFE,Neoprene,Sentoprene |
| Valve Ball | PTFE |
| Valve Seat | Polypropylene |
| O Ring | PTFE |
Tested Performance
| Suction Lift Dry | 4 m |
|---|---|
| Suction Lift Wet | 5 m |
| Maximum Flow Rate | 210 lpm |
| Maximum Size Solids | 4.5 mm |
| Maximum Air Pressure | 8.05 bar |
| Maximum Head | 40 m |
| Displacement Per Cycle | 1.2 Leter |
| Temprechure | -29'C to 105 C' |
| Noice Level | 82 db (70 PSI) |
Pump M.O.C
| Wetted Parts | Polypropylene |
|---|---|
| Lock nut | Polypropylene |
| Holding Plate | MS Powder Coated |
| Air Valve | Polypropylene |
| Diaphragm | PTFE,Neoprene,Sentoprene |
| Valve Ball | PTFE |
| Valve Seat | Polypropylene |
| O Ring | PTFE |
Tested Performance
| Suction Lift Dry | 4 m |
|---|---|
| Suction Lift Wet | 5 m |
| Maximum Flow Rate | 210 lpm |
| Maximum Size Solids | 4.5 mm |
| Maximum Air Pressure | 8.05 bar |
| Maximum Head | 40 m |
| Displacement Per Cycle | 1.2 Leter |
| Temprechure | -29'C to 105 C' |
| Noice Level | 82 db (70 PSI) |
Rightway make AODD Polypropylene series is Very affordable for chemical application. Is Very low price and light weight design.
Pump M.O.C
| Wetted Parts | Polypropylene |
|---|---|
| Lock nut | Polypropylene |
| Holding Plate | MS Powder Coated |
| Air Valve | Polypropylene |
| Diaphragm | PTFE,Neoprene,Sentoprene |
| Valve Ball | PTFE |
| Valve Seat | Polypropylene |
| O Ring | PTFE |
Tested Performance
| Suction Lift Dry | 5 m |
|---|---|
| Suction Lift Wet | 6 m |
| Maximum Flow Rate | 550 LPM |
| Maximum Size Solids | 6 mm |
| Maximum Air Pressure | 8.05 bar |
| Maximum Head | 60 m |
| Displacement Per Cycle | 1.5 Leter |
| Temprechure | -29'C to 105 C' |
| Noice Level | 75 db (70 PSI) |
Rightway make PVDF AODD PUMP is most efficient and durable product for Industrial Applications
Pump M.O.C
| Wetted Parts | PVDF |
|---|---|
| Lock nut | PVDF |
| Holding Plate | MS Powder Coated |
| Air Valve | Polypropylene |
| Diaphragm | PTFE,Neoprene,Sentoprene |
| Valve Ball | PTFE |
| Valve Seat | PVDF |
| O Ring | PTFE |
Tested Performance
| Suction Lift Dry | 4 m |
|---|---|
| Suction Lift Wet | 5 m |
| Maximum Flow Rate | 210 lpm |
| Maximum Size Solids | 4.5 mm |
| Maximum Air Pressure | 8.05 bar |
| Maximum Head | 40 m |
| Displacement Per Cycle | 1.2 Leter |
| Temprechure | -29'C to 105 C' |
| Noice Level | 82 db (70 PSI) |
Rightway make PVDF AODD PUMP use in most highly Temprature application and High corrosive resistant Application.
Rightway make AODD PUMP is most efficient and highly corrosive resistant. It's made from Die cast S.s and Diaphragm qaulity is very expensive and long life.
Pump M.O.C
| Wetted Parts | S.S 316 |
|---|---|
| Lock nut | S.S 316 |
| Holding Plate | MS Powder Coated |
| Air Valve | Polypropylene |
| Diaphragm | PTFE,Neoprene,Sentoprene |
| Valve Ball | PTFE |
| Valve Seat | S.S 316 |
| O Ring | PTFE |
Tested Performance
| Suction Lift Dry | 2 m |
|---|---|
| Suction Lift Wet | 3 m |
| Maximum Flow Rate | 120 lpm |
| Maximum Size Solids | 3 mm |
| Maximum Air Pressure | 8.05 bar |
| Maximum Head | 30 m |
| Displacement Per Cycle | 0.5 Leter |
| Temprechure | -29'C to 105 C' |
| Noice Level | 78 db (70 PSI) |
Pump M.O.C
| Wetted Parts | S.S 316 |
|---|---|
| Lock nut | S.S 316 |
| Holding Plate | MS Powder Coated |
| Air Valve | Polypropylene |
| Diaphragm | PTFE,Neoprene,Sentoprene |
| Valve Ball | PTFE |
| Valve Seat | S.S 316 |
| O Ring | PTFE |
Tested Performance
| Suction Lift Dry | 5 m |
|---|---|
| Suction Lift Wet | 6 m |
| Maximum Flow Rate | 550 LPM |
| Maximum Size Solids | 6 mm |
| Maximum Air Pressure | 8.05 bar |
| Maximum Head | 60 m |
| Displacement Per Cycle | 1.5 Leter |
| Temprechure | -29'C to 105 C' |
| Noice Level | 75 db (70 PSI) |
Rightway make AODD PUMP is highly resistant From acid and solvent. Very primium qaulity diaphragm use and smooth Operated design.
Additional Information:
Delivery Time : Ready Stock
Model- RWP300PTT
Inlet/outlet:- 1"
PTFE Diaphragm
Additional Information:
Payment Terms : L/C, D/A, D/P, T/T, Western Union,
Packaging Details : Cartage Box
Delivery Time : 2 days
Pump M.O.C
| Wetted Parts | ALUMINIUM |
|---|---|
| Lock nut | ALUMINIUM |
| Holding Plate | MS Powder Coated |
| Air Valve | Polypropylene |
| Diaphragm | PTFE,Neoprene,Sentoprene |
| Valve Ball | PTFE |
| Valve Seat | ALUMINIUM |
| O Ring | PTFE |
Tested Performance
| Suction Lift Dry | 2 m |
|---|---|
| Suction Lift Wet | 3 m |
| Maximum Flow Rate | 120 lpm |
| Maximum Size Solids | 3 mm |
| Maximum Air Pressure | 8.05 bar |
| Maximum Head | 30 m |
| Displacement Per Cycle | 0.5 Leter |
| Temprechure | -29'C to 105 C' |
| Noice Level | 78 db (70 PSI) |
Rightway make AODD PUMP is most efficient and important Pump for Most Industrial Applications and most efficient application.
Pump M.O.C
| Wetted Parts | S.S 316 |
|---|---|
| Lock nut | S.S 316 |
| Holding Plate | MS Powder Coated |
| Air Valve | Polypropylene |
| Diaphragm | PTFE,Neoprene,Sentoprene |
| Valve Ball | PTFE |
| Valve Seat | S.S 316 |
| O Ring | PTFE |
Tested Performance
| Suction Lift Dry | 1.5 m |
|---|---|
| Suction Lift Wet | 2 m |
| Maximum Flow Rate | 35 lpm |
| Maximum Size Solids | 2 mm |
| Maximum Air Pressure | 8.05 bar |
| Maximum Head | 10 m |
| Displacement Per Cycle | 0.10 Leter |
| Temprechure | -29'C to 105 C' |
| Noice Level | 75 db (70 PSI) |
