Lets You Have It Your Way

PZ Pilot Plus printing system is a perfect fit for manufacturers and contract packagers who are looking to print high-quality bar codes, clean and clear logos and razor-sharp text byautomatic Batch Coding Machine. Users select between systems designed to print on porous or non-porous surfaces, providing the ultimate level of flexibility and versatility that customers have come to expect from Squid Ink.

Printing That Is Simple and Versatile

Squid Inks innovative PZ Pilot Plus offers a simple alternative for your case coding and product marking applications. PZ Pilot Plus is capable of printing up to 8 lines of print, for a total print height of up to 1.4, on virtually any porous or non-porous substrate. PZ Pilot Plus requires minimal setup and is available with a portable, easily adjustable stand, or with mounting brackets that allow you to easily bolt it right to a conveyor. Best of all, the handheld input device and software is designed for people who run packaging lines, not computers, making everyone involved a smooth operator

Help Your Product Look Its Best

Using industry proven shared-wall technology, the PZ Pilot Plus offers better print quality than competitive high-resolution printing systems. With 256 addressable jets, PZ Pilot Plus boasts 180 dpi print resolution. The result is a system that produces razor-sharp text, scannable bar codes, and the cleanest logos and graphics on the market today.

Your Low Maintenance Alternative

If maintenance issues are consistently slowing down your production line and are costing you critical time and money, the PZ Pilot Plus is the flexible and reliable alternative youve been looking for. PZ Pilot Plus is a fully modular system that allows users to make a fix in less than five minutes, therefore eliminating the need for costly service calls or complete system repair. For most applications, daily maintenance is reduced to a one-time, 30-second printhead purge that is quick and easy to do.

Industrial-Strength Operation

Tired of inconsistent print on your cases? Unlike competitive high-resolution printing systems, PZ Pilot Plus printhead technology is not susceptible to vibration and will not easily lose its prime. In addition, PZ Pilot Plus compact printheads dont require a lot of space in crowded package printing environments. You can be confident that PZ Pilot Plus rugged design will withstand the most abusive industrial environments.

Affordable Ink Jet Printing

If you have wanted to start printing logos or highresolution bar codes on your products, but felt your budget restricted you from doing so, the PZ Pilot Plus offers a new level of economy. PZ Pilot Plus allows users to eliminate the need for pre-printed cases or expensive labeling equipment by printing specific product information directly onto the substrate. In addition, PZ Pilot Plus utilizes ink manufactured directly by Squid Ink, eliminating the costs caused by multiple layers of distribution. Any way you look at it, Squid Inks PZ Pilot Plus provides users with an affordable solution to meet their ink jet printing needs.

PZ Pilot Plus Printing System Components

Controller system with detachable ink reservoir128 or 256 printhead with data cable and ink linePhotocell product sensor and photocell mounting bracketIndustrial-strength handheld input device

High Quality Print on Any Type Of Product

Squid Inks SQ/2 ink jet printing system allows manufacturers to print high quality dot-matrix characters on a variety of products at a cost-effective price. In fact, the SQ/2 offers the lowest price per printed character in the industry today. Users can choose between two models: a water-based system for printing on porous surfaces like corrugated cartons, paper or wood, or a solvent-based system for printing on non-porous products like plastics, stretch wraps, metals, glass or more.

User Flexibility

SQ/2large characterink jet printerusers also have the option of choosing from several printhead configurations. Three different print sizes are available: 3/4, 1/2 or 3/8 character height. All printheads are capable of printing both a 7 x 5 and 5 x 5 character matrix, offering print sizes ranging from 1/4 to 3/4 in height. Users also have the flexibility to run one or two printheads at any time. All of these components are field-installable for future upgrade to meet your applications changing requirements.

User-Friendly System

The SQ/2 is designed for simple day to day operation. SQ/2s state of the art input device provides quick and easy message programming and retrieval for up to 64 messages. Resident software in the input device walks the user through a series of prompts to program and save each message for printing ondemand. The system can also be programmed and maintained with a PC through a standard RS-232 port.

Innovative Technology And Proven Reliability

Patented micro-channeling technology eliminates the need for a costly array of fluid valves. Squid Ink uses its own proven plunger technology and distributes ink through a series of channels, keeping production and maintenance costs to a minimum, especially when compared to the costly valve technology common in most ink jet printers today.

No More Service Calls

The SQ/2 was engineered inside and out for industrial-strength operation. Heavy-duty gauge coated steel cabinetry ensures continuous operation in harsh, real world environments. If the printer does fail, a fix can be completed in less than five minutes. Quick and easy-to-install replacement printheads, PC cards and air pump modules minimize downtime and eliminate costly service calls. Best of all, the water-based SQ/2 utilizes Squid Inks patented SQ-60 no-clog ink, allowing users to leave the ink in their printheads for an extended period of time without flushing or cleaning, making it the most cost-effective, low maintenance ink jet printing system available today.

SQ/2 Printing System Components

Controller cabinet and ink delivery systemOne or two printhead(s) and printhead mounting bracket(s)Printhead data cable(s) and ink line(s)Photocell product sensor and photocell mounting bracketIndustrial-strength hand-held input device

SQ/2 Printing System Specifications
Printer TypeLarge character ink jet printer
Character Height.75 (1.9cm) in 7 x 5 matrix; .5 (1.3cm) in 5 x 5 matrix, or.5 (1.3cm) in 7 x 5 matrix; .375 (1cm) in 5 x 5 matrix, or.375 (1cm) in 7 x 5 matrix; .25 (.6cm) in 5 x 5 matrix
Character Set61 character ASCII set
Print Speed20 feet/minute (6.1m/minute) to 200 feet/minute (61m/minute) line speed; optional extended characterwidth firmware allows for print speeds slower than 20 feet/minute
Message Length60 characters per message; 64 memory locations
CommunicationRS-232C, 9600 baud, 8 data bits, 1 start, 1 stop, Asynch
Software Features24-hour clock, Julian date, counter, lot counter
Operating FeaturesDot size, print delay, character width, photocell on/off, invert print, reverse print, purge routine
SQ/2 Exchange ProgramEliminates the need for costly service calls and minimizes downtime; troubled printheads andcomponents can be replaced in less than 5 minutes
Controller Dimensions12 (31cm) H x 12 (31cm) W x 5.25 (13cm) D
Controller Weight10.5 lbs. (4.8kg)
Printhead Dimensions3 (7.6cm) H x 1.6 (4.1cm) W x 7 (17.8cm) L; dimensions are for the printhead only an additional3 (7.6cm) is needed for the ink line and cabling which extends from the back of the printhead
Product SensorDiffuse beam photocell (24v) or hardware sinking signal
Electrical Requirements110/120 VAC, 50/60Hz, 1.6 amp
Cabinet ConstructionIndustrial gauge coated steel
Operating Environment38F (3C) to 122F (50C)
Substrate CapabilitiesPorous or Non-Porous surfaces
Air RequirementsNo external air needed
Ink CapabilitiesPorous: Squid Ink SQ-60 no-clog inkNon-Porous: Several Squid Ink solvent based fluids to meet adhesion and dry time needs
Ink Volume.5 (1.89 liters) gallon bottle standard; available upgrade (water-base ink only) to 5.0 gallon pail(18.93 liters)

SQ/2 Optional Accessories
Spare Parts KitIncludes spare printhead, card cage and PC board pack, air pump module, data cable and master cap
Starter KitIncludes ink, cleaner for flushing the system, spray bottle for cleaner, hand cleaner and lint-freewipes for the printhead
5-Gallon Pail UpgradeUpgrades ink supply to 5.0 gallons (water-base ink only)
PC SoftwareCommunications software for PC integration
Repeat Print FirmwareAllows continuous printing of messages
Extended CharacterAllows for print speeds slower than 20 feet/minute
Width Firmware
Rollaway StandProvides mount for the SQ/2 controller, designed with caster wheels for transportation within plant

The AutoPilot Advantage

Squid Ink introduces the AutoPilot printing system, a feature-rich hi-resolution printing system available at an entry level price. Squid Inks AutoPilot printing system offers several advantages over competitive HP or Lexmark - based printing systems. With the AutoPilot, users can expect 30% larger print, the ability to upgrade to a 2nd printhead, message programming via touchscreen user panel, the ability to print barcodes with standard systems, the ability to print on a variety of porous and non-porous surfaces, and much more.

Designed To Meet Your Demands

Squid Inks AutoPilot printing system will print up to .7" of hi-resolution characters, razor-sharp text, scannable bar codes, and great looking logos. Users can run up to two printheads from a single touchscreen controller to maximize efficiency and print on opposite sides of a case if needed. The AutoPilot is capable of running oil-based or solvent-based inks to print on a variety of substrates. Best of all, AutoPilots 180 dpi print resolution meets your application needs for quality coding and marking.

Printing Made Easy

The AutoPilots touchscreen controller features ATM-simple, easy-to-follow user prompts to program, save and print messages. Message programming or editing can be done right at the production line, or in the convenience of an office, and uploaded to the AutoPilot via USB or ethernet. In addition, the built-in software automatically calculates ink usage for each message so you can modify your messages and control your consumable costs.

Maximize Your Uptime

The AutoPilot is designed to meet the harsh demands of your application. UL, CE, and CSA certified, the AutoPilot features a durable touchscreen, industrial strength resin printer construction, and allows the AutoPilot to operate in the most extreme factory environments. In addition, Squid Inks PZ-1000 ink for porous substrates offers low-maintenance performance, eliminating the need for auto-priming functions and offering better ink utilization than competitive systems. You can be confident that AutoPilots rugged design will withstand the most abusive industrial environments while providing superior quality print.

Affordable Ink Jet Coding

Whether you are a seasoned pro, or if you have wanted to start printing high quality codes on your products, but felt your budget restricted you from doing so, the AutoPilot offers a new level of economy. As the newest addition to Squid Inks growing family of marking and coding systems, the AutoPilot gives users more choices for their coding applications. In addition, the AutoPilot utilizes ink manufactured directly by Squid Ink, eliminating the high ink costs of HP or Lexmark systems. Any way you look at it, Squid Inks AutoPilot provides users with an affordable solution to meet their ink jet coding needs.

The Right Solution

Rugged design likeCarton Batch Coding Machine. Low maintenance operation.Online carton printing machinehave user friendly software. Low cost of ownership. Your benefits go on and on.

When it comes toindustrial ink jet printing, rely on Squid Ink to provide the right solution for your coding and marking needs.

AutoPilot Printing System ComponentsUp to two .7 printer(s) with data cable(s)Touchscreen controller for message creationMounting bracket(s) for printer(s)Swivel arm mounting bracket for touchscreen controller
AutoPilot Printing System Specifications
Print TechnologyPiezo impulse printhead technology
Maximum Print Height.7 (1.8 cm) per printhead
Vertical Print Resolution180 dpi capable of printing razor-sharp graphics, small character text, and scannable bar codes
Horizontal Print Resolution180 dpi
Print SpeedUp to 135 feet/min. (41 m/min.) @ 180 dpi
Time & DateInternal real time clock with battery back-up
Product SensorBuilt in product sensors, optional external photocell
Communication InterfaceTwo USB host and one ethernet input
Touchscreen12.1 (30 cm) full color touchscreen display
Ink System200ml ink cartridge
Low Ink IndicatorWarning messages alert user on the printer and touchscreen, LED light beacon optional
Substrate CapabilitiesPorous or Non-Porous surfaces
Electrical Requirements90 - 264 VAC, 50/60 Hz
Operating Environment34F - 104F (1 - 40C)
Storage Environment0F - 140F (-18 - 60C)
Agency CertificationsUL, CE, and CSA certified

AutoPilot Software Specifications
Time & DateMultiple formats including: 3-letter, 2-digit, 1-letter month; 3-letter or 2-digit day; 2-digit hour; 2-digitminute; 2-digit second; 4-digit or 2-digit year; 2-digit week; 24-hour clock or 12-hour clock with AMor PM; Julian date
Item NumberingOne counter plus daily counter with ImageMaster Touch; four counters plus daily counter withImageMaster TouchXF
Shift CodesFour programmable shift codes with automatic rollover
Bar CodesCode 39, Interleaved 2 of 5, UPC-A, EAN-8, EAN-13, Code 128, UCC-128, SCC 14, SSCC-18, Postnet, MSI, DataMatrix and PDF417 bar codes standard
FontsOn the fly generation of Truetype fonts
LogosRequires ImageMaster TouchXF upgrade
Printing FeaturesReverse, invert, inverse, rotate, repeat, variable print density
Auto SetupBuilt in product sensors automatically determine product speed and direction based on product length
Message LengthLimited by substrate length up to 120
Number of Messages1GB storage space will store approximately 1000+ messages
Ink UsageAutomatically calculated for each message and displayed on touchscreen
User PromptsRequires ImageMaster TouchXF upgrade
Database ConnectivityRequires ImageMaster TouchXF upgrade, allows printing from variable fields
Software UtilitiesPC ImageMaster software
LanguagesUser selectable between English, Spanish, and Chinese

AutoPilot Optional Accessories
ImageMaster TouchXF SoftwareIncreases software capabilities to run two printheads, print logos, ability to use auto data anddatabase functions
EncoderFor operation with variable speed conveyors
Bar Code Laser ScannerAllows scan and print message retrieval
External Light BeaconIndicates low ink levels

Starter KitIncludes ink, cleaner and flush solution, printhead wipes, hand cleaner and latex gloves

Industrial inkjet printer the Citronix ci580 is a smart-featured continuous ink jet printing System (CIJ). Designed To meet a broad range of applications, the ci580 features the most common needed functions and capabilities necessary for the typical identification, lot date code, sell-by date printing applications.
