S H ELECTRONICS CO.

Shukrawar Peth, Pune, Maharashtra

Function:

• CNC edit
• It can cut different complicated plane figure
• Move at hazard
• Little shape
• High precision

Application

• Suitable for
• Engineering
• Mining
• Fabrication
• Structural manufacturer
• Profile cutting Industry
• Jigs & Fixtures Manufacturer.

Advantages

• Heavy Duty Cantilever design precise working & easy to movable facility with portable cnc cutting machine.
• Excellent cutting output, longitudinal rack & pinion drive.
• Flame can cut Mild steel, Carbon steel.

Available Sizes:

• 1000 x 2000mm
• 1250 x 2500mm
• 1500 x 2500mm
• 1500 x 3000 mm

CNC Profile Cutting Machine developed by Equipments India as SuperXL series which is suitable for many industries for metal plate cutting.This machine is rigid gantry type design Economical level solution for production of Oxy fuel & Plasma cutting process. This machine driven system with heavy duty track for steady and precision cutting.

• Longitudinal and transverse energy feed drag-chains, hose/cable clean and move smooth.
• Direct rack and pinion of 1.5 Module in both axes for accurate and repeatable motion.
• Plasma Torch height sensing system with rapid initial height sensing.
• High torque Stepper motors 3.4nm, 6.8nm or 8.7nm capacity.
• CNC Controllers of 7" or 10.4" screen allows entering the program directly on the system or transfer files through USB.
• Gantry Effective width available in 1.5, 2.0 & 2.5 Meter in standard size. Effective Length available from 3 Meter - 12 Meter.
• Variety of Nesting software available for programming.
• Rapid Speed 10mm - 6000mm/ min, Cutting speed 10mm -2000mm/min.
• Maximum two torch stations available as per customer requirement.

Offering Non Metal Laser Cutting Machine. Non Metal Laser is most suitable and the preferred choice of equipments in industries such as advertisement, gifts, shoes, toys, and etc. Non metal laser is equipped with Texas 32 Bit DSP control system, there is a Flash memory on the mother board, you can download the work file to the machine via USB cable

Preheat flames are used to heat up the surface of the steel to approximately 1000C (1800F bright red color) but below the metal's melting point. A jet of pure oxygen is then directed toward the heated area in a fine, high pressure stream. A vigorous exothermic chemical reaction takes place between the oxygen and metal forming an aluminum or iron oxide or rust. The pressure of the jet of oxygen blows away the slag or oxide forming a cavity. The preheat and oxygen stream are moved at constant speed to form a continuous cut.

• High ratio between quantity and price, good reliability, long-term stability, fast speed, high efficiency, good economic returns, kerf small, cutting surface smooth.
• High cutting precision, can meet all requirements of sheet metal processing technology.
• Focal length automatic follow with cutting head, even if the material surface roughness and also can ensure cutting quality. kerf smooth, perfect, no need clean.
• Low operation cost, all material can be cut by air only (if need faster cutting speed, using oxygen.)
• Collecting trailer with wheel, lightweight design, easy to clean material.
• Powerful smoking device, solve question of metal processing dust and bad environment.
• Use Gantry mechanism, compact structure, no need take up large area.
• Imported linear guide rail, Panasonic servo drive, precision gear and rack, and let whole machine work perfect.

We are offer Kjellberg Plasma source as OEM Partner As pioneers in plasma cutting we have worked intensively on refining this separating process since 1959. We offer you diverse products for CNC-guided and manual plasma cutting. Being the technology leader and oldest manufacturer on the market, Kjellberg Finsterwalde's products of the HiFocus series achieve highest cutting quality and are, therefore, a serious alternative to laser cutting or other precision cutting methods. With Kjellberg Finsterwalde's products - Made in Germany - users not only acquire state-of-the-art plants but also the latest plasma cutting technology. HiFocus stands for highest cutting quality. It allows not only cutting in vertical position and with a smooth surface but also with almost no further treatment required. The cost-efficient units of the PA-S series offer good cutting results for simple applications.

The liquid-cooled plasma torch allows the use of air, oxygen, argon and hydrogen as plasma gas. Furthermore, these robust plasma cutting units can be operated with hand and machine torches. CutFire stands as synonym for powerful but technically simple plasma cutting inverters at low investment costs which are suitable for mechanised cutting of thin sheets. Kjellberg's systems for manual plasma cutting can be used for many applications. According to the customers' preferences there are diverse systems which are perfectly tailored to their individual requirements.

CNC Plasma cutting machine is capable of cutting material much faster than oxy fuel, but plasma is only capable of piercing material up to 50mm thick. Plasma is also able to cut a larger range of material and transfers much less heat into material than oxy fuel. Often plasma cutting torches and oxy fuel cutting torches are mounted on the same CNC cutting machine to give the machine a larger range of processing thicknesses, for example 3mm - 150+mm. For most work Plasma is more efficient than Oxy fuel as 90% of steel cut is less than 50mm thick and if you were to compare some suitable Plasma Cutting system to an oxy fuel system it would process 50mm mild steel more than twice as fast.

This machine is the Heavy gantry in the standard Equipments India product line. The MHG series is designed for use with the latest technology in today's Precision Plasma cutting systems as well as multi-head oxy-fuel applications. The high stiffness, precise linear guides in the transverse axis and heavy duty tracks guarantee the very best quality and a long duration of life. The leading edge of machine technology, incorporating the industry's most reliable digital servo amplifiers, AC brushless motors, precision gearboxes equipped with machine, easily becomes the most productive part of your cutting operation. Fast Oxy fuel cutting with integrated height sensing and ignition. Large structural steel tubing is welded together to form the end trucks and cross axis beam. Mating assembly surfaces are precision machined and ground for maximum accuracy. Precision gear rack insures repeatability and accuracy throughout the entire cutting process

We Equipments India is OEM partners for Hypertherm Plasma Series. HyPerformance plasma systems deliver HyDefinition cut quality at half the operating costs. By incorporating Hypertherm's proven HyDefinition, LongLife, and patented PowerPierce and True Hole technologies, HyPerformance Plasma boosts overall performance, productivity and profitability. The systems offer unmatched process flexibility to cut, bevel and mark metals up to 160 mm (6-1/4") thick. Heavy-duty production tools with cost-reducing LongLife technology for dramatically longer consumable life and much lower operating costs. Ideal for production environments cutting mild steel, stainless steel and aluminum. Hypertherm's Powermax line of products consists of six highly portable air plasma systems for hand or automated cutting and gouging of any electrically conductive metal. With a severance cut capacity range from 5/8" at 30 A to 2 1/4" at 125 A, Powermax systems will help you get your work done faster, easier, more reliably and at lower cost.

It enjoys features of convenient, easy to handle, working stability & elegant appearance. Can make intersecting pipe hole cutting in different directions and different diameters. Can make branch pipe and main pipe vertical or cross in some angle. Can cut branch intersecting pipe's end socket for main pipe. Can cut square and slotted hole and all shapes on the pipe. Can cut dual bending ends for bending of the pipe after welding.

• Equipped with "Two Axis Linkage Control" intersection.
• NC System with 7", 10.5" Color LCD Screen for pipe cutting without beveling.
• Applicable for Flame & Plasma cutting process.
• AC Stepper or Servo motor drive technology.
• Input Power: Single Phase AC 220V, Approximately 600W.
• Transmission: Rack & Pinion drive system.
• Track Length: 2000mm (effective cutting length Y axis). can be customized for extending cutting length.
• Applicable Pipe diameter: F60mm- F600mm.

We could say that CNC is an electronic driver of the Cutting System based on the configurations by the user and the profiles of the parts to be worked on fed into the system before the beginning of the job. Making use of built-in electronic and software automation, CNC can control the cutting process calculating all available parameters, both the ones determined by the Cutting code (G-Code) fed into it beforehand and the real-time cutting data provided by the relevant sensors. It adjusts the proper gas mixture and velocity, the feed rate and the torch movement along the three axes, and the power of the Source. The cutting process is automatically continuously adjusted in the best way, much better than by the most experienced operator.

Plasma cutting is a process that is used to cut steel and other metals of different thicknesses (or sometimes other materials) using a plasma torch. In this process, an inert gas (in some units, compressed air) is blown at high speed out of a nozzle; at the same time an electrical arc is formed through that gas from the nozzle to the surface being cut, turning some of that gas to plasma. The plasma is sufficiently hot to melt the metal being cut and moves sufficiently fast to blow molten metal away from the cut.

We, Equipments India, have established ourselves as a renowned manufacturer and supplier of CNC Flame Cutting Machine as Super series. Successfully inventing the CNC Cutting machines series it can carry advanced technology and fill the gap of cutting machine. Meanwhile our CNC flame cutting machines have been using stably in many Industries like Metal Profile Cutting Industries, Heavy Fabrication Industries, Special Purpose machine Manufacturer, Jigs & Fixtures Manufacturer, Sheet Metal Industries, Agricultural Equipment manufacturing, Auto parts manufacturing Industry.

We, Equipments India, have established ourselves as a renowned manufacturer and supplier of CNC Flame Cutting Machine as Super series. Successfully inventing the CNC Cutting machines series it can carry advanced technology and fill the gap of cutting machine. Meanwhile our CNC flame cutting machines have been using stably in many Industries like Metal Profile Cutting Industries, Heavy Fabrication Industries, Special Purpose machine Manufacturer, Jigs & Fixtures Manufacturer, Sheet Metal Industries, Agricultural Equipment manufacturing, Auto parts manufacturing Industry.

Standard Features

• Cutting width available 1.25 and 1.5 meter
• Cutting length available from 2.0 meter to 3.0 meter
• Longitudinal and transverse energy feed drag chains, hose/ cable clean and move smooth
• DC Stepper drive amplifiers for years of maintenance free operation.
• DC Stepper motors for wide speed range with accurate speed control
• CNC controller allows entering the program directly on the system or transfer files through USB drive
• Nesting software available for Programming
• Single torch station available
• Maximum machine speed: 5000 mm/min
• Precision Linear Rail Drive Engagement
• Adjustable steel mounting pads for adjusting height, level, straightness
