Semco Infratech Pvt Ltd

Patparganj, Delhi

Excellent heat dissipation performance, unique air duct design, through forced air cooling to reduce the impact of high temperature on equipment performance. The dual-fan mode is adopted to forcibly pump air to cool the power cooling module, and the thermal imager is used for thermal simulation test to ensure that the cooling device works within a reasonable temperature range.

The channels can be detachable, and each channel in the same box can be freely connected in parallel according to the need, in order to be compatible with multiple types of battery test, give full play to the one- type multi-purpose of the equipment, and save equipment costs for customers Built-in temperature of the device, each channel can be customized according to the needs of the main temperature without external auxiliary temperature (if there are multiple channels, the temperature needs external auxiliary temperature), real-time monitoring of battery temperature, so as to monitor and protect the normal safety test of the battery according to the temperature change.

It is applicable to the aging test of ternary, lithium iron phosphate, lead-acid, nickel-hydride nickel-cadmium and other battery packs;Suitable for co-port battery packs and split-port battery packs;Output voltage range of the device. 10V60V.ADJUSTABLE, STABLE, OUTPUT CURRENT RANGE 100mA10The.ADJUSTABLE AND STABLE. Battery module production inspection of battery manufacturing enterprises.

Battery pack cycle life test, battery pack capacity test, battery pack charge/discharge characteristics test, battery pack charge retention test, battery pack charge and discharge efficiency test, battery pack charge and over-discharge endurance test.

Battery Charging and discharging system (Semco SI BCDS 100V (20A-40A) (4KW) 1CH)

Charge and discharge Function

With constant current and constant voltage charging function, Constant current discharge function, charge and discharge the battery, and record the battery capacity.

Charge and discharge interface:

Fully meet the requirements of charging and discharging the same port and charging and discharging separate ports of the battery pack, that is, 2 wires (P+ P-) and 3 wires (P+ P- C-). At the same time, it can age the power tool battery (CH+P+P-) with positive plate charge protection and negative plate discharge protection.

Energy feedback energy saving During the test, the battery has energy saving effect (90%), discharge feedback effect (88%), and low heat generation, thus achieving energy saving and cost reduction for users. Safe and smooth transition from constant current to constant voltage charging- The voltage and current of the device adopt a four-wire connection method, and the voltage and current loops are designed independently, so that the constant current to constant voltage charging process can be safely and smoothly transitioned to avoid damaging the battery due to spikes. High-precision calibration method The charging current, discharging current, charging voltage and discharging voltage are all calibrated with high precision by Agilent to ensure that the accuracy of current and voltage is within 0.5%

Charging and discharging function: It has the functions of constant current and constant voltage charging and constant current discharge. It can charge and discharge the battery and record the battery capacity;Charging and discharging interface: Fully meet the requirements of the same charging and discharging port and charging and discharging sub port of the battery pack, i.e. two wires (P + P -), three wires (P + P - C -), electric tool battery with positive plate charging protection and negative plate discharge protection (CH + P + P -)

Origin: India

Condition : New

Power Source : Electric

After reaching high constant voltage charging time of 3.5 hours or the current drops to 0.3A automatically switch to float charging trickle charging

Style : (Semco SI BCDS 23V 50A 8CH)

Supports various testing:

Battery pack cycle life test, battery pack capacity test, battery pack charge/discharge characteristics test, battery pack charge retention test, battery pack charge and discharge efficiency test, battery pack charge and over-discharge endurance test.

It is applicable to the aging test of battery packs such as ternary, lithium iron phosphate, lead acid, nickel-nickel-cadmium, etc.

It is suitable for the same battery pack and separate battery pack

Equipment output voltage rangeTenV75VModulation, stability, output current range100mA40A Modulation and stability

Battery module production and testing of battery manufacturers;

Vacuum cleaners, electrical tools, scooter battery packs Charge and discharge detection

Battery pack cycle life test, battery pack capacity test, battery pack charge/discharge characteristics test, battery pack charge retention test, battery pack charge and discharge efficiency test, battery pack charge and over-discharge endurance test.

Discharge energy feedback to the grid; adopting a dual closed-loop structure, constant current and constant voltage conversion can smoothly transition, effectively preventing current spikes and large currents from impacting the battery cells, protecting the battery cells.

Style : (Semco SI-B BCDS 30V 10A 32CH)

Energy feedback energy-saving type, there is energy saving during the test (80%), the effect of discharge feedback (75%), heat is small, so as to achieve the purpose of energy saving and cost reduction for users

Constant current to constant voltage charging safely and smoothly, the voltage and current of the device are connected in a four-wire system, and the voltage and current loops are independently designed to ensure a safe and smooth transition during the constant current to constant voltage charging process to avoid damage to the battery due to spikes

High precision Calibration method, the charging current, discharging current, charging voltage and discharging voltage are all calibrated with high precision by Agilent to ensure that the accuracy of current and voltage is within 0.5%

It is applicable to the aging test of battery packs such as ternary, lithium iron phosphate, lead acid, nickel-nickel-cadmium, etc.

It is suitable for the same battery pack and separate battery pack

Equipment output voltage rangeTenV60VModulation, stability, output current range 100mA60A Modulation and stability

Battery module production and testing of battery manufacturers

Charge and discharge interface:

Fully meet the requirements of charging and discharging the same port and charging and discharging

separate ports of the battery pack, that is, 2 wires (P+ P-) and 3 wires (P+ P- C-). At the same time, it

can age the power tool battery (CH+P+P-) with positive plate charge protection and negative plate

discharge protection.

Charge/discharge function: Constant current and constant voltage charge function, constant current discharge function, charge/discharge the battery and record the battery capacity

Charge and discharge interface: Fully meet the requirements of the battery pack charging and discharging the same port and charging and discharging sub-port, that is, 2 wires (P + P-)

3 wires (P + P- C-) and positive plate charging protection, negative plate discharging protection of power tool batteries (CH + P + P-)

Check voltage protection: By charging and discharging the battery, check whether the charging protection and discharging protection of the battery work

Built-in temperature of the device, each channel can be customized according to the needs of the main temperature without external auxiliary temperature (if there are multiple channels, the temperature needs external auxiliary temperature), real-time monitoring of battery temperature, so as to monitor and protect the normal safety test of the battery according to the temperature change Single box power supply, the whole cabinet each box independent power supply, to ensure the stability and safety of the whole cabinet power supply

Independent power supply to ensure uniform circuit output in the process of power supply, no protection problems

It is applicable to the aging test of battery packs such as ternary, lithium iron phosphate, lead acid, nickel- nickel-cadmium, etc.

It is suitable for the same battery pack and separate battery pack.

Equipment output voltage rangeTenV120VModulation, stability, output current range100mA100A Modulation and stability.

Battery module production and testing of battery manufacturers

Product features:

Modular design, single-point control technology, convenient expansion, high production and maintenance efficiency

Battery cycle life test

Battery charge/discharge characteristic test

Battery charge retention ability test

Battery charge/discharge efficiency test

Battery overcharge/over discharge rate endurance test

Support CAN communication to realize data docking with BMS

Support docking with MES system

Excellent heat dissipation performance, Unique air duct design, through forced air cooling to reduce the impact of high temperature on equipment performance. Adopt dual-fan mode, perform forced air cooling on the power cooling module, and use thermal imager for thermal simulation test to ensure that the radiator works within a reasonable temperature range.

The channel is detachable, Various channels in the same box can be freely connected in parallel according to needs to be compatible with multiple types of battery tests, give full play to the multiple functions of the equipment, and save equipment costs for customers.

Charging and Discharging mode:

Stand still, pause, constant current charging CC, constant voltage charging CV, constant resistance charging CR, constant current and constant voltage charging CCCV, constant power charging CP, constant current discharge DC, constant power rate discharge DP, constant resistance discharge DR, DC internal resistance test

Energy feedback energy saving During the test, the battery has energy saving effect (90%), discharge feedback effect (88%), and low heat generation, thus achieving energy saving and cost reduction for users.

Safe and smooth transition from constant current to constant voltage charging- The voltage and current of the device adopt a four-wire connection method, and the voltage and current loops are designed independently, so that the constant current to constant voltage charging process can be safely and smoothly transitioned to avoid damaging the battery due to spikes

High-precision calibration method - The charging current, discharging current, charging voltage and discharging voltage are all calibrated with high precision by Agilent to ensure that the accuracy of current and voltage is within 0.5%

Excellent heat dissipation performance, Unique air duct design, through forced air cooling to reduce the impact of high temperature on equipment performance. Adopt dual-fan mode, perform forced air cooling on the power cooling module, and use thermal imager for thermal simulation test to ensure that the radiator works within a reasonable temperature range

The channel is detachable, Various channels in the same box can be freely connected in parallel according to needs to be compatible with multiple types of battery tests, give full play to the multiple functions of the equipment, and save equipment costs for customers

It is applicable to the aging test of battery packs such as ternary, lithium iron phosphate, lead acid nickel-nickel-cadmium, etc.

It is suitable for the same battery pack and separate battery pack.

Equipment output voltage rangeTenV200VModulation, stability, output current range 100mA 100A Modulation and stability.

Charge and discharge mode:

Standstill, pause, constant current charging CC, constant voltage charging CV, constant resistance charging CR, constant current constant voltage charging CCCV, constant power charging CP, constant current discharge DC, constant power rate discharge DP, constant resistance discharge DR, DC internal resistance test

Scope of application of the equipment: Mainly used in the production or experiment of lithium-ion batteries, lead-acid batteries, nickel-cadmium batteries, nickel-hydrogen batteries, etc. Life aging testing (Circle Life Testing) and quality control.

Supported test content: Battery pack cycle life test, battery pack capacity test, battery pack charging characteristic test, battery pack discharge characteristic test, battery pack charge retention test, battery pack charge and discharge efficiency test, battery pack overcharge, over discharge rate tolerance test, etc.

Energy feedback energy saving During the test, the battery has energy saving effect (90%), discharge feedback effect (88%), and low heat generation, thus achieving energy saving and cost reduction for users.

Safe and smooth transition from constant current to constant voltage charging- The voltage and current of the device adopt a four-wire connection method, and the voltage and current loops are designed independently, so that the constant current to constant voltage charging process can be safely and smoothly transitioned to avoid damaging the battery due to spikes

High-precision calibration method - The charging current, discharging current, charging voltage and discharging voltage are all calibrated with high precision by Agilent to ensure that the accuracy of current and voltage is within 0.5%

Energy feedback energy saving During the test, the battery has energy saving effect (90%), discharge

feedback effect (88%), and low heat generation, thus achieving energy saving and cost reduction for users.

Safe and smooth transition from constant current to constant voltage charging- The voltage and current of the device adopt a four-wire connection method, and the voltage and current loops are designed independently, so that the constant current to constant voltage charging process can be safely and smoothly transitioned to avoid damaging the battery due to spikes

High-precision calibration method - The charging current, discharging current, charging voltage and discharging voltage are all calibrated with high precision by Agilent to ensure that the accuracy of current and voltage is within 0.5%

Charge:

Constant current charging, the channel outputs with constant current, and the current output adopts soft start. No current impact; Constant current and constant voltage charging in continuous mode, while limiting voltage output and current output. Automatic hardware switching, current hardware soft start, constant flow constant voltage without impact current

The constant voltage and constant current charging is safe and smooth, and the voltage and current sampling output of the device is controlled through the four-wire system connection for soft start, so as to make a safe and smooth transition in the constant voltage and constant current charging process to avoid the occurrence of peak damage to the battery. High-precision calibration: charging current, discharge current, charging voltage and discharge voltage are all calibrated by Agilent with high precision to ensure the accuracy of current within 1 and voltage within 0.5%.

Quality : Optimum

Grade : Premium

Brand : Semco

Condition : New

Country Of Origin : India

Durability : Long Lasting

* It is suitable for aging test of ternary, lithium iron phosphate, lead acid, nickel-hydrogen- nickel-cadmium battery packs.

* Suitable for battery pack with the same port.

* The voltage range of aging battery pack of equipment is 10V 100V, and the charging and discharging current range is 0.1 A 50A.

* The equipment is efficient and energy-saving, and the charging and discharging conversion efficiency is 85%-94%.

Energy feedback energy-saving type, during the test process, it has the effect of charging energy saving (90%) and discharging feedback (88%), with little heat generation, so as to achieve the purpose of saving energy and reducing costs for users.

Constant current to constant voltage charging is safe and smooth, the voltage and current of the equipment adopt the four-wire connection mode, and the voltage and current loop The circuit is independently designed to make a safe and smooth transition during the constant current to constant voltage charging process to avoid damage to the battery due to spikes case.

It is applicable to the aging test of battery packs such as ternary, lithium iron phosphate, lead acid,

nickel-nickel-cadmium, etc.

It is suitable for the same battery pack and separate battery pack;

Equipment output voltage rangeTenV100VModulation, stability, output current range100mA60AModulation and stability.

Battery module production and testing of battery manufacturers;

Vacuum cleaners, electrical tools, scooter battery packs Charge and discharge detection

It is suitable for aging test of ternary, lithium iron phosphate, lead acid, nickel-hydrogen-

nickel-cadmium battery packs.

Suitable for battery pack with the same port.

The voltage range of aging battery pack of equipment is 10V 100V, and the charging and discharging current range is 0.1 A 50A.

The equipment is efficient and energy-saving, and the charging and discharging conversion efficiency is 85%-94%.

Charge and discharge mode:

Stand still, pause, constant current charging CC, constant voltage charging CV, constant resistance charging CR, constant current and constant voltage charging CCCV, constant power charging CP, constant current discharge DC, constant power Rate discharge DP, constant resistance discharge DR, DC internal resistance test

Channel Features:Constant Current Source and Constant Voltage Source with Independent pairs of Closed-loop Structure.

Constant Voltage Output Range:25mV-5V

Charge Mode:CC, CV, CCCV, CP

Channel Features:Constant Current Source and Constant Voltage Source with Independent pairs of Closed-loop Structure.

Channel Control Mode: Independent Control

Constant Voltage Output Range: 0.025V-5V

Charge Mode:CC, CV, CCCV, CP

Input Power: AC 220V/110V 10% / 50Hz

Channel Features:Constant Current Source and Constant Voltage Source with Independent pairs of Closed-loop Structure

Constant Voltage Output Range: 25mV5V

Automated Switch:Automated switch from charge to discharge for each pulse

Channel feature:Constant current source and constant voltage source dual closed loop control

Channel parallel connection:Support max 4 channels parallel mode. Pulse and SIM tests will be disabled in channels parallel mode

Input power supply:AC380V15% 50/605Hz

Power input protection:Anti-surge, anti-islanding, over-under-frequency, over-under voltage, open- phase protection, etc

Input power:AC380V15% 50/605Hz

Power input protection:Anti-surge, anti-silos, anti over or under frequency, anti over or under voltage, anti-phase absence, etc.

Channel feature :Constant current source and constant voltage source dual closed loop control

Channel parallel connection :Support max 4 channels parallel mode. Pulse and SIM tests will be disabled in channels parallel mode.

The voltage of each battery is detected in real time. When charging, constant current charging is performed first. When the battery voltage reaches the set value, it will smoothly transition to constant voltage charging. When the set time or current termination conditions are met, charging ends. During constant current discharge, when the battery voltage is lower than the set value, the discharge ends and the corresponding battery indicator lights up.

The constant voltage and constant voltage charging is safe and smooth, and the voltage and current sampling output of the device is controlled through the four-wire system connection for soft start, so as to make a safe and smooth transition in the constant voltage and constant voltage charging process to avoid the occurrence of peak damage to the battery.

High-precision calibration: charging current, discharge current, charging voltage and discharge voltage are all calibrated by agilent with high precision to ensure the accuracy of current and voltage within 0.5%

Charge mode:Constant current charging, constant voltage charging, constant current and constant voltage charging, constant power charging, constant resistance charging

Charge mode: Constant charge mode, constant power mode

Cycle : 160000 times

Curve type:Able to draw the corresponding relationship curves during the formation process of each battery, including voltage/time curve, current/time curve, capacity/time curve, capacity/voltage curve, etc.

Charge mode:Constant current charging, constant voltage charging, constant current and constant voltage charging, constant power charging, constant resistance charging.

Hardware protection:Battery reverse connection protection, short circuit protection, poor contact protection in the circuit, dual-loop measurement protection for battery voltage.

Channel features:Discharge energy feedback to the grid; adopting a dual closed-loop structure, constant current and constant voltage conversion can smoothly transition, effectively preventing current spikes and large currents from impacting the battery cells, protecting the battery cells.

The Semco SI CT 5V 10A 20CH- Upto 33140 is capable of conducting capacity tests, charge and discharge characteristic tests, capacity grading and matching, balance maintenance, internal resistance tests, data analysis & comparison, etc., for a variety of Lithium batteries, NiMH batteries, and NiCD batteries. It offers physical compatibility with 18650, 26650, 32650 cells as well as pouch and prismatic cells.

Semco SI CT 5V/20A 8CH can be used for capacity test, charge and discharge test, capacity grading and matching, balance charging, etc. of various types of Li-ion Batteries, Ni-mH batteries, Ni-CD batteries. SI CT 5V/20A 8CH isolation detection technology can determine the location of the bad cells without disassembling the battery pack, then replace it. It can even charge and discharge the unbalanced battery pack to balance the battery and restore the battery pack to normal balance.

The constant voltage and constant current charging is safe and smooth for prismatic cell tester and the voltage and current sampling output of the device is controlled through the four-wire system connection for soft start, so as to make a safe and smooth transition in the constant voltage and constant current charging process to avoid the occurrence of peak damage to the battery.

Basic Function:

Charge Discharge Auto-cycle charge discharge Balance maintenance Internal resistance test Capacity grading and matching Test data analysis and comparison.

Power Supply:AC200V245V50/60HZ

Applicable Batteries:LiFePO4, Ternary lithium, LiCoO, Ni-mh, NiCd

Current sampling device uses imported alloy material, which ensures large current testing stability.

The current output uses the soft start mode, which avoids heat impact to the battery and the connector caused by the instantaneous output high current ripple.

Equipment hardware control loop uses current and voltage double loop control. No ripple for constant current and constant voltage switching.

Channel features: Discharge energy feedback to the grid; adopting a dual closed-loop structure, constant current and constant voltage conversion can smoothly transition, effectively preventing current spikes and large currents from impacting the battery cells, protecting the battery cells.

Curve type: Able to draw the corresponding relationship curves during the formation process of each battery, including voltage/time curve, current/time curve, capacity/time curve, capacity/voltage curve, etc.

Hardware protection: Battery reverse connection protection, short circuit protection, poor contact protection in the circuit, dual-loop measurement protection for battery voltage.

Channel Fearures:

Discharge energy feedback to the grid; adopting a dual closed-loop structure, constant current and constant voltage conversion can smoothly transition.Effectively preventing current spikes and large currents from impacting the battery cells, protecting the battery cells.

Hardware Protection:Battery reverse connection protection, short circuit protection, poor contact protection in the circuit, dual-loop measurement protection for batteryvoltage

Protection function:Reverse connection protection, short circuit protection, undervoltage protection, overvoltage protection, overcurrent protection, overtemperature protection, data loss protection, abnormal voltage protection, abnormal, current protection, offline protection. When the software protection reaches the user-set parameters, the device will automatically stop the channel operation and issue an alarm. At the same time, the software will record, it for easy tracking.

Main Features:

High efficiency in energy saving, discharging energy regenerates to power system with low heat.

Independent channels with configurable parameter and condition setting for each individual channel.

Reliable and ultra-high precision testing with 0.05% accuracy.

Equipped with complete input and output devices, hardware and software protection, polarity reverse protection, power failure protection and etc.

Precise control without overshoot during CC-CV and CV-CC transition.

Features:

Charging overvoltage protection, charging under voltage protection

discharge overvoltage protection, discharge under voltage protection

Charge and discharge voltage trend protection

Voltage fluctuation protection

Current fluctuation protection

Battery reverse protection, hardware protection

Power tube short-circuit protection

Channel capacity alarm protection (timeout protection)

Voltage sampling off-line protection

Charging mode:Constant current charging, constant voltage charging, constant current constant voltage charging, constant power charging.

Cut-off condition:Voltage, current, relative time, capacity

Software protection:Overvoltage protection, under voltage protection, capacity protection, overcurrent protection, undercurrent protection

Charge modes:CC, CV, CCCV, CP, CCCV for battery pack

Input AC :AC 380V/208V 10% / 50Hz

Cut-off condition:Voltage, Time

Output power:500W

Charge mode:Constant current charging, constant voltage charging, constant current and constant voltage charging, constant power charging, constant resistance charging.

Input Power: AC380V 10%/50Hz

Discharge mode:Constant current discharge, constant power discharge, constant resistance discharge

Charging: Constant Current CC, Constant Voltage Charging CV, Constant Current and constant Voltage Charging CC CV;

Discharge: Constant current discharge CD, Constant power discharge CP; Aging Suspension

Output power: Maximum power of single channel continuous operation 500W

Channel control mode : Each battery has an independent constant current and constant voltage source, which is stable without impact. Start, stop, pause, continue and protection can be realized.

Each channel's charging current and discharging current accuracy can be automatically calibrated through software. It has the function of real-time detection of contact impedance (four-wire system)

Power tube using field effect tube, suitable for lower voltage discharge battery, such as lithium iron phosphate battery.

The use of graphic operation interface, intuitive and clear, while displaying the battery voltage, current, time, capacity and other data and can be set the same color displays the corresponding working status and abnormal conditions.

The equipment accuracy is 0.05%, the data recording time is 1 second/time, and the stability is high.

Charging Mode: Constant Current Charging, Constant Voltage Charging, Constant Current and Constant Voltage Charging, Constant Power Charging, Pulse Step, Analog Step

Discharge Mode: Constant Current Discharge, Constant Power Discharge, Constant Resistance Discharge Auxiliary Channel: Temperature

Operation Environment Temperature: 0C40C (When the Temperature Is 2510C, The Accuracy Error Caused by Temperature Change Is Less Than 0.005% Of FS/C)

Channels Feature: Independent Pairs of Closed Loop for Constant Current Source and Constant Voltage Source.

Current sampling device uses imported alloy material, which ensures large current testing

stability.

The current output uses the soft start mode, which avoids heat impact to the battery and the

connector caused by the instantaneous output high current ripple.

Equipment hardware control loop uses current and voltage double loop control. No ripple for

constant current and constant voltage switching.

* High-precision calibration: Charging current, discharge current, charging voltage and discharge voltage are all calibrated by Agilent with high precision to ensure the accuracy of current and voltage within 0.5%.

* Independent channels with configurable parameter and condition setting for each individual channel.

Automatic Double-side spot welding equipment is powered up by Semco 8000A/10000A powersupply.

Able to spot weld0.2mm pure nickel strip and nickel-plated steel strip, capable of flat welding0.2mm pure nickel and steel nickel plated nickel sheet.

Able to spot weld 0.3mm pure nickel strip and nickel-plated steel strip with welding spot onsurface, capable of welding 0.25mm pure nickel and steel nickel-plated nickel sheets with bumpson the surface Easy programming, support random position welding and array welding, able to download 99 setsWelding array programming is simple, supports any point programming and array programming, graphics import, and can store 99 groups of programming files.
Copper welding needle replacement warning, the equipment will remind users to replace worn-out welding needles Welding needle replacement forecast reminder, the device will promptlyremind the user to replace the lost welding needle.

Working voltage: AC 220V10%/50Hz, power: 1.5 KW

Working gas source: 0.50.7 Mpa (dry gas)

Sorting efficiency: 45PPM

Adapt to battery specifications: 33140/40135 finished battery cellsEquipment weight: about 300kgEquipment qualified rate: 99.5%

Equipment utilization rate: 98%

Dimensions: 1500 (length) 900 (width) 1600 (height) mm

Sorting machine frame material: High-quality thick cold-rolled plate, made of aluminiumprofile.

Semco SI 05C MFSM multi-function cylindrical battery testing and sorting machine is applicableto a variety of specifications of cylindrical battery voltage, internal resistance test of automaticequipment. 4 good gear, 1 bad product profile.

Applicable batteries models (18650/18700/21700/26650/26700/32650/32700).

This machine to test the sorting is controlled by PLC+ touch screen man-machine interfacecomponents. Per hour complete cylinder finished batteries sorting quantity 3000-3600branched left and right. Mechanical structure is simple and elegant design, system testing andstable performance.

It is mainly composedof climbing pulsator, lifting slope, feeding storage hopper, battery discharging pulsator, andstorage belt. After the washing machine is discharged, the height of the washing machine isdifferent from that of the lamination machine, so a climbing mechanism is added in the middleto solve the problem of height difference. After the battery passes through the pulsator andclimbs the slope, it enters the storage hopper, and the hopper pulsator turns the battery tothe storage belt.

Semco SI-BR 6CH MFSM-18135-33145-40140- Six channel Multifunction with Barcode scannercylindrical battery testing and sorting machine is along Automatic sorting equipment for cylindricalcell voltage and internal resistance testing. 51 good product file, defective product file, applicablecell model: 18135/18140/twenty one135/26135/26140/32140/33140/40135 And other models, thenumber of cylindrical finished cells sorted per hour 3000 Only above. The mechanical structure designis simple and elegant, and the system test performance is stable.The data query of a single batterycan be realized by assembling the code scanning mechanism. The mechanical structure design issimple, and the system test performance is stable.

The connection current rises very fast, realizing high-quality welding in a short time.

Welding current/voltage/power resistance waveform for dynamic real-time monitoring.

Welding transformer, small / lightweight/ beautiful.

Constant current/constant voltage/constant current and constant voltage combined modethree control modes.
