We are leaders in the market for providing best range of Counter Balance
| Product model | CPD25A | |||
| power mode | lead-acid battery | truck body length(fork excluded) | 2800mm | |
| operating mode | seated | truck body width | 1200mm | |
| rated capacity | 2500kg | height, mast retraction | 2200mm | |
| load center distance | 500mm | turning radius | 2650mm | |
| wheelbase | 1970mm | groubd clearance under mast | 110mm | |
| tire type | Solid tires | travel speed, laden/unladen | 9/10km/hadjustable speed | |
| wheels number(front/rear) | 2/2 | lifting speed, laden/unladen | 180/200mm/sadjustable speed | |
| front track | 900mm | maximum negoniable gradient, laden/unladen | 15/20 | |
| rear track | 810mm | service mass(with battery) | 3300kg | |
| tire(front) | 650-10 (widened) | battery voltage /nominal capacity | 60V/280AH | |
| tire(rear) | 18X7.8 (widened) | drive motor power | 11kw | |
| tilt of the mast, front/rear | 5/10 | lift motor power | 11kw | |
| overall maximum lift height | 3000mm | drive motor controlling mode | MOSFET/AC | |
| lateral Fork Adjustment(Outside of Forks)Max/Min | 1040/100mm | lifting motor controlling mode | MOSFET/AC | |
| fork size(TxWxL) | 45*122*1070mm | service brake/parking brake | Hydraulic/Mechania | |
| Charging voltage | 220/110V | Battery life | 6-8h | |
| Gantry material | Forklift 160special steel | Fork material | Forged forks |
Additional Information:
Payment Terms : L/C, D/A, D/P, T/T, Western Union
Packaging Details : As per customer demand
