Speed Kleen Systems

Ecotech Xii, Greater Noida, Uttar Pradesh

Specification-

• Sheet Material :Mild Steel, Galvanized Iron, Stainless Steel Etc.
• Thickness :1 mm, 1.6 mm, 2 mm, 2.5 mm, 3 mm, 4 mm, 5 mm, or can be customized as per requirement.
• Size: 1100 ltrs, 2500 ltrs, 3500 ltrs, 4500 ltrs, 6500 ltrs, 8500 ltrs or can be customized as per requirement.
• Wheel : Solid Caster Wheel of 4 Nos. There will be an option with Brake & Without Brake.
• Channel :M.S. with (10050)mm & (7540)mm Etc according to the Strength & capacity of container
• Arrangement: Top cover for garbage loading/Unloading in 1100 litres containers & Top Cover for loading & Side Cover for unloading of garbage in above 2000 litres.

We are the leading organization in the industry to manufacture and supply the best quality range of Commercial Waste Bin or M. S. Dustbin. The provided bins are precisely manufactured by our highly experienced professionals using the best grade raw material and modern technology. Offered bins are available in different sizes as per the demands of our clients. Moreover, our clients can avail these bins from us at the most affordable prices. Garbage Dustbin is our Speed product and is our specialty.

Our Skip Bins are manufactured from 3mm sheet with RHS Frames. Our Lifting lugs are made from the solid bar (not tube as in some) and through welded the RHS (Rectangular Hollow Structure) providing a much stronger and safer lifting point.

We do have a standard stock range of skip bins in 2 3 4 5 and 6m sizes, we find it is often necessary to manufacture to your specific design and dimensions. For an obligation, free quote on your skip bin needs some dimensions and we will price your bins accordingly.

Sky lift is an also known as automatic lifting machine for maintenance purposes in different sections such as municipalities works, Highways, Building Glass Cleaning & Constructions Etc.

They are being manufactured with High Strength, Reliability, Superior Quality & Better utilization for its end use.

Technical Data

• Code:SSL-03
• Chassis :2 Ton, 6 Ton, 7 Ton, 9 Ton, 12 Ton, 16 Ton Etc.
• Size Available:7 Mtr, 9 Mtr, 11 Mtr, 14 Mtr, 16 Mtr or Customized .
• Sheet Material:Mild Steel (IS:2062)
• Thickness:3 mm (4, 5, 6) Etc
• Bucket:FRP Material with Single Person or Two Person lift
• Cylinder: 2 Nos. for Bucket Lifting & 2 Nos. for Stabilizers (Customized)
• Hydraulic Pump:20-80 LPM
• Hydraulic Motor:50-200 CC
• Hydraulic Hoses:High Pressure Hoses
• Power Take Off :Suitable Power Transfer Ratio from Gear box to Drive Shaft
• Hydraulic Tank:30-70 Ltrs capacity
• Operating :Sky lift is operated by help of 2 Nos. Heavy Cylinder those are mounted on Heavy Booms for lifting the Bucket on certain height by help of Control Valve.

• VEHICLE: TATA SUPER ACE
• VOLU MATRIC CAPACITY: 2.5 Cub. Mtr
• CHASSIS: TATA ACE
• BOTTOM & SIDES : 2.0 MM G.I. Sheet
• TOP, REAR DOOR & WINDOW: 1.6 MM approx. G.I. Sheet
• HYDRAULIC SYSTEM: 12 V DC Battery Operated PowerPack System
• ACCESSORIES: STD accessories like Oil Tank, Hyd. Rubber Hose Pipe, Oil Filler knob, Oil Level Indicator, etc.
• S. MATERIAL: All angles and channels and other raw materials are as per Indian STD and Rolling Mill variation allowed.
• PAINTS: 1 coat of zinc-based primer inside & outside of the tipper, 1 coat of black color inside the Tipper & underbody of Tipper & 2 coat of MSWM Colour scheme outside the tipper paint must be of the standard brand only like Asian/ Berger /Sunlac / Estee.
• ACCESSORIES & SAFETY: Standard tool kit for each vehicle.
• User manual & service book for each vehicle.
• Electronic push-button type control for tipping Container.

• Carrying Waste Material containers of different sizes.
• It is a unique, highly productive, easy operational and low maintenance, hygienic system to help in keeping a city clean.
• Better waste Handling Equipment vehicle in its range of products.
• Heavy duty cylinders to carry heavy containers safely in very less time.
• Optimum Loading & Unloading ability through heavy duty hydraulic hoses, Pumping system and safety devices like load holding valve, pressure & safety valve etc.
• Hydraulically arrangement for Lifting system with the help of Control lever for minimize the human efforts & time.
• Arrangement for stabilizing of vehicle with stabilizers for better Strength & Rigidity at the same time of heavy operation.
• Suitable for Municipalities, Building Developments as well as Individual.

Multi-Modal container Handling system, best suitable for containerized movement of Garbage, Scrap, Chemical, Debris. Available in Capacity of 3 Tons to 40 Tons.

We are engaged in manufacturing and selling the best quality of Hydraulic Trailer which are manufactured with the standard quality of raw material. These products are presented in various capacities and needs of our clients and they can easily move agriculture residue from one place to another. Before supplying our products we check the quality of the products to make sure that we are supplying the superior products to our clients.

Easy to operate & transportEasy loadingLow noise operationRust-proofHigh strengthStrong construction

We are manufacturing ofPortable Garbage compactor Trucks for the safe and efficient collection of waste Garbage. The advanced level of features for Machine loading, compacting and transportation are sure to meet your needs. Making the collection process easy and efficient has made COMP 10-16 models popular the all India.

Tailgate and ejector controls are in front of the body. All devices for loading control are mounted on tailgate right side, and all are manual control for safety purposes. Compaction is controlled electrically via push buttons, and manually in case. There is an emergency stop button each of side the truck on the control panel.

Our range ofDog Squad vanis considered as the most versatile equipment. Designed to perfection, these find applications in catching of dogs/ animals. we are dedicatedly engaged in manufacturing and supply of wide range of cattle catcher vehicle and dog Squad van.

Our company specializes in manufacturing and supplyingAnimal Catcher Vehiclealso. Animal Catcher Vehicle is used for catching the stray animals. Also, the bodies of the dead animals are collected from roads and streets using the Animal Catcher Vehicle. The Animal Catcher Vehicle we supply is a tractor mounted and manually pully operated vehicle. Further, this Animal Catcher Vehicle has a checkered floor that reduces the chances of slipping of animals.

The SRS (Speed Runway Sweeper) airport sweeper is a further development of the SRS airport sweeper, which has been a worldwide success. Safety at the airport is top priority. The high-speed Runway sweeper cleans all service and traffic areas of the airport with outstanding sweeping efficiency, so that follow-up damage caused by foreign objects is prevented. The Runway is suitable for professional use at both civil and military airports and is extremely versatile in everyday operations. It combines all important functions in one machine.

We are the leading manufacturer and supplier of Cattle Catcher vehicle in India. We offer Cattle Catcher Vehicle, which is well designed for Animal Pickups and Transportation. The Animal Catcher Vehicle is ideal for careful transportation of stray both alive and dead. The floor of our Catcher Vehicle is checkered. Thus, it is non- slippery. We are counted among the leading Manufacturers, Suppliers and Exporters of Catcher Vehicle.

• Suction Machine is used for Cleaning of Sewer Lines by Sucking out the dirt / Dust / Garbage / Other Impurities directly from chamber into its vacuum tank.
• Jetting machine is used to clear the blockage/choking of sewer lines by High capacity Jet throw of liquid that is store in its fresh water tank.
• Its easy operations, low maintenance & High capacity Suction-Jetting system helps in superior cleaning of Sewer lines with high productivity & in very less time.
• Provision for manufacturing suction and vacuum tank separately or combined on single vehicle.
• Heavy duty cylinders to Tipping the unit by help of control valve & also provision for hydraulic opening of rear door that will reducing the human efforts.
• High quality suction Hose, Jetting hose, Washing Hose, Hydraulic Motor & Pump are maintain the overall operations within optimum conditions.
• Suitable for Refineries, Municipalities, Building Developments as well as Others Cleaning Operations as required.

We manufacture and supply a wide range of Gully Pit Emptier Machines in Noida, Ghaziabad, Uttar Pradesh, India. These are fabricated by the high quality raw material which is procured by the reliable vendors. We also provides after sales service and supply spare parts of machines which enhances the life and performance of machinery.

Suitable for use in:Cesspit, Cesspool, Manhole chambers, Underground drainage

Sewer lines Important safety Features:Heavy-duty vacuum pump, Auto shut off valve, Siphon filter

Safety pressure release valves Capacities:3500 liters, 4000 liters, 8000 liters, 10, 000 liters

SPEED 2000

Suitable for cleaning of roads & paved areas in Cities, Industrial Plants, Housing Complexes, Parking area, Aircraft Hangers etc

Features:

• Highly Maneuverable
• Easy movement in restricted areas
• Hydraulic dumping of Dust Container
• Container Volume: 160-800 Ltr

De-silting Machine is deployed for dislodging settled sludge/ sit from underground trunk sewer pipeline, open drains, and suctioning the same from the depth of 8 to 10 Meters through specially designed fluidizing nozzles. The Suctioned sludge is collected in a truck-mounted suction Dump Tanker with cyclone for on wards disposal at dumping grounds.

The Manhole De-silting Machine set is developed using sophisticated machinery that guarantees better efficiency. Manhole De-silting Machine is known in the industry customers because of its unique characteristics such as high performance and durability to be generated in customized specifications. We sell the Manhole De-silting Machine at a highly competitive price for the patron
