Our Products
Our product range contains a wide range of LLDB3 Trigger Diode, BZV55C Zener Diode, BZX84C Zener Diode, LL4148 Switching Diode and 1N4148W Switching Diode
A Schottky diode, also known as a hot carrier diode, is a semiconductor diode which has a low forward voltage drop and a very fast switching action. There is a small voltage drop across the diode terminals when current flows through a diode. A normal diode will have a voltage drop between 0.6 to 1.7 volts, while a Schottky diode voltage drop is usually between 0.15 and 0.45 volts. This lower voltage drop provides better system efficiency and higher switching speed. In a Schottky diode, a semiconductor–metal junction is formed between a semiconductor and a metal, thus creating a Schottky barrier. The N-type semiconductor acts as the cathode and the metal side acts as the anode of the diode. This Schottky barrier results in both a low forward voltage drop and very fast switching.
Peak Repetitive Reverse Voltage
| 　 | 20V | 30V | 40V | 50V | 60V | 80V | 100V | 150V | 200V | |
|---|---|---|---|---|---|---|---|---|---|---|
| Average Forward Current | 1.0A | 1N5817 | 1N5818 | 1N5819 | 　 | 　 | 　 | 　 | 　 | 　 |
| SB120 | SB130 | SB140 | SB150 | SB160 | SB180 | SB1100 | 　 | 　 | ||
| 2.0A | SB220 | SB230 | SB240 | SB250 | SB260 | SB280 | SB2100 | SB2150 | SB2200 | |
| 3.0A | 1N5820 | 1N5821 | 1N5822 | 　 | 　 | 　 | 　 | 　 | 　 | |
| SB320 | SB330 | SB340 | SB350 | SB360 | SB380 | SB3100 | SB3150 | SB3200 | ||
| 5.0A | SB520 | SB530 | SB540 | SB550 | SB560 | SB580 | SB5100 | SB5150 | SB5200 |
Peak Repetitive Reverse Voltage
| 20V | 40V | 60V | 100V | 150V | 200V | ||
|---|---|---|---|---|---|---|---|
| Average Forward Current | 1.0A | SS12A | SS14A | SS16A | SS110A | 　 | 　 |
| 2.0A | SS22A | SS24A | SS26A | SS210A | SS215A | 　 | |
| SS22B | SS24B | SS26B | SS210B | SS215B | 　 | ||
| 3.0A | SS32A | SS34A | SS36A | SS310A | 　 | 　 | |
| SS32B | SS34B | SS36B | SS310B | SS315B | 　 | ||
| SS32C | SS34C | SS36C | SS310C | SS315C | SS320C |
