TFP-40S is made from high-quality silicon piezoresistive sensor. The piezoresistive sensor is packaged in stainless steel housing. The TFP-40S is precision engineered to fit most industrial pressure measurement.The compact and rugged design makes these pressure transmitter suitable for applications including process control systems, hydraulic systems and valves, refrigeration and HVAC controls, level measurement and test equipment . A wide range of process connection and electrical connection options are available to meet almost requirement.

Features :

• Measuring ranges from 100mbar to 600bar
• Absolute, gauge and sealed gauge
• Accuracy - ±0.25%FSO or ± 0.5%FSO
• Calibrated and temperature compensated
• Stainless steel construction
• Piezoresistive pressure sensor design
• Variety of Pressure & Electrical connections
• Output 4.20mA, 0.10V, 0.5V and others

Applications :

• Process control systems
• Refrigeration and HVAC controls
• Hydraulic systems and valve
• Machine building
• Pumps and compressors

Product Overview :

• TFP-40T is made from high temperature silicon piezoresistive sensor chip. The piezoresistive sensor chip is packaged in a fluid-filled cylindrical cavity and isolated from measured media by a stainless steel diaphragm and housing. The measured media is transferred onto sensor through heating cooling parts, and high accuracy amplified circuit board is in stainless steel housing, transmitting sensor signal into standard output signal.
• A wide range of process connection and electrical connection options are available to meet almost requirement.

Features :

• Measuring ranges from 350mbar to 600bar
• Absolute, gauge and sealed gauge
• Accuracy - ±0.25%FSO or ± 0.5%FSO
• Calibrated and temperature compensated
• Stainless steel construction
• Wider operation temperature range
• Variety of Pressure & Electrical connections
• Output 4.20mA, 0.10V, 0.5V and others

Applications :

• Process control systems
• Refrigeration and HVAC controls
• Hydraulic systems and valve
• Machine building
• Pumps and compressors

Product Overview :

• TFP-310 is made from high-quality silicon piezoresistive chip. All process connections of the fush pressure transmitter are made of stainless steel, fully welded and isolate the process medium from the pressure measuring instrument via a positive seal. The TFP-310 is precision engineered to fit food, pharmaceutical and chemical liquid pressure measurement.
• A wide range of process connection and electrical connection options are available to meet almost requirement.

Features :

• Measuring ranges from 1bar to 100bar
• Absolute, gauge and sealed gauge
• Accuracy - ±0.25%FSO or ± 0.5%FSO
• Calibrated and temperature compensated
• Flush diaphragm construction
• Piezoresistive pressure sensor design
• Variety of Pressure & Electrical connections
• Output 4.20mA, 0.10V, 0.5V and others

Applications :

• Process control systems
• Food and beverage
• Medical
• Papermaking
