Machine And Precision Tools

We offer a complete product range of All Geared Vertical Milling Machine

All Geared Vertical Milling Machine

All Geared Vertical Milling Machine
₹ 100 Lakh / piece Get Latest Price
  • Min. Order (MOQ) 1 Piece
  • Usage Industrial
  • Material Stainless Steel
  • Driven Type Electric
  • Certification CE Certified
  • Country of Origin 220V
  • Total Carbohydrate 1 Year
  • Number Of Flower Automatic

SALIENT FEATURES

  • Convenient & User Friendly Design.
  •  Highly Rigid Casting Frame.
  • Superior Quality Casting with Chemical Compositions.
  • Independent Motor Drives for Spindle & Feeds.
  • Single Lever Control for Rapid & Feeds.
  • Massive Range of Spindle Speeds & XYZ Axis Feeds
  • l Dip Gear Boxes
  • XYZ Axis can be run Automatically as well as Manually.
  • Fully Reliable Hardened Gears and EN Alloy Steel Shafts/ Acme Screws.
  • All parts are Interchangeable with Standard Designs.
  • ISI/CE Marked Electrical.



STANDARD EQUIPMENTS:

Draw Bar, Electrical Control Panel with Switch Box & Motors, Machine Lamp, Bellow Guards, Base Splash Tray



OPTIONAL EQUIPMENTS:

Dividing Head, Rotary Table, Milling Machine Vice, DRO (Digital Read Out), Electric Coolant Pump & whichever not mentioned in standard

Specifications

MODEL VMG 700 VMG 850 VMG 1100 VMG 1200 VMG 1300
Work Table Size 1350×300 1600×350 1900×400 2100X400 2300×500
Swivel of Table ±45° ±45° ±45° FIX FIX
T-Slot Nos. / Bolt Size 3/M16 3/M16 5/M16 5/M20 5/M20
T-Slot Centre Distance 70 90 80 90 95
Distance From Spindle to Table max/min 350-60 425-75 475-75 575-75 625-75
X-Longitudinal Table Travel 700 850 1100 1200 1300
Y-Cross Table Travel 225 325 450 500 550
Z-Knee Vertical Travel 410 500 600 650 700
Table Loading Capacity in (kgms.) 350 700 1100 1800 2500
FEEDS & RAPIDS IN X-Y-Z AXIS
No. of Feeds 18 18 18 18 18
Range of Longitudinal Feed/min 10 to 500 10 to 500 10 to 500 10 to 500 10 to 500
Range of Cross Feed /min 10 to 500 10 to 500 10 to 500 10 to 500 10 to 500
Range of Vertical Feed /min 251012 251012 251012 251012 251012
No. Of Rapid Traverse 1 1 1 1 1
Longitudinal Rapid Feeds / min 1500 1500 1500 1000 1000
Cross Rapid Feeds/ min 1500 1500 1500 1000 1000
Vertical Rapid Feeds/min 375 375 375 350 350
SPINDLE DETAILS
No of Spindle Speeds 12 12 12 12 12
Range of Spindle Speeds (RPM) 45-1120 45-1120 45-1120 45-1120 45-1120
Spindle Taper Standard ISO 40 ISO 40 ISO 40 ISO 40 ISO 40
Quill Travel Manual (mm) 95 95 95 95 95
ELECTRICAL
Spindle Motor/ RPM’s 3HP/ 1440 5 HP/ 1440 7.5 HP/1440 10 HP/ 1440 10 HP/ 1440
XYZ Axis Feed Motor 2kw 2kw 3kw 4kw 4kw
Coolant Motor 0.1 HP 0.1 HP 0.1 HP 0.1 HP 0.1 HP
FLOOR & PACKING DIMENSIONS (APPROX.)
Overall Length 2000 2050 2500 2700 2700
Overall Width 1750 1950 2500 2600 2700
Overall Height 1800 1880 2400 2700 2800
Net Weight kgms. 2500 3500 4200 5500 7000
Gross Weight with Wooden Packing 3500 4600 5500 6800 8500
