Our Products
Our offered Product range includes 3D/4D Ultrasound Machines SY-A024, Medical 4D Color Ultrasound Scanner Portable Color Doppler Ultrasound Machine, Medical 3D/4D Ultrasound Machine, 15 Inch LED Touch Screen Ultrasound Scanner SY-A034 and Ophthalmic B Scan Eye Examination Ultrasound Equipment. SY-A041.
Appearance
Smart, compact and clamshell design
12inch LEDmonitor
Backlit operation panel, 8TGC
Floating keyboard
Two active probeconnectors
Twoprobeholders
Probe
TransducerTypes
Electronic convexprobe
Electronic linearprobe
Electronic micro convexprobe
Electronic transvaginalprobe
Electronic phased arrayprobe
4D volume probe
Applications
Abdomen, Obstetrics, Gynecology, Pediatrics, Smallparts, Artery, Superficial organ, Orthopedics, Cardiology, Musculoskeletal, Vascular, etc
Function
Auto Image Optimization
Tissue Harmonic imaging
iClear(Speckle Noise Reduction)
iBeam(Spatial Compound Image)
iZoom
PIHI(Pulse-Inverse Harmonics Imaging)
SA(Synthetic Aperture Synthesis)
Panoramic Image(Option)
Trapezoid Image(Option)
Continuous Wave Doppler(Option)
Displaymode
B, BB, 4B, BM, M, BD, PW, BPW, CW, CF
Triplexmode
4D mode
PowerRequirements
Voltage: AC 100V to240V10%
Frequency: 50Hz1Hz
Rated Power:250VA
Dimension
Grossdimension:
510 mm X 500 mm X 330mm
Netdimension:
330mm X 150mm X380mm
SY-A024 Color Doppler USG is a very high cost-effective device, for it with good image, powerful functionsand also pretty appearance, but price is inexpensive.It with a large volume hardisk so can store many image and video, and can make a detail report directlynot need connect to computer and make on computer, and can work with general ink or laser printerso the printer cost is low.We believe you will like it, and it can bring benifits to your work.
Feature of USG :CFM, PDI, DPDI, PWD, Duplex, Triplex, HPRF, THIHigh definition imageVery thin, light and pretty15inch LED ScreenBuilt-in Battery3D imaging(option)Abundant functions, MultilingualHardisk, USB storage
Specifications of USG :1. Imaging Modes:B, BB, 4B, BM, MColor Doppler (CFM)Power Doppler (PDI)Directional Power Doppler (DPDI)Pulsed Wave Doppler (PWD)B+PWD (Duplex)B+CFM/PDI/DPDI+PWD (Triplex)High Pulse Repetition Frequency (HPRF)Tissue Harmonic Imaging (THI)
2. Scanning Method:
electronic linear, electronic convex, electronic micro-convex, scanning depth: 2-24cm
3. Color Doppler:PRF variable: 0.5-9 kHzwall filter settings: 3 steps (5%, %10%, 15% PRF)angle steering for linear transducers: 10real-time spatial filter: 4 valuesCFM palette>10 mapsPDI palette>10 mapsB/Color priority controlcolor threshold controlCFM baseline controlDoppler frequency selectioncolor frame averagingTransparent Color Mapping (TCM)
4. Pulsed Wave Doppler:PRF variable: 1-10 kHzwall filter settings: 16 steps (2.5%-20% PRF)angle steering for linear transducers: 10real-time trace line with automatic calculation of spectrum parametersstereo sound: volume controlPWD palette>10 mapsDoppler frequency selection
5.Processing:High Line Density scan mode for better resolution8 sliders TGC Controldynamic range>120 dBoverall gain controlM mode sweep speed controlacoustic power controlvariable frame averagingbrightness, contrastadvanced gamma controlscan direction, rotation, up-down controlsnegative / positive controlecho enhancement controlnoise rejection functionspeckle reduction
6. Image and video: AVI, JPG, BMP, PNG, TIF, DCM (DICOM)
7. General Measurements and Calculations: Distance, Length, Area, Circumference, Volume, Angle,
Stenosis %, A/B Ratio, Velocity, Pressure Gradient (PG), Acceleration, Resistivity Index (RI),
Heart Rate, Velocity Time Integral (VTI), etc.
8. Measurements and Calculations Software Packages: Obstetrics, Gynecology, Abdominal,
Urology, Endocrinology, Vascular, Cardiology, etc.
9. Expansion interfaces:VGA, TV InterfaceUSB2.0 InterfaceRJ-45 Network interfaceSupport DeskJet printer, LaserJet printer, video printer
Standard Configuration:Host 1 unit; Convex probe 1 pcs; Lienar or Trans-vaginal probe 1 pcs
Packing size:53*53*25cm 15kg
