Finger Print Scanner Specification :
- Fingerprint scanning window is 15.24×20.32mm
- Image Resolution is 300×400 pixel, 500DPI
- Image format is 8 bit 256 grayscale
- Raw fingerprint image file size is 150K byte
- Operation temperature: -10 to +55 Degree Celsius
- FBI PIV.071006 & Mobile Support
- ID FAP 20, INCIT5378, Bio API, ISO / IEC1974-2 Support
- ISO/IEC1979-4 Support
- Compliance : FCC, CE, RoHS, F2PS201 (HSPD-12)
- STQC Certified Scanner to meet Technical Specifications as defined by UIDAI
Mobile Smart & Magnetic Card Reader with Pinpad Feature
- Manual-insertion type reader
- ISO7811 Certified Magnetic Reader
- ISO7816 Certified Smart Card Reader
- EMV L1/EMV L2 certificated
- 16 key pad made of high quality & long life silica gel
- Support DES/3DES/AES/DUKPT encryption
