Min. Order (MOQ)
1 Set(s)
We are offering grg5h infrared carbon dioxide sensor.Instrument has advantages of measuring accuracy, fast response speed, long calibration cycle, is not affected by other gases, wide measuring range, low power consumption, long service life, stable performance, high reliability, etc.Basic parameters of projectco2 measurement range:(0.000.50)co2(0.505.00)co2basic error :0.10co2(0.05+5of true value)co2resolution: not less than 0.01% co2corresponding time 25 s or lessworking power: dc9v 24 v 95 ma. (mkd-i)alarm way intermittent sound, optical signal, optical signal visibility of not less than 20 m in the darkremote control distance: 5 m or lesstransmission distance: 2 km or lessthe output signal frequency (200 1000 hz); greater than 3 v output level (load resistance > 1.5 k )digital signal rs4851200bps 9600 bps are optionalmine intrinsically safe explosion-proof way, explosion-proof marks: exibiworking temperature 0 and 40 the relative humidity : 98% or less (+ 25 )storage temperature: 20 to + 50 installation dimensions: 260 mm *120 mm *50 mmweight: 1 kg or less
Additional Information:
Payment Terms :
T/T
Delivery Time : 7 days
Jining, Shandong, China
