We offer the best product range of Smgz Series Tunnel Anchor Drilling Rig, kqzdx series crawler type air-hydraulic linkage drilling rig, HZD-P Horizontal Water Grinding Drilling Rig, Dzc Series Loader-Mounted Guardrail Pile Driver and Gfdd Series Photovoltaic Ground Nail Drilling Rig.
SMGZ Series Tunnel Anchor Drilling Rig
1. Introduction to SMGZ Series Tunnel Anchor Drilling Rig
The tunnel anchor drilling rig is a tunnel-specific engineering machinery equipment developed based on the construction needs of drilling and anchoring operations in tunnels. It is mainly used to accurately drill holes in the tunnel surrounding rock and assist in the installation of anchor rods, anchor cables and other supporting structures, and cooperate with grouting to enhance rock stability, prevent collapse, and ensure construction safety. The excellent operability combined with powerful power can significantly improve construction efficiency and operation accuracy, and has been recognized by the majority of construction units.
2. Features of SMGZ Series Tunnel Anchor Drilling Rig
2.1 All-round drilling: The drilling frame can rotate 360, which can realize all-round anchoring operations in the tunnel.
2.2 Diversified operation modes: Equipped with high-performance dual hydraulic power heads or automatic impact rock drill heads to achieve diversified operations.
2.3 Diversified configuration: The basket arm can be configured to provide a lifting platform for auxiliary work such as charging, clearing hazards, hanging nets, etc., reducing the tedious work of scaffolding and greatly improving the safety and efficiency of construction.
2.4 Easy to move: It adopts crawler-type walking mode, which can adapt to the complex ground in the tunnel and can be flexibly maneuvered in narrow spaces.
2.5 Strong adaptability to terrain conditions: Suitable for various soil and rock conditions, showing strong environmental adaptability.
1. Introduction toKQZDX Series Crawler Type Air-hydraulic Linkage Down-the-hole Drilling Rig
KQZDX series crawler air-hydraulic linkage down-the-hole drillingrig is a highly efficient and flexible small open-pit crawler rock drilling equipment. It uses compressed air to drive the impactor to generate high-frequency impact force on the drill bit. At the same time, the hydraulic motor drives the drill bit to rotate at high speed to achieve efficient rock crushing. It can adapt to a wide range of strata from soft rock to extremely hard rock. It is mainly used in open-pit mine blasting holes, large-scale stone engineering, water conservancy and hydropower construction and other fields.
2. Features ofKQZDX Series Crawler Type Air-hydraulic Linkage Down-the-hole Drilling Rig
2.1 Equipped with crawler walking chassis, no need for manual movement, making it more convenient to move the machine.
2.2 The drilling rig is advanced and lifted by hydraulic cylinder, which makes the work more efficient.
2.3 The drilling frame angle can be adjusted to achieve 35-90 multi-angle drilling construction.
2.4 The power head can rotate forward, reverse and inching to meet various construction requirements.
2.5 The drilling rig is simple and easy to learn, and novices can quickly get started, reducing dependence on manual labor.
2.6 Made of high-strength materials, it has good wear resistance and impact resistance, reducing the cost of repairing and replacing equipment.
HZD-P Horizontal Water Grinding Drilling Rig
1.Introduction to HZD-P Horizontal Water Grinding Drilling Rig
The HZD-P horizontal water grinding drilling rig integrates high-pressure water flow and diamond circular cutting technology, which can efficiently penetrate reinforced concrete and hard rock formations, achieving precise drilling and coring. It is an environmentally friendly, low-disturbance, and highly adaptable horizontal drilling equipment. When used with a splitting rod, it can quickly promote tunnel excavation, specializing in mountain tunnel drilling and tunnel construction fields. Meanwhile, it is widely applied in scenarios such as trenchless pipeline laying, municipal pipe jacking, and building structure drilling. With its efficient drilling performance and excellent cost-effectiveness, it has won the favor of numerous construction and tunnel construction units.
2.Features of HZD-P Horizontal Water Grinding Drilling Rig
2.1 The drilling rig can drill at 360 in the forward direction, easily excavating arched or circular tunnels in mountain bodies.
2.2 It is simple and labor-saving to operate, without the need for a large number of workers.
2.3 Compared with large excavation equipment, it has the same function but is inexpensive.
2.4 It features low vibration, low noise, and less dust, reducing harm to the ecological environment and surrounding people.
2.5 The structure of the drilling rig can be customized according to customers ' construction requirements.
DZC Series Loader-Mounted Guardrail Pile Driver
1.Introduction to DZC Series Loader-Mounted Guardrail Pile Driver
The DZC series loader-mounted guardrail pile driver is a vehicle-mounted piling equipment developed based on the needs of the highway piling market. It integrates functions such as piling and pile extraction, with mature technology. It is widely used in piling operations for wooden piles, metal piles, and other pile types on pure soil pavements such as expressways, national highways, provincial highways, and county roads. When equipped with an air compressor and a drilling rig, the pile driver can perform drilling operations in high-hardness formations such as rocks and concrete, achieving multi-purpose functionality with one machine. It significantly reduces labor costs and improves construction efficiency, making it a core equipment in modern highway construction.
2.Features of DZC Series Loader-Mounted Guardrail Pile Driver
2.1 Adopts a technologically mature loader as the chassis, enabling fast transfer and stable performance.
2.2 The electrical, hydraulic, control, and monitoring instruments of the entire machine are centralized in the cab, ensuring convenient operation.
2.3 The pile driver 's portal frame can tilt forward, backward, and translate left and right, making it easy to achieve vertical piling on sloped ground.
2.4 Equipped with outrigger cylinders, it can realize precise piling without displacement.
GFDD Series Photovoltaic Ground Nail Drilling Rig
1. Introduction toGFDD Series Photovoltaic Ground Nail Drilling Rig
The GFDD series photovoltaic ground nail drill is a mechanical equipment specially used for ground nail installation and drilling operations in the construction of photovoltaic power stations. It adopts a crawler design and can move flexibly on various terrains. It is particularly suitable for construction in complex terrains such as mountains and slopes.
2. Features of GFDD Series Photovoltaic Ground Nail Drilling Rig
2.1 Equipped with a powerful power system and efficient hydraulic transmission device, it can quickly and accurately drive the ground nails into the ground, significantly improving construction efficiency.
2.2 Equipped with hydraulic radiator to ensure the drilling rig can work safely for a long time.
2.3 Equipped with crawler walking chassis, no manual movement is required, making the machine more convenient to move.
2.4 The drilling rig is propelled and lifted by hydraulic cylinders, which makes the work more efficient.
2.5 The operation is simple and centrally controlled through the operating console, making it convenient for users to control and adjust.
1Introduction toQYD Series Crawler Fully Hydraulic Core Drilling Rig
QYD series crawler fully hydraulic core exploration drilling rig adopts rope core drilling rig with full hydraulic power head drilling method, and the core drilled by the drilling tool is lifted out by the winch through the inner hole of the drill pipe to complete the geological drilling core work. It is mainly suitable for drilling solid ore deposits, and can also be used for engineering geology, shallow oil, natural gas, groundwater drilling, and engineering drilling such as tunnel ventilation, drainage and dike grouting.
2Features of QYD Series Crawler Fully Hydraulic Core Drilling Rig
2.1 Equipped with a wireless remote control, the drilling rig can be remotely controlled to prevent sudden dangers.
2.2 The rig is fully hydraulic driven, and the hydraulic system adopts load sensitive control, with high working efficiency and high torque.
2.3 The power head rotation is driven by axial piston pump and inclined shaft piston motor, and the mechanical two gears plus stepless speed regulation, advanced structure.
2.4 Adopts cylinder chain double speed feeding mechanism, stable and reliable movement, and with power head side translation mechanism.
2.5 Hydraulic gripper to achieve clamping drill pipe, with drill pipe disassembly.
2.6 Hydraulic motor driven hoist, can be flexible lifting drilling tools or auxiliary tools.
2.7 The rig adopts the touchdown base for touchdown fixation, making drilling more stable.
2.8 The use of air cooling and water cooling, more diversified way, can ensure the long time operation of the machine.
KY Series Metal Mine Prospecting DrillingRig
1.Introduction to KY Series Metal Mine Prospecting Drilling Rig
KY series fullyhydraulic exploration drilling rig is a kind of exploration equipment used in mine tunnel or surface, which has been widely used in the field of metal mines. When the drill is used in the tunnel, it can be drilled 0-360 degrees on the column and 0-90 degrees on the surface drilling frame.
2.Features ofKY Series Metal Mine Prospecting Drilling Rig
2.1 The drilling rig is composed of the main engine, pump station and operation platform, with flexible layout.
2.2 Small size, light weight and convenient installation.
2.3 Good decomposition and convenient transportation.
2.4 It can be put into production in the original tunnel, which plays a protective role in the overall structure of the mine.
2.5 Adopt light feeding frame, clamp, power head rotary drilling, oil cylinder pulling and sending drilling tools, which can save heavy derrick.
2.6 Mechanical principle twist and unload drill pipe, reduce labor intensity of workers and improve work efficiency.
2.7 It has the function of linkage. It can be operated in a centralized way through the control console. It is simple and safe, and it can adjust speed infinitely.
2.8 The 33 and 43 drill pipes can be used in the same machine, and the replacement is con.
BXZ Series Backpack Core Drilling Rig
1Introduction toBXZ Series Backpack Core Drilling Rig
BXZ series backpack drilling rig is a portable core drilling rig with backpack, which is mainly suitable for borehole sampling in shallow geological exploration such as mineral exploration, geological research and engineering exploration in mountainous areas where transportation and energy are inconvenient.
2Features of BXZ Series Backpack Core Drilling Rig
2.1 Compact structure, small size, light weight, easy to carry.
2.2 Using well-known brand gasoline engine, energy saving and high efficiency, the quality of drilling rig is guaranteed.
2.3 Equipped with high quality drill pipe and bit, it is durable and more efficient.
3Parametersof BXZ Series Backpack Core Drilling Rig
| Model | BXZ-1 | BXZ-1L | BXZ-1C | BXZ-2 | BXZ-2L |
| Style | One-person handrail | Steel column type | One-person handrail | Two-person handrail | Steel column type |
| Engine brand | Mitsubishi | Mitsubishi | Hengyue | Kohler | Kohler |
| Power | 3.2HP | 3.2HP | 3HP | 7.75HP | 7.75HP |
| Drill pipe | 32*700mm | 32*700mm | 25*800mm | 32*700mm | 32*800mm |
| Hole diameter | 33-46mm | 33-46mm | 26-36mm | 33-120mm | 33-120mm |
| Max.sampling depth | 20m | 20m | 15m | 20m | 30m |
| Host weight | 8kg | 25kg | 12kg | 30kg | 50kg |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
KY-6075 Fully Hydraulic Steel Cable Coring Exploration Drilling Rig
1.Introduction of KY-6075 Fully Hydraulic Steel Cable Coring Exploration Drilling Rig
KY-6075 fullyhydraulic exploration drilling rig can meet the most advanced steel strand wire core drilling technology. In the process of drilling, when the core is full of the inner pipe of the core, there is no need to lift the drill pipe, but take the drill pipe as the channel to lift the inner pipe of the core stored outside the hole with the help of prestressed steel strand and special fishing tools to obtain the core. In view of the characteristics of high strength and small deformation of prestressed steel strand, the steel strand wire core drilling rig can achieve 360 all-round drilling.
2.Features of KY-6075 Fully Hydraulic Steel Cable Coring Exploration Drilling Rig
2.1 In the process of drilling, it is unnecessary to lift the core, and 360 core drilling can be realized.
2.2 Reduce the auxiliary time of lifting drill pipe and increase the pure drilling time. The deeper the borehole is, the more significant the economic effect is.
2.3 If the core is blocked, it can be immediately fished out to improve the core recovery rate.
2.4 lt can reduce the wear of drill pipe thread during screwing and unloading, and the wear of bitcleaning, prolong the service life of drill pipe and reduce the consumption of pipe material.
2.5 Reduce flushing fluid suction and hole wall pressure balance, so as to reduce accidents in thehole.
2.6 Reduce the mechanical wear of lifting and delivering drill pipe, and increase the service life ofthe drill.
2.7 Reduce borehole curvature and improve borehole quality.
2.8 It is conducive to drilling compiex stratum and avoiding hoie wait coliapse and biock faiing.
2.9 The inclinometer can be set in the drill pipe with steel strand wire to measure the inclinometer.
1. Introduction toKQZ Series Air-electric Down-the-hole Drilling Rig
The KQZ series air-electric down-the-hole drillingrig is a highly efficient rock drilling equipment. It uses compressed air to drive the impactor to generate high-frequency impact force on the drill bit. At the same time, the electric motor drives the drill bit to rotate at high speed to achieve efficient rock crushing. It is an efficient and reliable choice for hard rock deep hole operations. It is mainly used in open-pit mine blasting holes, large-scale stone projects, water conservancy and hydropower construction and other fields.
2. Features of KQZ Series Air-electric Down-the-hole Drilling Rig
2.1 High-efficiency drilling: The impact drilling method is adopted, and the impact energy directly acts on the drill bit at the bottom of the hole, with small energy transfer loss, which greatly improves the drilling efficiency.
2.2 Good drilling quality: the drilled hole is straighter, the hole wall is smoother, and the drilling accuracy is higher.
2.3 Strong adaptability: It can adapt to a wide range of strata from soft rock to extremely hard rock.
2.4 Simple operation: The drilling rig is easy to operate and novices can quickly get started, reducing manual dependence.
2.5 Durable: Made of high-strength materials, it has good wear resistance and impact resistance, can operate stably for a long time, and reduces the cost of repairing and replacing equipment.
YQZ-50B Hydraulic Light Core Drilling Rig
1Introduction toYQZ-50B Hydraulic Light Core Drill Rig
YQZ-50B hydraulic portable drilling rig is a kind of small-scale sampling drilling equipment suitable for plain and mountainous areas and areas with inconvenient transportation and energy resources. It is widely used in railway, water conservancy and other construction projects as well as geological core drilling and small grouting holes in field mountainous areas.
2Features of YQZ-50B Hydraulic Light Core Drilling Rig
2.1 With oil pressure automatic feeding mechanism, high drilling efficiency
2.2 The ball clamping mechanism and hexagonal active drill pipe are used to realize rod reversing without stopping the machine
2.3 The drilling rig is equipped with hydraulic winch, which can be used together with the drilling tower to lift the
2.4 Equipped with 4-speed transmission system. It is convenient for the operator to adjust the forward rotation speed freely according to the geological conditions. In addition, it is equipped with a slow reverse gear, which is convenient for the operator to disassemble the drill pipe and drill pipe.
2.5 The handle is centralized, easy to operate, safe and feasible.
2.6 It is equipped with pressure gauge at the bottom of the hole to indicate the pressure, so as to master the situation in the hole.
2.7 The drilling rig is equipped with a shifting slide way, which can quickly replace the drilling tools and save time and effort.
2.8 Compact structure, small size, light weight, small footprint.
2.9 It has strong decomposition ability and is easy to be relocated. It is suitable for complex terrain.
3Parametersof YQZ-50B Hydraulic Light Core Drilling Rig
| Model | YQZ-50B |
| Boreholedia. | 75mm |
| Samplingdepth | 50m |
| Drill pipe | 42mm |
| Vertical shaftspeed | 70-650rpm(1-3 Gear) |
| Reversespeed | 50-130rpm(R Gear) |
| Liftingforceofwinch | 500kg |
| Cylinderstroke | 600mm |
| Transferstroke | 200mm |
| Main enginepower | Diesel engine R180 |
| Drillsize | 1400*950*1250mm |
| Weight | 340kg |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
LSMGZ Series Wheeled Tunnel Anchor Drilling Rig
1. Introduction to LSMGZ Series Wheeled Tunnel Anchor Drilling Rig
The wheeled tunnel anchor drilling rig is a tunnel-specific engineering machinery equipment developed based on the construction needs of drilling and anchoring operations in tunnels. It is mainly used to accurately drill holes in the tunnel surrounding rock and assist in the installation of anchor rods, anchor cables and other supporting structures, and cooperate with grouting to enhance rock stability, prevent collapse, and ensure construction safety. The excellent operability combined with powerful power significantly improves construction efficiency and operation accuracy, and has been recognized by the majority of construction units.
2. Features of LSMGZ Series Wheeled Tunnel Anchor Drilling Rig
2.1 Omnidirectional drilling: The drilling rig can rotate 360, enabling all-round anchoring operations in the tunnel.
2.2 Diversified operating modes: Equipped with high-performance dual hydraulic power heads or automatic impact rock drill heads to achieve diversified operations.
2.3 Configuration diversity: The basket arm can be configured to provide a lifting platform for auxiliary work such as charging, clearing hazards, hanging nets, etc., reducing the tedious work of scaffolding and greatly improving the safety and efficiency of construction.
2.4 Easy to move: It adopts tire-type walking method, which makes it more convenient to move to other places.
2.5 Strong adaptability to terrain conditions: Suitable for various soil and rock conditions, showing strong environmental adaptability.
KQZD Series Down-the-hole Drilling Rig
1. Introduction to KQZD Series Down-the-hole Drilling Rig
The KQZD series down-the-hole drilling rigis an efficient and flexible open-pit crawler rock drilling equipment. It transmits impact energy to the drill bit through the impactor. The drill bit rotates at high speed while impacting the rock at high frequency. Compressed air discharges the drilled rock cuttings out of the hole, realizing the synchronous operation of "impact-rotation-slag discharge ". The down-the-hole drilling vehicle has excellent mobility and off-road capability, adapts to all-terrain operations, and can quickly and flexibly transfer in complex terrain. It is mainly used in open-pit mine blasting holes, large-scale stone engineering, water conservancy and hydropower construction and other fields.The Jujiang down-the-hole drill rig is an efficient and reliable choice for hard rock deep hole operations
KQZ Series FullyPneumatic Down-the-hole Drilling Rig
1. Introduction toKQZ Series Fully Pneumatic Down-the-hole Drilling Rig
The KQZ series fully pneumatic down-the-hole drilling rigis a highly efficient rock drilling equipment. It uses compressed air to drive the impactor to generate high-frequency impact force on the drill bit. At the same time, the pneumatic motor drives the drill bit to rotate at high speed to achieve efficient rock crushing. It is an efficient and reliable choice for hard rock deep hole operations. It is mainly used in open-pit mine blasting holes, large-scale stone projects, water conservancy and hydropower construction and other fields.
2. Features of KQZ Series FullyPneumatic Down-the-hole Drilling Rig
2.1 High-efficiency drilling: The impact drilling method is adopted, and the impact energy directly acts on the drill bit at the bottom of the hole, with small energy transfer loss, which greatly improves the drilling efficiency.
2.2 Good drilling quality: the drilled hole is straighter, the hole wall is smoother, and the drilling accuracy is higher.
2.3 Strong adaptability: It can adapt to a wide range of strata from soft rock to extremely hard rock.
2.4 Simple operation: The drilling rig is easy to operate and novices can quickly get started, reducing manual dependence.
2.5 Durable: Made of high-strength materials, it has good wear resistance and impact resistance, reducing the cost of repairing and replacing equipment.
1. Introduction toJFD Series Crawler Reverse Circulation Water Well Drilling Rig
The rotary water well drilling rig with reverse circulation well washing medium is referred to as reverse circulation drilling rig. Its core lies in the unique "reverse circulation " working mode. The drilling fluid naturally flows into the annular gap between the drill pipe and the well wall directly to the bottom of the well, and then carries the cut drill cuttings back to the wellhead through the inner cavity of the drill pipe, and is discharged to the water supply pool through the faucet and the slag discharge pipe, and is recycled after sedimentation and clarification. This "outside down and inside up " circulation method is particularly good at handling large-diameter drilling operations in complex formations such as pebbles and gravel, and has achieved efficient slag discharge capabilities far exceeding traditional drilling rigs. It is mainly used in the fields of water well drilling and engineering bored pile drilling.
2. Features of JFD Series Crawler Reverse Circulation Water Well Drilling Rig
2.1 The mud pump has strong suction, high rising flow rate, and strong pipeline slag discharge capacity. It can continuously and quickly discharge the cut drilling slag or pebbles out of the hole, reducing the number of repeated cutting or grinding and significantly improving the construction speed.
2.2 The power head has large rotation torque, which is more suitable for large-diameter drilling operations.
2.3 Equipped with crawler walking chassis, no need for manual movement, making it more convenient to move the machine.
2.4 Equipped with hydraulic legs to level the drilling rig and ensure the stability of the machine body.
2.5 There is ample driving space on the crawler chassis, making operation more convenient.
2.6 The layout of the operating handle and distribution box is compact and reasonable, which is convenient for centralized control.
2.7 The slide adopts heavy-duty structural design, and the key parts are shock-proof and wear-resistant, with a long service life and low failure rate.
3. Parameters of JFD Series Crawler Reverse Circulation Water Well Drilling Rig
| Drilling rig specifications | JFD-5 | JFD-6 | JFD-6S | JFD-7S |
| Drilling diameter | 300-1000mm | 500-1500mm | 500-1800mm | 500-2500mm |
| Drilling depth | 40-80m | 20-100m | 30-200m | 30-200m |
| Drill pipe specifications | 140*2000mm | 168*2000mm | 168*2000mm | 194*2000mm |
| Generator power | 50kW | 50kW | 75kW | 100kW |
| Hydraulic pump motor power | 7.5kW | 15kW | 11kW | 22kW |
| Mudpump motor power | 15kW | 22kW | 30kW | 37kW |
| Rotary motor power | 7.5kW | 11kW | 5.5kW*2 | 7.5kW*2 |
| Rotation torque | 18kN | 20kN | 26kN | 30kN |
| Rotation speed | 13rpm | 13rpm | 13rpm | 10rpm |
| Vacuum pump motor power | 7.5kW | 7.5kW | 7.5kW | 11kW |
| Winch motor power | 1kW | 1kW | 1kW | 1kW |
| Maximum lifting weight of winch | 500kg | 500kg | 500kg | 500kg |
| Track chassis | Rubber Wire Track | Rubber Wire Track | Rubber Wire Track | Engineering steel tracks |
| Travel motor power | 7.5kW | 7.5kW | 7.5kW | 22kW |
| Walking style | Gearbox travel | Gearbox travel | Gearbox travel | Hydraulic travel |
| L* W* H(With generator set) | 4.2*1.9*2.4m | 4.3*2*2.2m | 4.5*2.2*2.4m | 5.5*2.4*2.6m |
| Machine weight (With generator set) | 5T | 6.5T | 7T | 10T |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
QTZ-1S Double-tubeSoil SamplingDrilling Rig
1Introduction toQTZ-1S Double-tube Soil Sampling Drilling Rig
QTZ-1S portable double-tube soil sample drilling rig is a portable soil sampling drill held by one person. The drilling rig is powered by gasoline engine, with simple operation, high safety and stable performance, and can conduct double tube sampling. In the process of double tube sampling, it can effectively avoid secondary pollution, and has no pollution and little disturbance to the sampled soil. It is a kind of high efficiency and high quality soil sampling equipment.
2Features Of QTZ-1S Double-tube Soil Sampling Drilling Rig
2.1Double tube sampling is available, which can effectively avoid secondary pollution.
2.2 Equipped with hydraulic lifting device, no need to lift the drill, saving time and labor.
2.3 Strong impact capacity and fast footage. Powerful and durable.
2.4 The drilling rig has simple structure, small volume and light weight, which is convenient for assembly, handling and disassembly.
Additional Information:
Payment Terms : D/A, D/P
1. XJ S Well Washing Machine
10
100-300
2. XJ S Well Washing Machine
2.1
2.2
2.3
2.4
2.5
3.XJ
| Model | XJ-1 | XJ-2 | XJ-3 |
|
| 76*3 | ||
|
| 3.0 / | 4.0 / | 6.0 / |
|
| 100 | 180 | 300 |
|
| 900 | 1300 | 1500 |
cjd series crawler pneumatic water well drilling rig
1introduction tocjd series crawler pneumatic water well drilling rig
cjd series crawler pneumatic water well drilling rig is a kind of pneumatic water well drill jointly developed by huaxiamaster group and jining master research institute. it is mainly used for drilling operations in hilly and mountainous areas where there are many rocks. it has the advantages of large drilling diameter, deep drilling, fast penetration, flexible movement and high efficiency. it has been widely used in industrial drilling, geothermal drilling, environmental monitoring drilling and other occasions.
2features of cjd series crawler pneumatic water well drilling rig
2.1 using the principle of pneumatic impact, the drilling footage is fast and the drilling efficiency is high.
2.2 equipped with steel crawler chassis, strong cross-country performance, easy to deal with a variety of complex working sites
2.3 equipped with hydraulic high outrigger, it is easy to load and unload the truck, save the hoisting cost, and can be used for leveling the drilling rig to maintain the stability of the fuselage
2.4 equipped with high-power diesel engine, strong power, to meet the needs of work.
2.5 equipped with hydraulic take-off and landing composite boom to save space and provide strong lifting force for deep hole operation.
2.6 the drilling rig is equipped with hydraulic feeding system, dual hydraulic motor power head, chain drive and hydraulic cylinder propulsion, with large torque and high drilling efficiency.
2.7 equipped with a quick stripper, the drill pipe can be disassembled quickly, saving time and labor.
2.8 the operation handle is centralized, reasonable in layout, safe and feasible.
2.9 excellent workmanship, durable and low maintenance cost.
3parameters of cjd series crawler pneumatic water well drilling rig
| model | cjd-260 | cjd-300 | cjd-350 | cjd-450 | cjd-500 | cjd-600 | cjd-700 |
| borehole diameter | 140-325mm | 140-325mm | 140-325mm | 140-350mm | 140-350mm | 140-350mm | 140-400mm |
| drilling depth | 260m | 300m | 350m | 450m | 500m | 600m | 700m |
| drill pipe diameter | 76/89/102mm | 76/89/102mm | 89/102mm | 89/102/108mm | 102/108/114mm | 102/108/114mm | 102/108/114mm |
| drill pipe length | 1.5/2.0/3.0m | 1.5/2.0/3.0/6.0m | 1.5/2.0/3.0/6.0m | 1.5/2.0/3.0/6.0m | 1.5/2.0/3.0/6.0m | 1.5/2.0/3.0/6.0m | 1.5/2.0/3.0/6.0m |
| one time propulsion length | 3300mm | 6600mm | 6600mm | 6600mm | 6600mm | 6600mm | 6600mm |
| main engine power | 76kw | 85kw | 91kw | 103kw | 118kw | 132kw | 153kw |
| propulsion | 8t | 8t | 8t | 18t | 18t | 23t | 23t |
| lifting power | 16t | 18t | 22t | 25t | 26t | 30t | 30t |
| working pressure | 1.7-2.5mpa | 1.7-3.0mpa | 1.7-3.4mpa | 1.7-3.5mpa | 1.7-3.5mpa | 1.7-3.5mpa | 1.7-3.5mpa |
| air consumption | 17-31m/min | 17-36m/min | 17-36m/min | 17-36m/min | 17-42m/min | 17-42m/min | 17-42m/min |
| walking speed | 2.5km/h | 2.5km/h | 2.5km/h | 2.5km/h | 2.5km/h | 2.5km/h | 2.5km/h |
| climbing ability | 30max | 30max | 30max | 30max | 30max | 30max | 30max |
| rotation speed | 40-160rpm | 40-70rpm | 66-135rpm | 50-135rpm | 40-130rpm | 45-140rpm | 45-140rpm |
| slewing torque | 5000n.m | 5700-7500n.m | 6200-8500n.m | 7000-9500n.m | 7500-10000n.m | 8500-11000n.m | 8850-13150n.m |
| dimensions | 3950*1850*2850mm | 4100*2000*2500mm | 6000*2000*2550mm | 5950*2100*2600mm | 6200*2200*2650mm | 6200*2200*2650mm | 6300*2300*2650mm |
| total weight | 5.5t | 7.2t | 9t | 9.4t | 11.5t | 12t | 13t |
note: products are constantly being improved. any changes will not be notified separately. please refer to the actual product.
HUAXIAMASTER Screw Air Compressor
1.Introduction to HUAXIAMASTER Screw Air Compressor
A HUAXIAMASTER screw air compressor is a rotary positive-displacement compressor. It continuously draws in and compresses air through precisely meshed rotors to achieve efficient and stable power output. With excellent power performance, the machine can work normally in harsh environments such as extreme cold and heat. It is widely used in engineering fields like mining, water conservancy projects, tunnel engineering, road and bridge construction, etc., due to its outstanding performance.
2.Features of HUAXIAMASTER Screw Air Compressor
2.1 Strong Adaptability: The forced gas transmission design ensures a stable volumetric flow even when the discharge pressure fluctuates, adapting to the needs of complex working conditions.
2.2 Low-Noise Operation: The high-precision rotors and silent outer cover design effectively reduce mechanical friction and operating noise.
2.3 Excellent Performance: Equipped with high-performance power, it delivers stable output.
2.4 High Efficiency and Energy Saving: The screw compression has high efficiency with little energy loss, supports high-pressure output, and significantly reduces energy consumption.
2.5 Durable: It features a simple structure, easy maintenance, and a long service life.
2.6 Easy Operation: With a high degree of automation, operators can quickly get started after simple training.
2.7 Convenient Mobility: It can be equipped with a tire or crawler chassis, facilitating transportation and transfer in various terrains.
1Introduction to ARC Series Air Reverse Circulation Drilling Rig
ARC series air reverse circulation drilling rig is a new, efficient and environmentally friendly geological drilling equipment. It uses the latest air reverse circulation drilling technology from Master Research Institute, compressed air is used as the circulating medium to quickly dischargethe cuttings from the bottom of the hole through reverse circulation.Rock cuttings and dust are effectively collected and sorted through dust collectorsavoid sample contaminationensure the accuracy of sample data.The drilling rig is mainly used in mineral exploration, hydrogeological exploration, engineering geological exploration and other fields, suitable for various geographical environmentsincluding complex environments such as thin air at high altitudes, thick permafrost, and abundant groundwater. It is the preferred equipment for geological exploration drilling and other deep hole operations.
2Features of ARC Series Air Reverse Circulation Drilling Rig
2.1 Efficient drilling: The air reverse circulation drill uses a closed circulation system to quickly discharge cuttings, reduce repeated crushing, and significantly increase drilling speed.
2.2 High sample quality: The rock chip dust samples obtained through air reverse circulation drilling are free from contamination, easy to classify and track, and can accurately locate the mineralization location.
2.3 Green and environmentally friendly: Using compressed air as the circulating medium, compared with traditional mud drilling rigs, it does not require a large amount of water and chemicals during the construction process, reducing pollution to the environment.
GFQD All Terrain Photovoltaic Pile Driver
1. Introduction toGFQD All-terrain Photovoltaic Pile Driver
The GFQD all-terrain photovoltaic pile driver is a highly adaptable pile foundation construction equipment designed for the construction of photovoltaic power stations in complex terrains. It can complete pile foundation driving work in a variety of complex terrain conditions such as mountains, hills, deserts, swamps, etc. It can also choose spiral drilling, down-the-hole impact and other piling methods for construction operations according to different geological conditions. Its strong terrain adaptability, efficient piling ability and intelligent design can significantly improve construction efficiency and quality.
2. SPJ S G Disc Water Well D Rig
3.SPJ S G Disc Water Well D R IG
|
| SPJ-400 | SPJ-6 00 | SPJ-10 00 |
|
| 500 -1800 | 500 -2500 | 500 -2500 |
|
| 50-400 | 50 -600 | 50 1000 |
|
| 108 * 108 * 12 | 108 * 108 * 12 | 133 * 133 * 12 |
|
| 89 | 89 | 89 /114 |
|
| 32 | 60 | 60 |
|
| 18 | 20-21.5 | 20-21.5 |
|
| 150 | 240 | 280 |
|
| 15 | 32 | 32 |
|
| 14 | 18 | 18 |
|
| 150 | 150 | 280 |
|
| 500 | 605 | 670 |
|
| 4070128/ | 5070128/ | 366090130/ |
|
| A | A | A |
|
| 13 | 13 | 18 |
|
| 9 | 11 | 15 |
|
| 6000 * 2200 * 13000 | 6000*4000*13500 | 6000*4500*18000 |
1. Introduction toKQZDX Series Crawler Air-electric Linkage Down-the-hole DrillingRig
KQZDX series crawler air-electric linkage down-the-hole drillingrig is a highly efficient and flexible small open-pit crawler rock drilling equipment. It uses compressed air to drive the impactor to generate high-frequency impact force on the drill bit. At the same time, the electric motor drives the drill bit to rotate at high speed to achieve efficient rock crushing. It can adapt to a wide range of strata from soft rock to extremely hard rock. It is mainly used in open-pit mine blasting holes, large-scale stone engineering, water conservancy and hydropower construction and other fields.
2. Features of KQZDX Series Crawler Air-electric Linkage Down-the-hole DrillingRig
2.1 Equipped with crawler walking chassis, no need for manual movement, making it more convenient to move the machine.
2.2 The drilling rig is advanced and lifted by hydraulic cylinder, which makes the work more efficient.
2.3 The drilling frame angle can be adjusted to achieve 35-90 multi-angle drilling construction.
2.4 The power head can rotate forward, reverse and inching to meet various construction requirements.
2.5 The drilling rig is simple and easy to learn, and novices can quickly get started, reducing dependence on manual labor.
2.6 Made of high-strength materials, it has good wear resistance and impact resistance, reducing the cost of repairing and replacing equipment.
CJDX Series Crawler Pneumatic Water Well Drilling Rig
1Introduction toCJDX Series Crawler Pneumatic Water Well Drilling Rig
CJDX series crawler pneumatic water well drilling rig is a kind of pneumatic water well drill jointly developed by HUAXIAMASTER GROUP and Jining Master Research Institute. It is mainly used for drilling operations in hilly and mountainous areas where there are many rocks. It has the advantages of large drilling diameter, deep drilling, fast penetration, flexible movement and high efficiency. It has been widely used in industrial drilling, geothermal drilling, environmental monitoring drilling and other occasions.
2Features Of CJDX Series Crawler Pneumatic Water Well Drilling Rig
2.1 Using the principle of pneumatic impact, the drilling footage is fast and the drilling efficiency is high.
2.2 Equipped with rubber steel wire tracks, it is easy to move, and it will not hurt the road surface when walking on urban roads.
2.3 Equipped with hydraulic high outrigger, it is easy to load and unload the truck, save the hoisting cost, and can be used for leveling the drilling rig to maintain the stability of the fuselage
2.4 Equipped with high-power diesel engine, strong power, to meet the needs of work.
2.5 Equipped with hydraulic take-off and landing composite boom to save space and provide strong lifting force for deep hole operation.
2.6 The drilling rig is equipped with hydraulic feeding system, dual hydraulic motor power head, chain drive and hydraulic cylinder propulsion, with large torque and high drilling efficiency.
2.7 Equipped with a quick stripper, the drill pipe can be disassembled quickly, saving time and labor.
2.8 The operation handle is centralized, reasonable in layout, safe and feasible.
2.9 Excellent workmanship, durable and low maintenance cost.
3Parameters of CJDX Series Crawler Pneumatic Water Well Drilling Rig
| Drilling rig specifications | CJDX-160 | CJDX-200 | CJDX-230S |
| Borehole diameter | 130-203 | 140-325 | 140-325 |
| Drilling depth | 160m | 200m | 230m |
| Drill pipe diameter | 76 | 7689 | 7689 |
| Drill pipe length | 2m | 1.5m2.0m3.0m | 1.5m2.0m3.0m |
| `One time propulsion length | 2400mm | 3300mm | 3300mm |
| Main engine power | 63kW | 55kW | 65kW |
| Propulsion | 7T | 8T | 5T |
| Lifting power | 15T | 16T | 15T |
| Working pressure | 1.2-3.0Mpa | 1.7-2.5Mpa | 1.7-2.5Mpa |
| Air consumption | 10-25m/min | 17-31m/min | 17-31m/min |
| Walking speed | 2.5km/h | 2.5km/h | 2.5km/h |
| Climbing ability | 30Max | 30Max | 30Max |
| Rotation speed | 65-100rpm | 40-160rpm | 70-140rpm |
| Slewing torque | 4500N.m | 5000N.m | 6000N.m |
| Dimensions | 2540*1200*1880mm | 3850*1800*2450mm | 3250*1750*2180mm |
| Total weight | 2.8T | 4T | 5.5T |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
| Model | CJC-300 | CJC-350 | CJC-450 | CJC-500 | CJC-600 | CJC-700 |
| Borehole diameter | 140-325mm | 140-325mm | 140-350mm | 140-350mm | 140-350mm | 140-400mm |
| Drilling depth | 300m | 350m | 450m | 500m | 600m | 700m |
| Drill pipe diameter | 76/89/102mm | 89/102mm | 89/102/108mm | 102/108/114mm | 102/108/114mm | 102/108/114mm |
| Drill pipe length | 1.5/2.0/3.0/6.0m | 1.5/2.0/3.0/6.0m | 1.5/2.0/3.0/6.0m | 1.5/2.0/3.0/6.0m | 1.5/2.0/3.0/6.0m | 1.5/2.0/3.0/6.0m |
| One time propulsion length | 6600mm | 6600mm | 6600mm | 6600mm | 6600mm | 6600mm |
| Main engine power | 85kW | 91kW | 103kW | 118kW | 132kW | 153kW |
| Propulsion | 8T | 8T | 18T | 18T | 23T | 23T |
| Lifting power | 18T | 22T | 25T | 26T | 30T | 30T |
| Working pressure | 1.7-3.0Mpa | 1.7-3.4Mpa | 1.7-3.5Mpa | 1.7-3.5Mpa | 1.7-3.5Mpa | 1.7-3.5Mpa |
| Air consumption | 17-36m/min | 17-36m/min | 17-36m/min | 17-42m/min | 17-42m/min | 17-42m/min |
| Walkingspeed | 2.5km/h | 2.5km/h | 2.5km/h | 2.5km/h | 2.5km/h | 2.5km/h |
| Climbing ability | 30Max | 30Max | 30Max | 30Max | 30Max | 30Max |
| Rotation speed | 40-70rpm | 66-135rpm | 50-135rpm | 40-130rpm | 45-140rpm | 45-140rpm |
| Slewingtorque | 5700-7500N.m | 6200-8500N.m | 7000-9500N.m | 7500-10000N.m | 8500-11000N.m | 8850-13150N.m |
| Chassis | Truck chassis |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
SH30-2A Engineering Survey Drilling Rig
1Introduction toSH30-2A Engineering Survey Drilling Rig
SH30-2A engineering survey drilling rig is mainly used in the geological survey of placer gold exploration, industrial buildings, civil buildings, roads and bridges. The drilling rig has two feeding modes, impact and rotary, and customers can equip it on demand. Drilling rigs can be machined and customized to crawler type.
2Features of SH30-2A Engineering Survey Drilling Rig
2.1 Simple operation and high degree of mechanization, greatly get rid of heavy manual labor.
2.2 Light weight, compact structure, good disintegration performance, removable in mountainous areas.
2.3 Equipped with a pair of rubber wheels, in flat road can be used to achieve displacement by car towing.
3Parameters of SH30-2A Engineering Survey Drilling Rig
| Model | SH30-2A | |
| Drilling capacity | Openholedia. | 142mm |
| Endholedia. | 110mm | |
| Drillpipedia. | 42mm | |
| Drilling depth | 30m | |
| Engine | Model | D180Z |
| Power | 15hp | |
| Winch | Liftingweightmax. | 1500kg |
| Lifting speed | 0.240.571.48m/s | |
| Turntable | Caliber | 150mm |
| Speed | 1844110r/min | |
| Derrick | Height | 6m |
| Rubber wheels | Wheelspacing | 1100mm |
| Dimensions and weight | Dimension | 1780*1010*900 |
| Weight | 500kg |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
ZLJ Series Grouting Reinforcement Drilling Rig
1.Introduction to ZLJ Series Grouting Reinforcement Drilling Rig
The grouting reinforcement drilling rig is a type of engineering machinery specifically designed for drilling and grouting reinforcement operations. It integrates two core functions: drilling and grouting, and is widely used in engineering fields such as tunnels, mines, water conservancy and hydropower, subways, foundation pit support, foundation treatment, slope management, and disaster prevention. It is an indispensable key equipment in modern geotechnical engineering and geological disaster control.
2.Features of ZLJ Series Grouting Reinforcement Drilling Rig
2.1 The drilling rig integrates drilling and grouting functions, eliminating the need to replace other equipment and improving construction efficiency.
2.2 The overall design of the drilling rig is compact, making it convenient for construction in narrow spaces.
2.3 The drilling angle can be adjusted by rotating the vertical shaft to meet the needs of multi-angle grouting.
2.4 Optional rubber steel wire crawler chassis or electric three-wheeled vehicle chassis, which is convenient for moving and does not damage the road surface.
QTZ Series PortableSoil Sampling Drilling Rig
1Introduction toQTZ Series Soil SamplingDrilling Rig
QTZ series soil sampling drilling rig is a portable one-person soil sampling drilling rig, which is mainly suitable for environmental soil survey, soil structure description and so on. The drilling rig relies on the high-frequency impact force generated by itself to inject the soil extractor into the soil, and then extracts the soil extractor from the soil through the extractor.
2Features Of QTZ Series Soil SamplingDrilling Rig
2.1 Strong impact force, stable performance.
2.2 Simple operation and high safety.
2.3 There are gasoline engine models, diesel engine models, electric motor models and hydraulic pump station models, providing more variety in choices.
2.4 The drilling rig is simple in structure, small in volume and light in weight, which is convenient for assembly, handling and disassembly.
3Parameters of QTZ Series Soil SamplingDrilling Rig
| Model | QTZ-1 | QTZ-2 | QTZ-3 | QTZ-3D | QTZ-4 | QTZ-4Y |
| Engine | Gasoline engine | Two-phase electric motor | Diesel engine | |||
| Soil extractor dia | 50/70mm | |||||
| Sampling depth | 510m | 1015m | 1520m | 1520m | 2025m | 2025m |
| Host weight | 23KG | 25KG | 26KG | 22KG | 35kg | 40kg |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
1.Introduction toJFC-5 TractorMounted Reverse Circulation Water Well Drilling Rig
The rotary water well drilling rig with reverse circulation well washing medium is referred to as reverse circulation drilling rig. Its core lies in the unique "reverse circulation " working mode. The drilling fluid naturally flows into the annular gap between the drill pipe and the well wall directly to the bottom of the well, and then carries the cut drill cuttings back to the wellhead through the inner cavity of the drill pipe, and is discharged to the water supply pool through the faucet and the slag discharge pipe, and is recycled after sedimentation and clarification. This "outside down and inside up " circulation method is particularly good at handling large-diameter drilling operations in complex formations such as pebbles and gravel, and has achieved efficient slag discharge capabilities far exceeding traditional drilling rigs. It is mainly used in the fields of water well drilling and engineering bored pile drilling.
2. Features of JFC-5 TractorMounted Reverse Circulation Water Well Drilling Rig
2.1 With the tractor as the carrier, the mechanical structure technology is mature and the performance is stable.
2.2 The tractor chassis has all-terrain off-road capabilities and can be easily moved to other locations in complex terrains such as muddy fields, rugged hillsides, and narrow country roads.
2.3 The mud pump has strong suction, high rising flow rate, and strong pipeline slag discharge capacity. It can continuously and quickly discharge the cut drilling slag or pebbles out of the hole, reducing the number of repeated cutting or grinding and significantly improving the construction speed.
2.4 Equipped with hydraulic outriggers to level the drilling rig and ensure the stability of the machine body.
2.5 The well drilling rig is equipped with a generator in front, which is easy to switch between diesel and electricity.
2.6 The operating handle and distribution box are compactly and reasonably arranged for easy operation.
2.7 Equipped with a 5-speed gearbox, it can meet the differentiated speed requirements of different formations.
3. Parameters of JFC-5 TractorMounted Reverse Circulation Water Well Drilling Rig
| Drilling diameter | 300-1000mm |
| Drilling depth | 0-60m |
| Drill pipe specifications | 140*2000mm |
| Drilling speed | 20-126r/min(Five-speed shift) |
| Mudpump motor | 15kW |
| Rotary motor | 11kW |
| Vacuum pump motor | 4kW |
| Hydraulic oil pump motor | 4kW |
| Tractor chassis | 50HP |
| Drilling rig weight | 4.7T |
| Shipping dimensions | 5800*2100*2700mm |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
XYX Series Wheel Hydraulic Core Drilling Rig
1Introduction toXYX Series Wheel Hydraulic Core Drilling Rig
XYX series wheeled hydraulic core drilling rig is designed to satisfy the change of short distance construction site in field exploration. On the basis of hydraulic drilling rig, removable walking mechanism and towing device are installed. According to the special requirements of customers, we can customize two-wheel or four-wheel towing style.
2Features of XYX Series Wheel Hydraulic Core Drilling Rig
2.1 Walking mechanism and towing device make it more convenient to move in short distance.
2.2 The optional moving device can realize the front and back movement of the main machine and is convenient for wellhead operation.
2.3 The optional electrically started diesel engine can reduce the labor intensity of operators, especially in cold season.
2.4 It has an oil pressure feed mechanism to improve drilling efficiency.
2.5 Equipped with hole bottom pressure gauge, easy to master the situation in the hole.
3Parametersof XYX Series Wheel Hydraulic Core Drilling Rig
| Drilling rig model | XYX-100 | XYX-150 | XYX-200 | |
| Overall machine parameters | Drilling depth | 100m | 150m | 200m |
| Open hole dia | 325mm | 325mm | 400mm | |
| End hole dia | 75mm | 75mm | 75mm | |
| Drill pipe dia | 42mm | 42/50mm | 42/50mm | |
| Drilling angle | 90-75 | 90-75 | 90-75 | |
| Weight | 500kg | 550kg | 1300kg | |
| Vertical shaft | Vertical shaft speed | 142285570r/min | 1010790470295140r/min | 64128287557r/min |
| Vertical axis travel | 450mm | 450mm | 450mm | |
| winch | Single rope lifting force | 1000kg | 1600kg | 2400kg |
| Lifting speed | 0.420.841.68m/s | 1.050.660.31m/s | 0.410.821.64m/s | |
| Wire rope dia | 12mm | 12mm | 12mm | |
| Wire rope capacity | 35m | 35m | 35m | |
| Rig tower | Effective height | 6.5m | 6.5m | 6.5m |
| Rated load | 18T | 18T | 18T | |
| Mud pump | type | Horizontal single cylinder double acting | Horizontal single cylinder double acting | Horizontal single cylinder double acting |
| Displacement | 95L/min | 160L/min | 160L/min | |
| work pressure | 1.3Mpa | 1.3Mpa | 1.3Mpa | |
| Inlet hose dia | 50mm | 50mm | 50mm | |
| Outlet pipe diameter | 32mm | 32mm | 32mm |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
SJCY Series Wheeled Diesel Hydraulic Water Well Drilling Rig
1.Introduction toSJCY Series WheeledDiesel Hydraulic Water Well Drilling Rig
SJCYseries wheeleddiesel hydraulic water well drilling rigis a hydraulic drilling rig developed and widely promoted by HUAXIAMASTER GROUP. It is suitable for drilling in soil layer, quicksand layer and a small amount of rock and soil layer. It is mainly used for drilling civil draft wells, ground source heat pump air conditioning wells, engineering dewatering wells, drought-resistant wells, industrial wells, etc.
2.Features of SJCY Series WheeledDiesel Hydraulic Water Well Drilling Rig
2.1 The diesel engine is equipped with electric starting, which is convenient to start and reduces the labor intensity of the operator.
2.2 The drilling rig adopts hydraulic working principle and is equipped with radiator, so the drilling rig can work continuously and efficiently.
2.3 Equipped with high-power hydraulic motor, the power head can rotate forward and backward.
2.4 The drill frame is equipped with hydraulic oil cylinder, and the oil pressure can be raised and lowered through the operating handle.
2.5 The drilling rig has its own water pump, which has reasonable structure, compact layout and good slag removal effect.
2.6 It can be equipped with a motorcycle tricycle chassis for easy movement and transfer.
1Introduction toQY Series Portable Fully Hydraulic Core Drilling Rig
Fully hydraulic core exploration drilling rig adopts rope core drilling rig with full hydraulic power head drilling method, and the core drilled by the drilling tool is lifted out by the winch through the inner hole of the drill pipe to complete the geological drilling core work. It is mainly suitable for drilling solid ore deposits, and can also be used for engineering geology, shallow oil, natural gas, groundwater drilling, and engineering drilling such as tunnel ventilation, drainage and dike grouting.
2Features of QY Series Portable Fully Hydraulic Core Drilling Rig
2.1 Modular design, light weight, easy to disassemble and carry.
2.2 The rig is fully hydraulic driven, and the hydraulic system adopts load sensitive control, with high working efficiency and high torque.
2.3 The power head rotation is driven by axial piston pump and inclined shaft piston motor, and the mechanical two gears plus step less speed regulation, advanced structure.
2.4 Equipped with a lateral translation mechanism for the power head, the mast is raised and lowered by a cylinder and can slide as a whole, and can drill holes within the range of 45-90.
2.5 Hydraulic gripper to achieve clamping drill pipe, with drill pipe disassembly.
2.6 Hydraulic motor driven hoist, can be flexible lifting drilling tools or auxiliary tools.
XYX-3 Wheel Hydraulic Core Drilling Rig
1Introduction toXYX-3 Wheel Hydraulic Core Drilling Rig
XYX-3 wheeled hydraulic core drilling rig is a multi-functional traction hydraulic vertical rotary drilling rig. It is mainly used for the general survey and exploration of metal and non-metallic solid minerals, and also can be used for engineering geological exploration, hydrogeological survey, general survey and exploration of oil and gas fields, and well drilling.
2Features of XYX-3 Wheel Hydraulic Core Drilling Rig
2.1 The drilling rig is equipped with a wheeled traveling mechanism and hydraulic cylinder support which is convenient for moving the whole machine and horizontal adjustment of the drilling rig.
2.2 With oil pressure feed mechanism, the drilling efficiency is improved.
2.3 The drilling rig is equipped with a hydraulic chuck, which can reverse the rod without stopping the machine, with high working efficiency, convenient, safe and feasible operation.
2.4 It is equipped with a pressure gauge at the bottom of the hole to indicate the pressure, so as to grasp the situation in the hole.
2.5 The tower lifting and lowering are operated by hydraulic pressure, which is convenient and feasible.
2.6 The diesel engine is electrically started to reduce the labor intensity of workers.
3Parametersof XYX-3 Wheel Hydraulic Core Drilling Rig
| Model | XYX-3 | |
|
Overall machine parameters | Drillingdepth | 600m |
| Open holedia | 600mm | |
| End holedia | 75mm | |
| Drillpipedia | 60mm | |
| Drillingangle | 75-90 | |
| Matching power | YunneiYN27/39kW | |
| Weight | 3600kg | |
| L*W*H)Dimension | 4500*2600*3300mm | |
|
| Forward speed | 32-1057r/min |
| Reverse speed | 29-137r/min | |
| Stroke | 600mm | |
|
| Lifting force | 3000kg |
| Lifting speed | 0.5-1.9m/s | |
| Wire rope dia | 12.5mm | |
| Wireropecapacity | 65m | |
| Derrick | Height | 6.5m |
| Ratedload | 18t |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
Additional Information:
Delivery Time : 7
KQZ Series Air-hydraulicLinkage Down-the-hole Drilling Rig
1.Introduction toKQZ Series Air-hydraulicLinkage Down-the-hole Drilling Rig
The KQZ series air-hydraulicdown-the-hole drillingrig is a highly efficient rock drilling equipment. It uses compressed air to drive the impactor to generate high-frequency impact force on the drill bit. At the same time, the hydraulic motor drives the drill bit to rotate at high speed to achieve efficient rock crushing. It is an efficient and reliable choice for hard rock deep hole operations. It is mainly used in open-pit mine blasting holes, large-scale stone projects, water conservancy and hydropower construction and other fields.
2.Features of KQZ Series Air-hydraulicLinkage Down-the-hole Drilling Rig
2.1 High-efficiency drilling: The impact drilling method is adopted, and the impact energy directly acts on the drill bit at the bottom of the hole, with small energy transfer loss, which greatly improves the drilling efficiency.
2.2 Good drilling quality: the drilled hole is straighter, the hole wall is smoother, and the hole forming accuracy is higher.
2.3 Strong adaptability: It can adapt to a wide range of strata from soft rock to extremely hard rock.
2.4 Simple operation: The drilling rig is easy to operate and novices can quickly get started, reducing manual dependence.
2.5 Durable: Made of high-strength materials, it has good wear resistance and impact resistance, can operate stably for a long time, and reduces the cost of repairing and replacing equipment.
XYD-2C Crawler Hydraulic Core Drilling Rig
1Introduction toXYD-2C Hydraulic Core Drilling Rig
XYD-2Chydraulic core drilling rig is an upgraded core drilling equipment based on XY-2 hydraulic drilling rig. The whole machine adopts the heightening design, which can increase the pole by 2m at a time, and the efficiency is greatly improved. The steel crawler chassis is suitable for the difficult mountain roads, especially in Yunnan, Guizhou and Sichuan areas. It is widely used in highway, railway, house and Bridge exploration. It has outstanding performance in drilling backfill and well drilling. Now, the drilling rig is called "HUAXIAMASTER drill king " by the majority of drilling friends.
2Features of XYD-2C Hydraulic Core Drilling Rig
2.1 The drilling rig adopts heightening design, which provides space for adding auxiliary function area.
2.2 The main engine is equipped with a fixed clamping mechanism and an extended integral main rod, which can realize reciprocating rod adding without lifting the drill, and the drilling efficiency is greatly improved.
2.3 Hydraulic landing gantry drill tower is supported by two oil cylinders, which is safe and convenient to operate.
2.4 It can be used for staff rest.
2.5 Drum and water pipe are equipped to provide clear circulating water for drilling rig from nearby water source.
2.6 Equipped with steel crawler chassis, it has strong cross-country performance and can easily deal with various complex working sites.
2.7 Equipped with hydraulic high outrigger, it is used for leveling the drilling rig to ensure the stability of the fuselage
2.8 Centralized control handle, reasonable layout, flexible and reliable
2.9 Turn on the power switch, turn the start key to the start position, and you can start it with one click
2.10 The main engine is equipped with moving slide, which is convenient for drilling
3Parametersof XYD-2C Hydraulic Core Drilling Rig
| Drilling rig model | XYD-2C | |
|
Overall machine parameters | Drilling depth | 300m |
| Borehole diameter | 75-219mm | |
| Main rod specification | 79*89mm | |
| Length of main pole | 2810mm | |
| Power | 33kW | |
| Mud pump | Three cylinder160 mud pump | |
| Drill weight | 6T | |
| Dimensions(retracted tower) | 4.7*2.4*3.2m | |
| Rig tower | Derrick height | 6200mm |
| Maximum load weight of drilling tower | 2000Kg | |
|
Drum | Drumlength | 1500mm |
| Water pipe winding | 300m | |
|
Trackchassis | Trackspecifications | 2.6*0.4m |
| Track capacity | 8000Kg | |
| Rated grade | 030 | |
| Walking speed | 520km/h |
Note: Products are constantly being improved. If there are any changes, we will not notify you separately. Please refer to the actual product.
XYC-3 Truck-mounted Hydraulic Core Drilling Rig
1Introduction toXYC-3 Truck-mounted Hydraulic Core Drilling Rig
XYC-3 vehicle mounted hydraulic core drilling rig is a multi-functional hydraulic vehicle-mounted vertical shaft rotary drilling rig, which is mainly used in geological census exploration, road and high-rise building foundation exploration, as well as various concrete structure inspection holes, river embankments, roadbed grouting hole drilling and direct grouting holes, civil wells, etc.
2Features of XYC-3 Truck-mounted Hydraulic Core Drilling Rig
2.1 The truck chassis is a medium truck chassis. The rig transmission system, winch, mud pump and other important accessories are installed on the chassis. The layout is reasonable and compact, and the operation is simple.
2.2 BW-250 mud pump is equipped with high pressure and large flow to ensure the drilling depth and diameter.
2.3 The drilling rig is equipped with a mobile device, which can realize the forward and backward movement of the drilling rig host and facilitate wellhead operation.
2.4 The rig tower is equipped with hydraulic automatic telescopic drilling tower, which is safe and convenient to operate.
2.5 The hydraulic system realizes the control of feed pressure and speed to meet the needs of drilling in different strata.
3Parametersof XYC-3 Truck-mounted Hydraulic Core Drilling Rig
| Model | XYC-3 | |
|
Overall machine parameters | Drillingdepth | 600m |
| Open holedia | 600mm | |
| End holedia | 75mm | |
| Drillpipedia | 60mm | |
| Drillingangle | 75-90 | |
| Matching power | YunneiYN27/39kW | |
| Weight | 22000kg | |
| (L*W*H)Dimension | 9000*2500*3600mm | |
|
| Forward speed | 32-1057r/min |
| Reverse speed | 29-137r/min | |
| Stroke | 600mm | |
|
| Lifting force | 3000kg |
| Lifting speed | 0.5-1.9m/s | |
| Wire rope dia | 12.5mm | |
| Wireropecapacity | 65m | |
|
| Height | 6.5m |
| Ratedload | 18t |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
1Introduction toHJD Horizontal Mountain Spring Water Well Drilling Rig
HJD horizontal spring water well drilling rig adopts modular design, which is composed of main machine, slide way, distribution board, water gas bottle, etc., with reasonable layout and compact structure. In order to further facilitate mobile handling, the main machine can continue to be disassembled into rotary part, propulsion part and main machine base, and the slide way can continue to be disassembled into guide rail, wire rope tensioner and drilling tool support frame. The main machine of the drilling rig adopts the principle of water and gas combination of pneumatic drilling and wet slag removal, which can be used in conjunction with the long-stroke slide to realize the horizontal drilling of mountains. The drilling rig has been widely used in horizontal drilling and mountain horizontal drilling.
2Features of HJD Horizontal Mountain Spring Water Well Drilling Rig
2.1 The drilling rig adopts the working principle of water and air combination, with high efficiency, fast footage and less dust.
2.2 Long stroke slide way shall be configured and long drill pipe shall be selected to reduce the number of drill pipe switching.
2.3 The drilling rig adopts modular design, which can be easily disassembled and assembled, and is convenient for transportation and handling.
2.4 In addition to forward rotation, the main machine is equipped with inching forward rotation and inching reverse rotation for easy loading and unloading of drill pipe.
2.5 The power distribution panel of the drilling rig is equipped with a wireless remote controller, which can realize remote operation of the host.
3Parameters of HJD Horizontal Mountain Spring Water Well Drilling Rig
| Model | HJD | |
| Drilling diameter | 65707680mm | |
| Drill pipe specifications | 42*4000 | |
| Voltage | 380V | |
| Power | Rotary motor | 4kW |
| Propulsion motor | 2.2kW | |
| Weight | Turning part | 90kg |
| Promotion Department | 69kg | |
| Host base | 80kg | |
| Guide | 38kg/Strip | |
| Drill tool support | 19kg | |
| Water bottle | 20kg | |
| Distribution box | 10kg | |
| Assembly size | 5660*840*970mm |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
QTZ-2YS Double-tubeSoil SamplingDrilling Rig
1Introduction toQTZ-2YS Double-tube Soil Sampling Drilling Rig
QTZ-2YS hydraulic portable soil sample drilling rig is a hydraulic soil borrowing drill. The drilling rig adopts modular design, which is mainly composed of hydraulic soil borrowing host, hydraulic pump station, hydraulic puller, etc. The structure is simple and convenient for assembly, handling and disassembly. QTZ-2YS portable soil sample drilling rig adopts the hydraulic working principle, with strong impact capacity and fast footage. It has been widely used in environmental protection testing, geological research, wetland environmental investigation, soil structure description, agricultural soil investigation, etc.t.
2Features Of QTZ-2YS Double-tube Soil Sampling Drilling Rig
2.1 The hydraulic pump station adopts electric starting, which reduces the labor intensity of the operator and is convenient to start in the cold season.
2.2 The hydraulic system greatly enhances the impact force of the main machine in the soil, and samples can be drilled smoothly even in relatively hard soil conditions.
2.3 It has good sampling stability, which can effectively reduce human errors in the sampling process and ensure the credibility and scientific of the data.
2.4 Double tube sampling is available, which can effectively avoid secondary pollution.
2.5 The drilling rig has simple structure, small volume and light weight, which is convenient for assembly, handling and disassembly.
DZL Series Small Four-Wheel Guardrail Pile Driver
1.Introduction to DZL Series Small Four-Wheel Guardrail Pile Driver
The DZL series small four-wheel guardrail pile driver is a multi-functional engineering machinery specially designed for highway guardrail construction. Powered by a diesel engine and adopting a full hydraulic transmission system, it features self-propelled capability without the need for external traction. Its core functions include steel pipe pile driving, extraction, and drilling, enabling it to complete guardrail installation and emergency repair operations in various complex stratum conditions. It fully embodies advantages such as convenient mobility and diversified functions, and is widely used in expressways, municipal engineering, and field construction sites.
2.Features of DZL Series Small Four-Wheel Guardrail Pile Driver
2.1 Power configuration: Equipped with a high-performance diesel engine, it provides a strong power source for construction operations, with significantly improved power reliability and fuel economy.
2.2 Hydraulic system: Advanced hydraulic system with high-quality hydraulic components and strict assembly processes ensures high efficiency and durability of the hydraulic system.
2.3 Design: The overall frame structure is sophisticated with qualified materials, featuring high strength and good stability. The design conforms to industrial aesthetics, and the operator 's working space is more spacious.
2.4 Production process: The production process is more reasonable. Wear-resistant components are all treated with heat treatment. The welding process is rigorous, and after stress relief treatment, it is not easy to deform.
1Introduction toXY-3 Series Hydraulic Core Drilling Rig
XY-3 series hydraulic core drilling rig is a kind of medium-shallow hole vertical spindle rotary drilling rig which can meet the needs of various drilling techniques and drilling in different strata. The main types of XY-3 series drilling rig are XY-3 conventional type, XYX-3 wheel type, XYD-3 crawler type and XYC-3 truck-mounted type.
2Features of XY-3 Hydraulic Core Drilling Rig
2.1 The drilling rig adopts the automobile gearbox assembly, which has 10-gear forward and 2-gear reverse. The rotational speed of each gear is reasonably designed to meet the requirements of different drilling technologies.
2.2 The hydraulic system realizes the control of feed pressure and speed to meet the needs of drilling in different strata.
2.3 Equipped with hole bottom pressure gauge, easy to grasp the situation in the hole.
2.4 The drilling rig has large output torque and strong bearing capacity, so it is easy to deal with various underground accidents.
3Parametersof XY-3 Series Hydraulic Core Drilling Rig
| Model | XY-3 | XYX-3 | XYC-3 | XYD-3 | |
|
Overall machine parameters | Drillingdepth | 600m | 600m | 600m | 600m |
| Open holedia | 600mm | 600mm | 600mm | 600mm | |
| End holedia | 75mm | 75mm | 75mm | 75mm | |
| Drillpipedia | 60mm | 60mm | 60mm | 60mm | |
| Drillingangle | 75-90 | 75-90 | 75-90 | 75-90 | |
| Matching power | YunneiYN27/39kW | YunneiYN27/39kW | YunneiYN27/39kW | YunneiYN27/39kW | |
| Weight | 1800kg | 3600kg | 22000kg | 6500kg | |
| L*W*H | 2500*900*1800mm | 4500*2600*3300mm | 9000*2500*3600mm | 4500*2600*3300mm | |
| Vertical shaft | Forward speed | 32-1057r/min | 32-1057r/min | 32-1057r/min | 32-1057r/min |
| Reverse speed | 29-137r/min | 29-137r/min | 29-137r/min | 29-137r/min | |
| Stroke | 600mm | 600mm | 600mm | 600mm | |
|
| Lifting force | 3000kg | 3000kg | 3000kg | 3000kg |
| Lifting speed | 0.5-1.9m/s | 0.5-1.9m/s | 0.5-1.9m/s | 0.5-1.9m/s | |
| Wire rope dia | 12.5mm | 12.5mm | 12.5mm | 12.5mm | |
| Wireropecapacity | 65m | 65m | 65m | 65m | |
|
| Height | 6.5m | 6.5m | 6.5m | 6.5m |
| Ratedload | 18t | 18t | 18t | 18t |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
GFCY Series Photovoltaic Hydraulic Pile Hammer
1. Introduction toGFCY Series Photovoltaic Hydraulic Pile Hammer
GFCY series photovoltaic hydraulic pile hammer machine is a commonly used pile foundation construction equipment in the construction of photovoltaic power stations. The machine uses hydraulic hammering to drive the pile foundation into the ground. The pile driving speed is fast and can quickly complete the construction of steel sheet piles, I-beams, U-shaped steels, cement piles, wooden piles and other pile foundations.
2. Features of GFCY Series Photovoltaic Hydraulic Pile Hammer
2.1 It has higher hammering energy and hammering frequency, which significantly improves the efficiency of pile hammering, shortens the construction period and reduces construction costs.
2.2 The chassis uses special engineering tracks with wide and stable track shoes, which have good off-road performance and can adapt to various complex and changeable terrains.
2.3 The chassis is configured to rotate 360 to achieve all-round pile foundation construction.
2.4 Equipped with a slide pitch cylinder, a slide swing cylinder and a slide telescopic compensation cylinder, the trinity can accurately locate the pile hole position, ensuring the verticality of the pile and reducing errors.
2.5 The operation console is centrally controlled, easy to operate, safe and reliable.
2.6 The overall welding of the equipment is rigorous, and the wear-resistant parts adopt heat treatment technology to avoid structural deformation. It has a long service life and a low failure rate.
1. Introduction to PMGZ Series Crawler High Lift Slope Anchor Drilling Rig
The PMGZ series crawler high-lift slope anchor drilling rig is a construction equipment for geological disaster prevention and control projects. The drilling rig is equipped with a hydraulic telescopic boom, which can be extended section by section through the hydraulic system to easily cover the slope area with a large vertical height and a long horizontal distance. The boom has a pitch adjustment function. Combined with the telescopic action, it can accurately locate any slope position and perform vertical, inclined or horizontal hole drilling to meet the needs of complex anchoring construction. It is mainly used in landslide control and dangerous rock anchoring projects. At the same time, the drilling rig is also widely used in urban deep foundation pit support, anti-floating anchors and foundation grouting reinforcement engineering holes, blasting holes in blasting projects, tunnel anchor projects, tunnel pipe shed support, and water conservancy and hydropower high slope rock anchoring projects.
2. Features of PMGZ Series Crawler High Lift Slope Anchor Drilling Rig
2.1 Convenient high-altitude construction: The drilling platform is equipped with a drilling rig, an operating platform and a drilling tool placement platform, which makes it more convenient for construction workers to cooperate with construction at high altitudes.
2.2 There is no need to frequently move the drilling rig, and the high-lift telescopic arm can cover a large construction area, improving construction efficiency while avoiding the risk of landslides caused by the equipment being close to unstable slopes.
2.3 Support various drilling methods such as conventional down-the-hole drilling, pipe drilling, spiral drilling, etc., to efficiently cope with complex and changeable formation conditions.
2.4 Equipped with a large torque hydraulic power head, it has strong drilling capability and improves construction efficiency.
2.5 Equipped with an engineering steel crawler chassis, the drilling rig can move easily in various complex terrains.
2.6 The key components are thickened and treated with wear-resistant treatment, the whole machine is sturdy and durable, the quality is reliable, and the failure rate and maintenance cost are reduced.
XYD-2C Crawler Hydraulic Core Drilling Rig
1Introduction toXYD-2C Hydraulic Core Drilling Rig
XYD-2Chydraulic core drilling rig is an upgraded core drilling equipment based on XY-2 hydraulic drilling rig. The whole machine adopts the heightening design, which can increase the pole by 2m at a time, and the efficiency is greatly improved. The steel crawler chassis is suitable for the difficult mountain roads, especially in Yunnan, Guizhou and Sichuan areas. It is widely used in highway, railway, house and Bridge exploration. It has outstanding performance in drilling backfill and well drilling. Now, the drilling rig is called "HUAXIAMASTER drill king " by the majority of drilling friends.
2Features of XYD-2C Hydraulic Core Drilling Rig
2.1 The drilling rig adopts heightening design, which provides space for adding auxiliary function area.
2.2 The main engine is equipped with a fixed clamping mechanism and an extended integral main rod, which can realize reciprocating rod adding without lifting the drill, and the drilling efficiency is greatly improved.
2.3 Hydraulic landing gantry drill tower is supported by two oil cylinders, which is safe and convenient to operate.
2.4 It can be used for staff rest.
2.5 Drum and water pipe are equipped to provide clear circulating water for drilling rig from nearby water source.
2.6 Equipped with steel crawler chassis, it has strong cross-country performance and can easily deal with various complex working sites.
2.7 Equipped with hydraulic high outrigger, it is used for leveling the drilling rig to ensure the stability of the fuselage
2.8 Centralized control handle, reasonable layout, flexible and reliable
2.9 Turn on the power switch, turn the start key to the start position, and you can start it with one click
2.10 The main engine is equipped with moving slide, which is convenient for drilling
3Parametersof XYD-2C Hydraulic Core Drilling Rig
| Drilling rig model | XYD-2C | |
|
Overall machine parameters | Drilling depth | 300m |
| Borehole diameter | 75-219mm | |
| Main rod specification | 79*89mm | |
| Length of main pole | 2810mm | |
| Power | 33kW | |
| Mud pump | Three cylinder160 mud pump | |
| Drill weight | 6T | |
| Dimensions(retracted tower) | 4.7*2.4*3.2m | |
| Rig tower | Derrick height | 6200mm |
| Maximum load weight of drilling tower | 2000Kg | |
|
Drum | Drumlength | 1500mm |
| Water pipe winding | 300m | |
|
Trackchassis | Trackspecifications | 2.6*0.4m |
| Track capacity | 8000Kg | |
| Rated grade | 030 | |
| Walking speed | 520km/h |
Note: Products are constantly being improved. If there are any changes, we will not notify you separately. Please refer to the actual product.
1Introduction toSJCY-D Crawler Diesel Hydraulic Drilling Rig
SJCY-D crawlerdiesel hydraulic water well drilling rig is a hydraulic drilling rig developed and widely promoted by Shandong Master Group. It is suitable for drilling in soil layer, quicksand layer and a small amount of rock and soil layer. It is mainly used for drilling civil draft wells, ground source heat pump air conditioning wells, engineering dewatering wells, drought-resistant wells, industrial wells, etc.
2Features of SJCY-D Crawler Diesel Hydraulic Drilling Rig
2.1 The diesel engine is equipped with electric starting, which is convenient to start and reduces the labor intensity of the operator.
2.2 The drilling rig adopts hydraulic working principle and is equipped with radiator, so the drilling rig can work continuously and efficiently.
2.3 Equipped with high-power hydraulic motor, the power head can rotate forward and backward.
2.4 The drill frame is equipped with hydraulic oil cylinder, and the oil pressure can be raised and lowered through the operating handle.
2.5 The drilling rig has its own water pump, which has reasonable structure, compact layout and good slag removal effect.
2.6 Equipped with rubber steel wire tracks, it is easy to move, and it will not hurt the road surface when walking on urban roads.
3Parameters of SJCY-D Crawler Diesel Hydraulic Drilling Rig
| Model | SJCY-D |
| Machine power | Single cylinder diesel engine/22 HP |
| Chassis | Rubber crawler hydraulic walking chassis |
| Vehicle weight | 950kg |
| Overall machine size | 2000*1100*2100mm |
| Power head | BM5-200 Hydraulic Motor |
| Pressurized system | Hydraulic cylinder booster |
| Outrigger | Four screw legs |
| Drill pipe specifications | 50*1500mm |
| Drilling diameter | 80-300mm |
| Drilling depth | 0-120m |
| Slide travel | 2400mm |
| Lift height | 2600mm |
| One-time advancement length | 1500mm |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
XY Series Hydraulic Core Drilling Rig
1Introduction toXY Series Hydraulic Core Drilling Rig
XY series drilling rig is a medium-shallow hole core drilling rig with hydraulic feed and mechanical transmission. It can be used in geological core drilling, grouting hole drilling and hydro logical well drilling. Diamond, composite and alloy bits can be selected for drilling according to different strata.
2Features of XY Series Hydraulic Core Drilling Rig
2.1 It has automatic hydraulic feeding mechanism to improve drilling efficiency and reduce labor intensity.
2.2 The steel ball clamping device can replace drill pipe without stopping, easy to operate, safe and reliable.
2.3 Equipped with hole bottom pressure gauge, easy to grasp the situation in the hole.
2.4 Compact structure, centralized handle, small area, easy to move.
2.5 With large torque and strong bearing capacity, it can realize remote control and speed change, and the operation is centralized and convenient.
3Parametersof XY Series Hydraulic Core Drilling Rig
| XY series hydraulic core drilling rig | ||||||
| Drilling rig model | XY-80 | XY-100 | XY-150 | XY-180 | XY-200 | |
| Drilling capacity | DrillingdepthDrilling depthDrilling depth | 80m | 100m | 150m | 180m | 200m |
| Openholedia. | 219mm | 325mm | 325mm | 375mm | 400mm | |
| Endholedia. | 75mm | 75mm | 75mm | 75mm | 75mm | |
| Drillpipedia | 42mm | 42/50mm | 42/50mm | 42/50mm | 42/50mm | |
| Drilling angle | 75-90 | 75-90 | 75-90 | 75-90 | 75-90 | |
|
| Vertical shaft speed | 142285r/min | 142285570r/min | 1402954707901010r/min | 71142310620r/min | 71142310620r/min |
| Vertical axis travel | 450mm | 450mm | 450mm | 450mm | 450mm | |
| Hydraulic oil pump | Pressure | 1.2Mpa | 1.2Mpa | 1.2Mpa | 1.2Mpa | 1.2Mpa |
| Speed | 1500r/min | 1500r/min | 1800r/min | 1800r/min | 2000r/min | |
| Hoist | Lifting capacity | 9.3kN | 9.8kN | 14kN | 15kN | 20kN |
| Wire rope capacity | 27m | 35m | 35m | 35m | 35m | |
| Wire diameter | 12mm | 12mm | 12mm | 12mm | 12mm | |
| Power | Matching power | S1100 Diesel Engine | S1100 diesel engine 10kw motor | S1105 diesel engine 11kw motor | S1115 diesel engine 15kw motor | S1115 diesel engine 15kw motor |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
| XY series hydraulic core drilling rig | |||||
| Drilling rig model | XY-100Y | XY-150Y | XY-180Y | XY-200Y | |
| Shape | Mobile model | Mobile model | Mobile model | Mobile model | |
|
| DrillingdepthDrillingdepthDrilling depth | 100m | 150m | 180m | 200m |
| Openholedia | 325mm | 325mm | 375mm | 400mm | |
| Endholedia | 75mm | 75mm | 75mm | 75mm | |
| Drillpipedia | 42/50mm | 42/50mm | 42/50mm | 42/50mm | |
| Drilling angle | 75-90 | 75-90 | 75-90 | 75-90 | |
| Spindle speed | 142285570r/min | 1402954707901010r/min | 71142310620r/min | 71142310620r/min | |
| Spindlestroke | 450mm | 450mm | 450mm | 450mm | |
| Hydraulic pump | Hydraulic pump pressure | 1.2Mpa | 1.2Mpa | 1.2Mpa | 1.2Mpa |
| Hydraulic pump speed | 1500r/min | 1800r/min | 1800r/min | 2000r/min | |
| Hoist | Lifting capacity | 9.8kN | 14kN | 15kN | 20kN |
| Wire rope capacity | 35m | 35m | 35m | 35m | |
| Wire diameter | 12mm | 12mm | 12mm | 12mm | |
| Power | Matching power | S1100 diesel engine 10kw motor | S1105 diesel engine 11kw motor | S1115 diesel engine 15kw motor | S1115 diesel engine 15kw motor |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
QZ Series Portable Core Drilling Rig
1Introduction toQZ Series Light Core Drilling Rig
QZ series light drilling rig is a light multi-purpose geological engineering drilling rig, which is mainly suitable for geological exploration, advanced drilling, standard penetration test (SPT), blasting hole drilling, dredging acoustic hole testing, etc.
2Features of QZ Series Light Core Drilling Rig
2.1 Compact structure and small occupation area.
2.2 Light weight and easy disassembly, easy to move.
2.3 Two gears speed change, easy to deal with different strata.
2.4 If equipped with winch, more convenient to lift.
3Parametersof QZ Series Electric Light Core Drilling Rig
| Model | QZ-1A | QZ-2A | QZ-2D | QZ-2DS |
| Engine | Two-phase electricity | Three-phase electricity | Three-phase electricity | Three-phase electricity |
| Power | 1.5kW | 3kW | 4kW | 4kW |
| Borehole dia | 3346mm | 3391mm | 3391mm | 4691mm |
| Sampling depth | Soil layer46: 2025m Rock461520m | Soil layer91: 1015m Rock91: 05m Rock75: 510m Rock60: 1015m Rock46: 1520m | Soil layer91: 1015m Rock91: 05m Rock75: 510m Rock60: 1015m Rock46: 1520m | Soil layer91: 1520m Rock91: 1015m Rock75: 1520m Rock60: 2025m Rock46: 2530m |
| Drill pipe dia | 25mm | 32mm | 32mm | 32mm |
| Dimension | 600*450*1900mm | 600*450*1900mm | 600*450*1900mm | 600*450*2500mm |
| Weight | 80kg | 95kg | 100kg | 115kg |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
4Parametersof QZ Series Internal Combustion Engine Lightweight Core Drilling Rig
| Model | QZ-1B | QZ-2B | QZ-2C | QZ-2CS | QZ-3 |
| Engine | gasoline engine | gasoline engine | gasoline engine | gasoline engine | Diesel engine |
| Power | 3.5kW | 3.5kW | 4.5kW | 4.5kW | 6kW |
| Displacement | 224cc | 196cc | 224cc | 224cc | 499cc |
| Borehole dia | 3391mm | 3391mm | 4691mm | 4691mm | 46110mm |
| Sampling depth | Soil layer91: 1015m Rock91: 05m Rock75: 510m Rock461520m | Soil layer911015m Rock9105m Rock75: 510m Rock60: 1015m Rock46: 1520m | Soil layer91: 1520m Rock91: 1015m Rock75: 1520m Rock60: 2025m Rock46: 2530m | Soil layer91: 1520m Rock91: 1015m Rock75: 1520m Rock60: 2025m Rock46: 2530m | Soil layer110: 2025m Rock91: 2025m Rock75: 2530m Rock60: 2530m Rock46: 4050m; |
| Drill pipe dia | 25mm | 28mm | 30mm | 30mm | 30mm |
| Rotate speed | 200570r/min | 200570r/min | 200570r/min | 200570r/min | 3600r/min |
| Torque | 110N.m | 110N.m | 110N.m | 110N.m | 180N.m |
| Dimension | 600*450*1900mm | 600*450*1900mm | 600*450*1900mm | 600*450*1900mm | 680*1200*3800mm |
| Weight | 90kg | 90kg | 95kg | 95kg | 165kg |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
YQZ-50A Hydraulic Light Core Drilling Rig
1Introduction toYQZ-50A Hydraulic Light Core Drill Rig
YQZ-50A hydraulic portable drilling rig is a kind of small-scale sampling drilling equipment suitable for plain, mountainous areas and areas with inconvenient transportation and energy resources. It is widely used in railway, water conservancy and other construction projects as well as geological core drilling and small grouting holes in field mountainous areas.
2Features of YQZ-50A Hydraulic Portable Core Drilling Rig
2.1 Equipped with double cylinder hydraulic feeding system, drilling speed is fast and working efficiency is high.
2.2 The drilling rig is equipped with a fixed clamping mechanism and an integral main rod, so it is convenient to work without a drill tower.
2.3 Equipped with 4-speed transmission system. The operator can freely adjust the forward rotation speed through three gears. In addition, it is equipped with a slow reverse gear, which is convenient for the operator to disassemble the drill pipe.
2.4 The handle is centralized, easy to operate, safe and feasible
2.5 It is equipped with pressure gauge at the bottom of the hole to indicate the pressure, so as to master the situation in the hole.
2.6 Compact structure, small floor area.
2.7 It has strong decomposition ability and is easy to be relocated. It is suitable for complex terrain such as hills and mountainous areas.
3Parametersof YQZ-50A hydraulic Portable Core Drilling Rig
| Model | YQZ-50A |
| Boreholedia. | 75mm |
| Samplingdepth | 50m |
| Drill pipe | 42mm |
| Verticalshaftspeed | 70-650rpm(1-3Gear) |
| Reversespeed | 50-130rpm(RGear) |
| Cylinderstroke | 1100mm |
| Main enginepower | Diesel engine R180 |
| Drill size | 1400*950*1600mm |
| Weight | 280kg |
Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
GFHY Series Photovoltaic Hydraulic Pile Driver
1. Introduction to GFHY Series Photovoltaic Hydraulic Pile Driver
GFHY series photovoltaic hydraulic pile drivers are important equipment for the construction of photovoltaic power stations. They are mainly used for pile driving and drilling work of pile foundations to provide a solid foundation for the installation of photovoltaic brackets. Photovoltaic hydraulic pile drivers can choose spiral drilling, down-the-hole impact and other piling methods for construction operations. They are widely used in mountains, hills, deserts and other scenes, providing more efficient, environmentally friendly and reliable solutions for the construction of photovoltaic power stations.
2. Features of GFHY Series Photovoltaic Hydraulic Pile Driver
2.1 It adopts advanced hydraulic system, the power head has large torque and high piling efficiency.
2.2 The chassis adopts special engineering tracks, the track shoes are wide and stable, have good off-road performance, and can adapt to various complex and changeable terrains.
XYD Series Crawler Hydraulic Core Drilling Rig 1Introduction toXYD Series Crawler Hydraulic Core Drilling Rig XYD series crawler hydraulic core drilling rig is a kind of drilling rig equipped with crawler chassis and hydraulic derrick to meet the needs of high speed, high efficiency and strong maneuverability in field exploration.The drilling rig can realize mobile operation in uneven areas such as hills and virgin forests. 2Features of XYD Series Crawler Hydraulic Core Drilling Rig 2.1 Rise and fall of derrick can be easily controlled by operation valves, which saves time and labor, and is safe and reliable. 2.2 The chassis adopts steel wire rubber crawler, which can reduce the noise of walking and not damage the road surface when walking on urban roads. 2.3 The chassis is equipped with high hydraulic legs, which can be used for leveling the drilling rig, can also realize self-loading and unloading without crane, saving a lot of lifting time and cost. 2.4 The 24V electric start diesel engine is used to reduce the operator 's labor intensity, making it more convenient to start in cold seasons. 2.5 BW-160 mud pump has high pressure and high flow rate, which ensures drilling depth and borehole diameter. 2.6 Configuration of the moving device can realize the front and back movement of the main machine and facilitate the operation of the wellhead. 3Parametersof XYD Series Crawler Hydraulic Core Drilling Rig Drilling rig model XYD-100 XYD-150 XYD-200 XYD-130YY XYD-200YY Overall machine parameters Drilling depth 100m 150m 200m 130m 200m Opening diameter 219mm 325mm 400mm 325mm 400mm final hole diameter 75mm 75mm 75mm 75mm 75mm Drill pipe diameter 42mm 42/50mm 42/50mm 42/50mm 42/50mm Active drill pipe 46/51*4200mm 46/51*4200mm 53/59*4200mm 53/59*4200mm 53/59*4200mm Drilling inclination 90 90 90 90 90 Drilling rig weight 2900kg 3000kg 3100kg 3800kg 4000kg Overall dimensions 3600*1900*2200mm 3600*1900*2200mm 3600*1900*2200mm 3600*2000*2400mm 3600*2000*2400mm Vertical shaft Vertical shaft speed 142285570r/min 1402954707901010r/min 64128287557r/min 142285570r/min 64128287557r /min Vertical axis travel 450mm 450mm 450mm 450mm 450mm Crawler chassis Crawler specification 350mm*90*54 350mm*90*54 350mm*90*54 350mm*90*48 360mm*90*48 Climbing angle 35 35 35 35 35 Walking speed 10km/h 10km/h 10km/h 10km/h 10km/h Hydraulic leg height 1500mm 1500mm 1500mm 1500mm 1500mm Winch Single rope lifting capacity 10kN 11kN 24kN 11kN 24kN Single rope lifting speed 0.411.64m/min 0.411.64m/min 0.411.64m/min 0.411.64m/min 0.411.64m/min Wire rope diameter 12mm 12mm 12mm 12mm 12
William Carter (HUAXIAMASTER), jining, China
Share us via
