Ruby Laser Technology Co Limited

• MOQ 1 Set(s)
• ApplicationYAG laser cutting machin
• Brand NameRL

• MOQ 20 Set(s)
• Applicationlaser engraving machine
• Brand NameRL

• MOQ 20 Set(s)
• Applicationlaser engraving machine
• Brand NameRL

• MOQ 20 Set(s)
• Brand NameRL
• usageco2 laser engraving machine

• MOQ 1 Piece(s)
• UsageYAG laser welding machine
• Brand NameRL

• MOQ 10 Piece(s)
• Applicationlaser machine
• Brand NameRL

• MOQ 20 Set(s)
• Applicationreci co2 tube
• Brand NameRL

We are offering 150w co2 laser power supply. specification: input ac voltage ac220v or ac110v input dc voltage dc 300v or dc150v input ac frequency 47-440hz max. Output voltage 50kv max. Output current 38ma(depends on laser tube) efficiency 91% over current protection 130% of max. Current open circuit protection yes (for short time) cooling fan cooling voltage range of high level control not less than3v voltage range of low level control not more than0.8v working temperature -30 - +65 degree centigrade humidity 20-85%rh(no dew) withstand voltage input-output ac1500vminnot more than10ma input-shell ac1500vminnot more than10ma output-shell connected insulation not less than 50mohm（dc500v） leakage current not less than 1ma（ac220v）not more than 0.5 ma（ac110v） shock resistance amplitude: 0.5mm, frequecy:10-55hz, 3d dretion:2 hours mtbf not less than30, 000hours full load 60 degree centigrade test 12hours 7 seconds startstop test 500 times dimension（lxwxh） 315mmx220mmx80mm

• MOQ 1 Piece(s)
• ApplicationYAG laser marking machine
• Brand NameRL

We are offering yag ld cw laser power supply. Specification: input input voltage ac220v.15% or ac110v.15% (please specify when placing order) ac frequency 47---440hz cold inrush current less than60a(ac220v input) less than30a(ac110v input) current leakage less than0.7ma(ac220v input) less than0.4ma(ac110v input) output max output voltage dc 24v voltage ripple noise less than30mv max output current dc 1-30a current ripple noise less than30ma temperature drift (half hour after boot) less than100ppmdegree stability(half hour after boot) less than0.1% soft increasedecrease time after current starting. more than10s efficiency more than90%(full load) mtbf more than50000 hours withstand voltage inpu-input, input-enclosure:ac1500v 10ma 60s.output-enclosue:dc500v 10ma 60s protection overload circuit, over output over current, overload, water through detection and water temperature detection environment operating temperature(-10-40)degree , relative humidity:less than90% cooling force-air cooling (fac) dimension l×w×h=483×88×192 (mm)

• MOQ 5 Piece(s)
• Brand NameRL
• ApplicationHeNe Laser machine

We are offering he-ne laser tube 1. Features: low leakage, isolated case, surge overload rating – 50 amperes peak, low forward voltage drop and high voltage. 2. Specification: model size(mm) mode power output(mw) rh-150d 150x26 tem00 more than0.8 rh-180d 180x26 tem00 more than1.2 rh-230d 230x35 tem00 more than1.8 rh-250d 250x35 tem00 more than2.0 rh-300 300x35 lower mode more than4.0 rh-350 350x35 lower mode more than6.0 rh-400 400x40 lower mode more than8.0 rh-450d 450x40 lower mode tem00 more than 10／5.5 rh-550 550x40 lower mode more than 15 rh-600d 600x40 lower mode tem00 more than 18 ／12 rh-700d 700x45 lower mode tem00 more than 25 18 rh-800d 800x50 lower mode tem00 more than 35 25 rh-1000d l000x50 lower mode tem00 more than 48 35.

• MOQ 5 Set(s)
• Brand NameRL
• ApplicationCO2 Laser engraving machine

We are offering co2 laser tube. Co2 laser tube reci co2 laser tube this is a high quality co2 laser tube made by reci . We deal direct with reci to avoid the possibility of getting a fake reci tube. The life span of the tube is estimated to have about 8, 000~ 10, 000 hours. description: 1, good compatibility . 2, extend the life of laser tube. 3, power supply-self has a feedback port, can be used for closedcircle control, also can be used for checking practical operating current of laser tubes. 4, power supply-self has a protection while opening circuit power supply can be used in copering circuit state in a short time , so avoid to damage power supply while leaking of laser tube, so can extend the life of laser tube. 5, connection method between power supply and laser tube, check and remove of common obstacles(see usage-book). Laser tube parameter item power normal(w) the highest power(w) length(mm) diameter(mm) catalysator working time(h) guarantee period (month) w2 90w 100w 1200 80 have 10000 10 w4 120w 135w 1400 80 have 10000 10 w6 150w 170w 1650 80 have 10000 10 w8 170w 195w 1850 90 have 10000 10.

• MOQ 1 Piece(s)
• ApplicationYAG laser marking machine
• Brand NameRL

We offer YAG Krypton Lamp Power Supply .Specification: Max. Output voltage：500V（500V, 400V and 200V for selection） Max. Output current：30A（20A, 30A and 40A for selection） Model RLJK223 RLJK323 RLJK243 RLJK222 RLJK322 Max. Output current（A） 20 30 20 20 30 Max. Output Voltage(V) 200 200 400 200 200 Output current ripple ≦0.4% ≦0.4% ≦0.4% ≦0.4% ≦0.4% Control precision 0.4% 0.4% 0.4% 0.4% 0.4% Sleep current(A) 7 7 7 7 7 Switch working frequency 30KHZ 30KHZ 30KHZ 30KHZ 30KHZ Permitted AC current fluctuation ±15% ±15% ±15% ±15% ±15% Working temperature 0～50℃ 0～50℃ 0～50℃ 0～50℃ 0～50℃ Working humidity 90% 90% 90% 90% 90% Required AC electric power 380V, 6KVA 380V9KVA 380V11KVA 220V6KVA 220V9KVA Dimension (mm) 480x135 x405 480x135 x405 480x135 x405 480x135 x405 480x135 x405 Weight(Kg) 15 15 17 15 15
