High speed Central drum type FLEXOGRAPHIC PRINTING MACHINE Machine Structure Features: 1)Unwinding is automatically lifted by electric crane, controled by magnetic powder tension, so as for smooth material unwinding and overall correction. 2)The printing group uses dual-wall structure; The printing mechanism uses the printing plate and the ceramic body to complete printing and quit printing. 3)NSK The transmission bearing is assembled by Japanese NSK, keeping stability in high speed operation 4)Enclosed ink chamber can rapidly load and unload (without tools). 5)The central impression roller has water cooling roller device to timely cool the materials and ensure quality. 6)The winding uses backward style suface winding; Electric crane easily unloads and transfer. The main winding force is the torque motor, constant torque winding makes flat winding. Basic Technical Parameters: Maximum paper width 1220mm Maximum printing width 1150mm Printing length range 200-1200mm Winding dimension dia. 1200 mm Gear size1/8 CP Printing plate thickness 2.28mm1.7mm Pasting tape thickness 0.38mm Maximum mechanical speed 90M/MIN

We Offer Flexographic Printing Machine, also Called Aniline Press Which Uses Photosensitive Resin Plate as the Printing Plate of Printing Machine. It Adopts Environmental Ink and Has Advantage of Low Edition-producing Cost , This is An Ideal Machine for Mass Lots , Large Variety Production Manufacturer It is also Snitable for Printing Hdpe, Ldpe, Pp.cellophane Paper, Rolling Paper Etc.
