Xinxiang Huayin Renewable Energy Equipment Co.,Ltd

henan, China

Company Profile: Xinxiang Huayin Renewable Energy Equipment Co., Ltd is specialized in manufacturing tyre pyrolysis machine for over 20 years. We have certificates of ISO9001, ISO14001, CE, and nine patents for our equipment while our products have been exported to Italy, Romania, Thailand, Russia, Lebanon, Pakistan and India, which enjoy a good reputation among our clients. High-capacity device: the most important part of our waste tire refining plant is reactor, which decide the machines quality and the oil output in some extent.A.Reactor:Using 245R, 345R boiler plate or 304 and 306 stainless.The thickness of part by fire is 14mm, 16mm or 18mm, other parts 12mm.B.End Enclosure:Using 245R, 345R boiler plate and head of pressure vessel.C.Welding:Using the same material welding wires, automatic welding, processing according to standard of head of pressure vessel.Guarantee the quality and bigger bearing capacity.D.Compound door of feeding:Big door?1200mm;Small door720mmWith big door when feeding the whole tires and big pieces of waste plastic.With small door when feeding the broken tires and waste plastic, multifunction and many choice.Using 245R, Boiler plate, the thickness is 12mm, the length is 1000mm, welding for three time at the junction and reinforcing. Advantage: A. Added by 0.36m3, which makes the real volume large than before.B. High precision makes the main body little vibration, small fault in long life in the production process.C. The seal property of all-door-open type device is good, more energy saving and environmental.D. Quick starting and quick close compound feeding doorsBig diameter, overall TAO Steel flange, UShape bolt hole, easy to loosen or tighten.Concave seal groove makes long life of Sealing material and Sealing degree.E. Build-in Spiral Plate Leave me message to get latest inquiry right now: http:www.plastic-oil-machine.cominquiry.htm

We are offering waste tyre pyrolysis plant. company profile:with the global warming and usage of plastic and rubber products, it has become unstoppable trend to recycle these solid wastes and convert them into fuel oil in pyrolysis way which adopts green environment friendly technology. Huayin waste tyre pyrolysis plant began to research waste tyre waste tyre pyrolysis equipment since 1993. Now we did it, we invented the waste tyre recycling machinery to make fuel oil without any pollution., which could ease the energy shortage and create huge economic benefits. waste tyre pyrolysis to oil process: a.huayin waste tyre pyrolysis plant use auto-feeder to feed the waste tires into reactor automatically, seal the feeding inlet door tightly, which could save labor and time. B. Heat the reactor by burning the following fuel material: coal, wood, natural gas, or fuel oil in the combustion system. The reactor will be heated slowly, when the temperature reaches around 250 degree celsius, the oil gas will be formed. C. After processed by huayin waste tire recycling pyrolysis plant, the oil gas will go to the cooling system to be liquefied. The gas which can not be liquefied under normal pressure will be designed to go back to combustion system through safety device instead of the fuel material to burn the reactor, which is environmental friendly and can save you much energy. D. After finishing oil collecting, the temperature of reactor will be down, while, carbon black can be discharged automatically at the same time. E. When the temperature falls down to 100 degree celsius, workers can open the door of reactor to discharge the steel wire. F. Start another batch working. leave me message to get latest inquiry right now: http:www.plastic-oil-machine.cominquiry.htm
