Zhengzhou Hanfa Import & Export Trading Co., Ltd

Zhengzhou, Henan, China

• MOQ 1 Set(s)

Features and advantages: This machine is a trailer type machine. It has two tires with one axle under the chassis , and it welds traction frame and towing ring together. It can be dragged by one tractor. This machine's work efficiency is high, drilling footage is speedy, assist time is short, especially suitable to drill shallow well. This machine adopts color tower type combination, and It has drilling tools of motion link to assure the upright of bore, it has the characteristics of compact structure, easy installation, stable performance, easy operation and maintain, suitable to water well drilling and piling foundation . Parameters of HF180 for your reference: Max drilling diameter Drilling water well :100-600mm Piling :1200mm Max drilling depth 180m Max output torque 2knm Driving drilling pipe size 108×4.5×6000mm Drilling pipe size 108×4.5×4000mm Max drilling diamter of turntable 140mm Turntable speed 55R/min power 7.5KW motor or 12HP diesel engine Hoist lifting capacity 5T Overall Dimension 4800×1700×6500mm Main machine Weight 2200kg

• MOQ 1 Set(s)

I. Application Apply to drinking water well drilling, farm irrigation, garden irrigation, geological general investigation and exploration, road and tall building basic exploration, kinds of hole in concrete structure, river levees, roadbed grouting hole drilling and direct grouting, and earth central air conditioner, etc III. Technical Parameter Main machine technical parameter Drilling depth 30--150m Drlling diameter 300-75mm Drilling pipe diameter 50mm Drilling angle 90°～75° Drilling weight（no include power） 910kg Unity machine dimensions 2.75×0.95×1.6m Spindle Spindle speed 64、128、287、557r/min Spindle stroke  450mm Hoist Max.single line hoisting capacity 1600kg Reel lifting speed 17、35、75、151r/min  Reel diameter 140mm Wirerope diameter 12.5mm Wirerop cubic measure 35m Hug floodgate diameter 254mm Hug floodgate belt width 70mm Distance between drill and hole 400mm Mud pump Type Horizontal single urn twin-action Displacement 170L/min Power Diesel engine s1110 Model, 20HP Electric Motor Y160M—4 , 15kw 1440r/min Maximum pressure 1.5Mpa Work pressure 0.7Mpa Water inlet caliber 40mm Water to exit caliber 30mm Triangle conveyer belt B1728mm

• MOQ 1 Set(s)
• Applicationgeological exploration
• work siteplains and mountains

• MOQ 1 Set(s)
• coloryellow
• weight560kgs
• usagesoil sampling

• MOQ 1 Set(s)

I. Application This machine mainly used to farm irrigation, garden irrigation, and water well drilling, etc. It can drill 60-80m depth, and drilling diameter is 70-300mm. It can apply to different stratum, such as sand, soil, clay, gravel and so on. II. Features and Advantages 1. Light weight. The main engine is only 135 kg. 2. Easy to operate. Needing little experience to operate. 3. Durable. The first generation of products used for 13 years, drilled more than 4000 water wells, nearly no repair record except the drilling bits. 4. Carbide tipped drill. Can drill through hard stratum, except for thick rock layer. 5. Reducing labor intensity. Equipped with lifting mechanism. 6. High efficiency. In plain area, the drilling speed could reach 20 meters depth per hour. 7. Economical. It can be called the most economical water well drilling machine. III. Main Technical Parameter Drilling depth 30-80m Drilling diameter 70-300mm Power Engine 12HP Overall dimension of the main engine (LxWxH) 1100X600X500mm Weight (main engine) 135kg
