Water Well Drilling Machine

I. Application
This machine mainly used to farm irrigation, garden irrigation, and water well drilling, etc. It can drill 60-80m depth, and drilling diameter is 70-300mm. It can apply to different stratum, such as sand, soil, clay, gravel and so on.
II. Features and Advantages
1. Light weight. The main engine is only 135 kg.
2. Easy to operate. Needing little experience to operate.
3. Durable. The first generation of products used for 13 years, drilled more than 4000 water wells, nearly no repair record except the drilling bits.
4. Carbide tipped drill. Can drill through hard stratum, except for thick rock layer.
5. Reducing labor intensity. Equipped with lifting mechanism.
6. High efficiency. In plain area, the drilling speed could reach 20 meters depth per hour.
7. Economical. It can be called the most economical water well drilling machine.
III. Main Technical Parameter
Drilling depth 30-80m
Drilling diameter 70-300mm
Power Engine 12HP
Overall dimension of the main engine (LxWxH) 1100X600X500mm
Weight (main engine) 135kg
