HF-180 Piling Rig With 1200mm Hole Diameter

Features and advantages:
This machine is a trailer type machine. It has two tires with one axle under the chassis ,and it welds traction frame and towing ring together. It can be dragged by one tractor.
This machine's work efficiency is high, drilling footage is speedy, assist time is short, especially suitable to drill shallow well. This machine adopts color tower type combination, and It has drilling tools of motion link to assure the upright of bore, it has the characteristics of compact structure, easy installation, stable performance, easy operation and maintain, suitable to water well drilling and piling foundation .
Parameters of HF180 for your reference:
Max drilling diameter Drilling water well :100-600mm
Piling :1200mm
Max drilling depth 180m
Max output torque 2knm
Driving drilling pipe size 108×4.5×6000mm
Drilling pipe size 108×4.5×4000mm
Max drilling diamter of turntable 140mm
Turntable speed 55R/min
power 7.5KW motor or 12HP diesel engine
Hoist lifting capacity 5T
Overall Dimension 4800×1700×6500mm
Main machine Weight 2200kg
