Main Features:

• Lighting: Examination of cut, color, inclusions
• Optics: User a high quality stereo zoom microscope to produce binocular image

Illumination System:

A halogen lamp with reflactor coupled with reflaction system OR 32 LEDs ensures sharp and focused light on the diamond under examination which need to investgate the color, cut and inclusions.

Darkfield Illumination:
The darkfield illumination is specially designed for analyzing the inside characteristics of the Diamond. Aset of mirrors focused the light from all directions on the center of stone. In this way, the smallest inclusions become visible.


Overhead LED Illumination:

LED (Light Emitting Diode) illumination which provides a brighter white light then the standard halogen and TL lighting. LED illumination is idea for helping the grader see inclusions and other impurities at diamond. It is useful for studying clarity, cut grade and even color.

Features and Benefits:

• The tender-scope has been developed by Cognep Biomedical Instruments and is indispensable tool to assist you when purchasing diamond on location. Its provides greater magnification than a loupe x10 and is equipped with a light source

Easy to Carry:

• The tender-Scope is a small, lightweight, portable and easy to install microscope that works on rechargeable batteries. It???s your must have tool to help you to make the right decisions on site

When working away from your lab, for example for a tender or a supplier visit, you might have the opportunity to buy an exceptional parcel of rough or polished diamonds. The tender-scope is a sophisticated tool to help you to access the quality of a diamond quickly and accurately.

Key Features:

• 3.5X-90X extended zoom magnification using high-quality Greenough stereoscopic objective lenses with 0.5X and 2X Barlow lenses.
• The microscope provides up to 6.5" (165mm) of working distance.
• A highly-versatile stereo microscope on a heavy-duty, multi-pivot boom-stand which allows the microscope to easily swing into place when needed, and away when not.
• Dual diopters can be adjusted to maintain consistent focus throughout the magnification range, greatly improving productivity.
• The stereo optics provide upright images with clear depth-of-field and a wide view for hands-on applications.
• A trinocular photo-port provides a dedicated mount for adding a camera.
• This microscope is ideal for laboratories, repair shops, and engravers.
• Monitor and capture photos and videos with the included 16MP USB 3.0 camera. Professional microscopy software for Windows, Mac, and Linux provide tools for image processing, measuring, and more.
• The 144-LED ring-light uses a power module with four subdivisions to produce either directional light or an encompassing ring of light.

The SM-4T is a heavy-duty, highly-flexible microscope designed for biological and industrial applications. This model is especially popular in the QC, repair and engraving industries thanks to it ease-of-use and reliability. With its wide zoom range and double-arm boom-stand, this model will become an indispensable instrument in any workshop or lab.

Optics:The stereo optics provide clear, sharp images with excellent focus-depth and a large working-distance. With 0.7X-4.5X zoom objectives, moving through the magnification range is as easy as turning a knob. 10X wide-field eyepieces provide an ample magnification range from 7X to 45X, with high-eyepoint optics to accommodate glasses or goggles. 0.5X and 2X Barlow lenses are included, which can be alternated to either halve or double the magnification range, expanding the possible magnifications to 3.5X-90X.
Ocular Adjustment:

Dual ocular diopters can be adjusted to maintain consistent focus, greatly improving productivity. Rotating interpupillary adjusters simplify the process of aligning the eyepieces for each user.

Trinocular Port:

The switched trinocular photo-port provides a dedicated mount for a camera. When the photo-port is switched open, all light from the left objective is diverted to the port to provide maximum brightness for the camera to guarantee the best quality images. This microscope uses our CX series trinocular port, so it can be easily replaced with optional C-mount ports to match specific cameras.

Double-arm Boom-Stand: The multi-pivoting, double-arm stand provides a stable, flexible support system, ideal for hands-on work. Use of a drop-down column allows the head to be positioned at virtually any angle. Ball-bearing provide smooth movement of the lateral arms, which can easily pivot the microscope out of the way when it is not needed. The heavy, steel base ensures the stability of the microscope, even when laden with attachments.
