High-speed, high-accuracy fingerprint identification Download fingerprint images from the device Read and write fingerprint templates and databases Simple UART protocol (default 9600 baud) Secure your project with biometrics this all in one optical fingerprint sensor will make...
First start running the device : When the first energy given to the device the red led light switch on along 2 seconds and the buzzer make a sound consecutively.
User finger recognition : At first AUTHORIZED FINGER will put over the sensor than USER FINGER will put over the sensor for recognition. Finger will be removed and place over again with every short sound of the device. This process is repeated 3 times after if the USER FINGER reco
Deletion of recognized finger : Closer the magnet to the left side surface. Buzzer will sounding in 250ms and green LED light switch on. The device get through the comparison mode. In the meantime, if you read AUTHORIZED FINGER the device delete all tracks in memory that back to the fac
Operate the device normally : When put the finger on the sensor device get through the comparison mode.
a- If the Sensor is active but did not put the compared finger or compared finger is absent in the memory than buzzer is sounding shortly 2 times and red LED light switch on.
Authorized finger recognition : Closer the magnet to the left side surface. Buzzer will sounding in 250ms and green LED light switch on. The device get through the recognition mode. The finger is placed over the sensor to be granted privileges. Finger will be removed and place over agai
Dimensions / Temparature : 125 x 150 x 45 mm / (-20), (+50) C
Personal : When the device is connected to the PC, it works online. If the device is disconnected from the PC for any reason or there is some other communication problem, it resumes operating offline according to its preset parameters. Upon restoring PC connection,
The Gate is open and personel passed info : With two different input ports available on the device, information concerning the gate status or whether anyone has passed through the turnstile is transferred to the control software.
Frequency / Response Rate / Reading Distance : 13,56 MHz / 400 ms / 10 cm. (max.)
Language / Logo Support : Language Support: Two user-selectable languages are supported as default. With the help of a PC software, user messages can be defined in all languages.
Logo Support: 128 x 64 black and white bmp files prepared by the user can be uploaded onto the
Extras : 3 optional I/Os available on the device can be used for any purpose as needed.
Data Information / Warning Message : Data Information: Each reader can save up to 180,000 access records. Each record containing personnel card number/fingerprint registration number, card type, time (hh.mm.ss) and date (day/month/year) information can be read on request with the help of a P
Sensor Type / Field : Capacitive, Industrial / 208 X 288 pixels, 508 dpi
Warranty / Technical Service : 2 years / Expert quality, fast and continuous technical support.
We are offering finger print biometric reader. we offer single-contact relay output connected to an external relay card is used. Maximum current capacity for inter-contacts is 1 a. Relay time can be set or cancelled between 1 and 9 seconds by user....
FEATURES : 2,200 Fingerprints, 2,000 RFID Card, Inbuilt RFID Card reader
Is a biometric fingerprint reader for time and attendance application. The advanced fingerprint recognition system enables quick and accurate identity matching and can record up to 50, 000 transaction records. It is incorporated with fast TCPIP network communication, popular USB...
700 Faces 3, 000 Fingerprints 1, 00, 000 transactions 630Mhz high speed multi-bio processor High definition infrared camera Memory : 256MB flash, 64SDRAM Display : 4.3” TFT touch screen 6 user defined function keys User name display, photo display...
