USB : Operating voltage: 5V
Connector: USB-A
Protection: 200mA self-recovery fuse, ESD protection
Transmission distance: about 5m
Features : USB to RS485 communication,Adopt original FT232RL and SP485EEN, fast communicating, stable and reliable, better compatibility,Onboard TVS (Transient Voltage Suppressor), effectively suppresses surge voltage and transient spike voltage in the circuit, ligh
Height (mm) : 14.5
RS485 : Connector: screw terminal
Pins: A+, B-, GND
Direction control: hardware automatic control
Protection: 600W lightning-proof and surge-suppress, 15KV ESD protection
Transmission distance: about 1200m (low rate)
Transmission mode: point-to-mul
Operating system : Mac, Linux, Android, WinCE, Windows 10 / 8.1 / 8 / 7 / XP
