Automatic Level Instrument

Our product range contains a wide range of Leica Sprinter 250M Digital Auto Level

Leica Sprinter 250M Digital Auto Level

Min. Order (MOQ) 10 Piece
Country of Origin India
Number Of Flower Digital Level
Automatic Grade Automatic
Brand Name Leica

Measurements have never been so easy to perform with the Leica Sprinter 250M Electronic Levels. The Leica Sprinter 150, 150M and 250M allow users to perform their job quickly and efficiently.

The Leica Sprinter Electronic Level offers everything that you would expect from a construction instrument. It enhances user benefits with a simple user interface and value-added functions:

USB interface (only 150M and 250M)
User-friendly menu
Automatic height calculation and delta height
The right levelling applications
Built-in memory (only 150M and 250M)

Leica Sprinter 250M for Advanced Levelling Work

The Leica Sprinter 250M are the perfect tools for advanced construction levelling tasks. Store up to 1’000 measurements, download and transfer them for further calculations to Excel® to a PC via USB. The delta height calculation and programs line levelling, cut & fill and monitoring facilitates your levelling jobs significantly. The 0.7 mm accuracy of the 250M and the monitoring program allow machine and construction subsidence measurements.

Advanced Leveling:

Aim and Focus: With its high-accuracy opticalelements you simply aim and focus the staff as an optical level.
Push the Button: With its easy one-button operation, Leica Sprinter does not need any intensive training. Simply push the red button to take the measurement. That‘s all you need to do.
Read: Optical reading is no longer needed. The bar code on the staff determines height and distance which is displayed on a highly visible LCD display. There will be no misreading.
Calculate: The Leica Sprinter takes on your calculations. Choose the right application in your language. The correct results will be displayed (for Sprinter 150 – only delta height and tracking) : Delta height, Line levelling, Cut & fill, Tracking & monitoring
Memorize: With their built-in memory for storing up to 1’000 points, the Sprinter 150M and 250M avoid transcription errors.
Download: With Leica Sprinter 150M and 250M, data can be downloaded to your personal computer via USB Interface. The Sprinter DataLoader enables a smooth data transfer to Excel®. Your measurements can also be transferred to an external data collector via RS232 interface.

Benefits:

Increase Productivity
Minimize Human Errors
Operate in Low Light Conditions

Leica Sprinter 150M / 250M

Leica Sprinter Onboard Softwares

Delta height (Sprinter 150/150M/250M):

This function calculates the height difference between points. Enter your benchmark, measure your backsight and then your various targets (foresights). The delta height is always calculated and displayed.

Line Levelling (Sprinter 150M/250M):

Whether you only have back and foresights or even intermediate sights, choose the line levelling job you need. Enter your starting benchmark, measure your backsights, intermediate sights and foresights until you have reached your final point. All measurements are stored in the appropriate order.

Cut & fill (Sprinter 150M/250M):

This onboard application indicates the cut & fill results based on a reference level. Enter your required reference level and benchmark. Take the backsight and start measuring. The program displays now the cut & fill results, height differences, compared to your reference level.

About Leica Geosystems – when it has to be right

With close to 200 years of experience pioneering solutions to measure the world, Leica Geosystems products and services are trusted by professionals worldwide to help them capture, analyze, and present spatial information. Leica Geosystems is best known for its broad array of products that capture accurately, model quickly, analyze easily, and visualize and present spatial information.

Those who use Leica Geosystems products every day trust them for their dependability, the value they deliver, and the superior customer support. Based in Heerbrugg, Switzerland, Leica Geosystems is a global company with tens of thousands of customers supported by more than 3, 500 employees in 28 countries and hundreds of partners located in more than 120 countries around the world. Leica Geosystems is part of the Hexagon Group,

Technical Specifications

Technical Data	Sprinter 150/150M	Sprinter 250M
Height accuracies	Standard devation height measurement per 1 km double run (ISO 17123-2)	Standard devation height measurement per 1 km double run (ISO 17123-2)
−Electronic measurement*	1.5 mm	1.0/0.7* mm
−Optical measurement	With standard aluminum E-scale/Numeral staff: 2.5 mm	With standard aluminum E-scale/Numeral staff: 2.5 mm
−Single staff reading	Standard Deviation: 0.6 mm (electronic) and 1.2 mm (optical) at 30m	Standard Deviation: 0.6 mm (electronic) and 1.2 mm (optical) at 30m
Distance accuracies	Standard deviation distance measurement 10 mm for D ≤ 10 m and (Distance in m x 0.001) for D > 10 m	Standard deviation distance measurement 10 mm for D ≤ 10 m and (Distance in m x 0.001) for D > 10 m
Range	2 – 100 m (electronic)	2 – 100 m (electronic)
Measuring modes	Single and Tracking	Single and Tracking
Time for single measurement	<3 sec	<3 sec
Compensator	Magnet damped pendulum compensator (range +/- 10min)	Magnet damped pendulum compensator (range +/- 10min)
Telescope	Magnification (optical) 24x	Magnification (optical) 24x
Data storage	up to 1’000 points (only 150M)	up to 1’000 points
Environmental conditions	IP55	IP55
Power supply	AA dry cells (4 x LR6/AA/AM3 1.5 V)	AA dry cells (4 x LR6/AA/AM3 1.5 V)
Weight	<2.5 kg	<2.5 kg
