Wires

We offer a complete product range of Teflon Wire, Rubber Insulated Wire and Rg-6 Cable Copper

Teflon Wire

Teflon Wire
  • Operating Temperatures 650 to 2650
PTFE (Polytetrafluoroethylene) cables are basically heat resistant insulated cables. The PTFE Insulated Cables are tape wrapped wires that have uniform insulation thickness around the central conductor compared to the wires insulated by extrusion process. PTFE is higher grade insulating polymer compared to other fluorocarbons that are used in extrusion process.

Technical Data

LT XLPE Cable with Copper & Aluminum Conductors
Nominal conductor size (Sq. mm) Minimum No. of Wires DC reistance @ 20°c (Ohm/Km) AC reistance @ 90°c (Ohm/Km)
Non Compacted Compacted
Copper Aluminum Copper Aluminum Copper Aluminum Copper Aluminum
1.5 3 3 - - 12.1 18.1 15.5 23.17
2.5 3 3 - - 7.41 12.1 9.48 15.5
4 7 3 - - 4.61 7.41 5.9 9.48
6 7 3 - - 3.08 4.61 3.94 5.9
10 7 7 6 - 1.83 3.08 2.34 3.94
16 7 7 6 6 1.15 1.91 1.47 2.44
25 7 7 6 6 0.73 1.2 0.93 1.54
35 7 7 6 6 0.52 0.87 0.67 1.11
50 19 19 6 6 0.39 0.64 0.5 0.82
70 19 19 12 12 0.27 0.44 0.34 0.57
95 19 19 15 15 0.19 0.32 0.25 0.41
120 37 37 18 15 0.15 0.25 0.2 0.32
150 37 37 18 15 0.12 0.21 0.16 0.26
185 37 37 30 30 0.1 0.16 0.13 0.21
240 61 37 34 30 0.08 0.13 0.1 0.16
300 61 61 34 30 0.06 0.1 0.08 0.13
400 61 61 53 53 0.05 0.08 0.06 0.1
500 61 61 53 53 0.04 0.06 0.05 0.08
630 61 91 53 53 0.03 0.05 0.04 0.06
800 61 91 53 53 0.02 0.04 0.03 0.05

Technical Data

HT XLPE Cable with Copper & Aluminum Conductors
Nominal conductor size (Sq. mm) Minimum No. of Wires Max DC reistance @ 20°c DC reistance @ 20°c (Ohm/Km) AC reistance @ 90°c (Ohm/Km) Current rating (K.Amps)
Copper Aluminum Copper Aluminum Copper Aluminum Copper Aluminum
25 6 6 0.73 1.2 0.93 1.54 3.58 2.36
35 6 6 0.52 0.87 0.67 1.11 5.01 3.31
50 6 6 0.39 0.64 0.49 0.82 7.15 4.72
70 12 12 0.27 0.44 0.34 0.57 10.02 6.61
95 15 15 0.19 0.32 0.25 0.41 13.59 8.98
120 18 15 0.15 0.25 0.2 0.33 17.17 11.34
150 18 15 0.12 0.21 0.16 0.27 21.46 14.17
185 30 30 0.1 0.16 0.13 0.21 26.47 17.48
240 34 30 0.08 0.13 0.1 0.16 34.34 22.68
300 34 30 0.06 0.1 0.08 0.13 42.93 28.35
400 53 53 0.05 0.08 0.06 0.1 57.23 37.79
500 53 53 0.04 0.06 0.05 0.08 71.54 47.24
630 53 53 0.03 0.05 0.04 0.06 90.14 59.52
800 53 53 0.02 0.04 0.03 0.05 114.47 75.59
1000 53 53 0.02 0.03 0.03 0.04 143.08 94.48
View Complete Details
Ask Latest Price & Details
Rubber Insulated Wire

Rubber Insulated Wire
  • range 0.25 sq. mm to 240 sq. mm
Silicon Rubber Insulated Cable from us that serve your purpose in the most efficient manner. These cables are used in electric utilities such as the generation and transmission of electricity. The Silicone Rubber Insulated Cables offered by us are featured with long service life under normal environment in nuclear and conventionally powered generating stations. We have selected silicone in the manufacturing process because Silicon offers circuit integrity, low smoke evolution, and freedom from halogen acids when exposed to fire.We offer a complete range of Silicon Rubber insulated wires & cables from 0.25 sq. mm to 240 sq. mm. These are heat resistant, oil resistant & flame retardant wires & cables.
View Complete Details
Ask Latest Price & Details
