Copper Wire

We are leaders in the market for providing best range of Flat Copper Braid

Flat Copper Braid

Flat Copper Braid
  • Min. Order (MOQ) 50 Meter
  • Thickness 1 Mm To 10 Mm
  • Material Bare Copper / Tinned Copper
  • Packaging Type Roll, Coils, Cut Lengths, Or Custom Packs
  • Country of Origin India
  • Wire Diameter 0.51 Mm To 3 Mm
  • Stranding Fine copper wires (typically 0.07–0.20 mm dia each)
  • Width Range 5 mm to 100 mm (custom on request)
  • Current Capacity Varies as per cross-sectional area
  • Finish Options Bare / Electro Tinned
  • Resistance Low electrical resistance
  • Operating Temperature -20°c to +120°c (approx.)

Flat Copper Braid is a flexible, tinned or bare copper conductor made by weaving multiple fine copper wires into a flat, ribbon-like structure. It is widely used for electrical grounding, bonding, shielding, and as a flexible connector in electrical systems. Due to its flat profile, it offers excellent current-carrying capacity with space efficiency.

\n

Key Features:

\n

High flexibility and vibration resistance

\n

Excellent conductivity for electrical applications

\n

Easy to solder and terminate

\n

Corrosion-resistant in tinned variant

\n

Ideal for compact electrical assemblies

\n



\n

Applications:

\n

Electrical grounding and bonding

\n

Busbar connections

\n

Shielding in control panels and switchgear

\n

Battery connections and inverter systems

\n

Flexible jumpers in machinery and railways

\n



\n



\n



Additional Information



Sl NO

Paras Part Number

Nominal Flat Width in inches

Nominal Flat Width in mm
Nominal Thickness in inches
Nominal Thickness in mm
AWG of Individual Strands

No. of Carriers

No. of Wires per Carrier

Total No. of Wires

Ampere

Approx. Shipping Weight Kg/Km
1 6010230481909 0.906 23 0.061 1.55 36 48 19 912 89 154.15
2 601024240309 0.125 3.18 0.02 0.508 36 24 3 72 16 12.17
2 601026240409 0.156 3.96 0.031 0.7874 36 24 4 96 19 16.23
3 601028240509 0.187 4.75 0.02 0.508 36 24 5 120 25 20.28
4 601029240709 0.25 6.35 0.03 0.762 36 24 7 168 32 28.4
5 601029241009 0.25 6.35 0.046 1.1684 36 24 10 240 40 40.57
6 6010211241309 0.281 7.14 0.046 1.1684 36 24 13 312 46 52.74
7 6010213480609 0.375 9.53 0.03 0.762 36 48 6 288 40 48.68
8 6010213240509 0.375 9.53 0.045 1.143 30 24 5 120 60 20.28
9 6010222480809 0.625 15.88 0.03 0.762 36 48 8 384 53 64.91
10 6010222481109 0.625 15.88 0.046 1.1684 36 48 11 528 62 89.25
11 6010219480809 0.5 12.7 0.03 0.762 36 48 8 384 53 64.91
12 60102129481809 0.75 19.05 0.04 1.016 36 48 18 864 88 146.04
13 6010232481809 1 25.4 0.045 1.143 36 48 18 864 85 146.04
14 6010227481909 0.812 20.62 0.045 1.143 36 48 19 912 93 154.15
15 6010229482209 0.875 22.23 0.05 1.27 36 48 22 1056 105 178.49
16 60102129246709 0.75 19.05 0.04 1.016 36 24 67 1608 125 271.8
17 6010251488409 1.625 41.28 0.08 2.032 36 48 84 4032 230 681.52
18 60102128241017 0.5 12.7 0.093 2.3622 30 24 10 240 90 157.2
19 6010222241517 0.625 15.88 0.093 2.3622 30 24 15 360 120 235.79
20 60102129242017 0.75 19.05 0.11 2.794 30 24 20 480 145 314.39
21 6010229242417 0.875 22.23 0.12 3.048 30 24 24 576 165 377.27
22 6010231242617 0.937 23.8 0.13 3.302 30 24 26 624 170 408.71
23 6010231242617 0.937 23.8 0.13 3.302 30 24 27 648 175 424.43
24 6010231242717 1 25.4 0.14 3.556 30 24 32 768 195 503.03
25 60102129480517 0.75 19.05 0.05 1.27 30 48 5 240 93 157.2
26 6010243480717 1.375 34.93 0.05 1.27 30 48 7 336 100 220.07
27 6010232480817 1 25.4 0.07 1.778 30 48 8 384 120 251.51
28 6010241481017 1.25 31.75 0.08 2.032 30 48 10 480 145 314.39
29 6010247481117 1.5 38.1 0.06 1.524 30 48 11 528 145 345.83
30 6010229481217 0.875 22.23 0.09 2.286 30 48 12 576 150 377.27
31 6010244481417 1.375 34.93 0.09 2.286 30 48 14 672 165 440.15
32 6010247481817 1.5 38.1 0.1 2.54 30 48 16 768 180 503.03
33 6010251481817 1.625 41.28 0.11 2.794 30 48 18 864 200 565.91
34 6010244482217 1.375 34.93 0.12 3.048 30 48 22 1056 235 691.66
35 6010254482617 1.75 44.45 0.13 3.302 30 48 26 1248 250 817.42
36 6010259482817 2 50.8 0.13 3.302 30 48 28 1344 255 880.3
37 6010259483217 2 50.8 0.14 3.556 30 48 32 1536 290 1006.06
38 6010259483517 2 50.8 0.15 3.81 30 48 35 1680 320 1100.37
39 6010269484417 2.375 60.33 0.175 4.445 30 48 44 2112 370 1383.33
40 6010286484717 3 76.2 0.19 4.826 30 48 47 2256 390 1477.64
41 601027248525217 2.5 63.5 0.19 4.826 30 48 52 2496 410 1634.84
