060 Hydraulic Steering Control Unit, Brand Name : Hanjiu

Product description
060 integral series power steering units
060 series psu incorporated the inlet check valve, safety valve, internal check valve, cylinder port shock valve and anti-cavitation valve. The design is more compact and convenient.
Features
incorporated five valves into the psu, so it is more compact and convenient
low hydraulic noise
special casting design for low pressure drop.
3 basic systems-open center, closed center and load sensing
displacement: 50~500 mlr
main specification data
max. System pressure --------16mpa
max. Back pressure -----------2.1mpa
input torque--------------------1.7~2.5nm
max. System operating temperature--------93º c
recommended oil filtration--------iso 1916
function of the incorporated valve
inlet safety valve: limits maximum pressure drop across the psu to protect the steering circuit.
Cylinder port shock valve: protects hoses against pressure surge created by ground forces on the cylinder axle.
Anti- cavitation valve: protects steering circuit against vacuum (cavitation) conditions.
Inlet check valve: prevents oil from returning through the psu when pressure on the cylinder side is greater than the inlet side. It prevents steering wheel kick.
Internal check valve: converts the psu to a hand operated pump for limited manual steering.
displacement (mlr) 50 63 80 100 125 160 200 250 315 400 500
l(mm) 137.5 139.5 139.5 142 150 150 155 161 171 181 193
hydraulic steering unit is widely used in the steering control system
such as the steering system of many kinds of industrial and agricultural
mobile machinery forklift,loader,roadroller,tractor,comebine harvester, etc.
We produce the products match with the oem number of all machines.
hydraulic steering unit applications:
construction machinery
agriculture machinery
heavy-duty equipment
forestry machinery
mining equipment
