Contact SupplierDescription & Specifications:
X Working Area 1300mm
Y Working Area 2500mm
Z Working Area 200mm
Table size 1300x2500mm
Traveling Positioning Accuracy ±0.05mm
Repositioning Positioning Accuracy ±0.05mm
Table Surface By clamp
X,Y ,Z Structure XY gear wheel, Z ball screw
Max. Power Consumption(Without spindle) 1.84KW
Max. Rapid Travel Rate 30000mm/min
Max. Working Speed 20000mm/min
Spindle 4.5kw 3 PHASE, HSD air cooled spindle
Spindle Speed 0-18000r/min
Drive Motor 450B
Driver High speed driver Yako 2D811
Command G-code*.u00*.mmg*.plt
Working voltage AC380V/60Hz
Control System DSP ---A11S version
Guide rail 25 Square rail (TAIWAN BRAND:TBI)
Control cabinet Independent cabinet
N.W./G.W. 1700/1850KGS
Packing Size 3200*2150*1850mm
