    Trinocular Metallurgical Microscope, Power Source : Battery
    • Trinocular Metallurgical Microscope
    • 1016496
    • 1016497

    Trinocular Metallurgical Microscope, Power Source : Battery

    Get Latest Price
    • Power SourceBattery
    • Availability1-3kg
    • EyepiecesWF15X
    • Vision Angle5-10Degree
    • Supply TypeManufacturer, Supplier
    • Preferred Buyer Location All over the world
    View More Details
    Send Enquiry

    Company Information

    Heat Treatment Sales & Servicesverified-icon
    location Odhav, Ahmedabad, Gujarat
    4.5/5fill iconfill iconfill iconfill iconhalf icon(2)
    View Number
    • calendar Member Since 15 Years
    • building Nature of Business Manufacturer
    • gst icon GST No. 24ANYPS0431L1ZI

    Ask for more detail from the seller

    Contact Supplier
    Report incorrect details
    View Company Details

    • Product Details

    • Company Details

    no_img_icon

    • Availability1-3kg
    • Power SourceBattery
    • EyepiecesWF15X
    • Vision Angle5-10Degree
    • IlluminatorThe Epi illuminator has 5W LED lamp adjustable brightness.
    • Standard AccessoriesBlue, Green & Yellow filters. Styrofoam molded pack.
    • EyepieceWide field eyepiece 10X (Paired) FOV 18mm

    Trinocular Observation Head :

    • Siedentopf observation head inclined at 45°.
    • Vertical phototube for micro photography light split (80:20).
    • Diopter adjustment ring on ocular tube (±5).
    • Interpupillary distance from 54mm to 75mm.



    Objectives (Infinity Corrected) :

    • M Long Working Distance Plan Achromatic 5X
    • M Long Working Distance Plan Achromatic 10X
    • M Long Working Distance Plan Achromatic 20X
    • M Long Working Distance Plan Achromatic 50X ( S L ) Dry



    Mechanical Body :

    • Co-axial focusing system with large knobs, PRE-FOCUSING LEVER & TENSION ADJUSTMENT RING.
    • Quadruple nosepiece on ball bearing.
    • Mechanical stage is 180mmX155mm.
    • Moving range - 75mmX40mm.
    • The Mechanical stage has low positioned co-axial controls on ball bearing guide ways.


    Details

    DescriptionStandard Delivery
    Eyepiece10X/22
    Objectives
    Equipped with bright & dark field objectives    		L5X/0.12 BD / WD:9.70mm
    L10X/0.25 BD / WD:9.30mm
    L20X/0.40 BD / WD:7.23mm
    L50X/0.70 BD / WD:2.50mm
    Eyepiece tubeInclination angle is 45
    inter papillary distance is 53~75mm
    Focus systemCoaxial coarse/fine focus
    with tension adjustable-minimum division
    of fine focusing is 2um
    NosepieceQuintuple(Backward ball bearing inner locating)
    Mechanical StageTravel Range: 50×40mm; Size: 242×200mm
    Rotundity and rotatable stage size: maximal measurement is Ø130mm and minimal clear aperture is less then Ø12mm
    Illuminator12V/50W Halogen Lamp
    Color FilterGrey Color Filter
    Blue Color Filter
    Green Color Filter
    Ground glass
