1:4 PLC Splitter With SC APC Connector

The 1:4 PLC splitter is with one input port and 4 output ports , it can be installed for 4 endusers for GPON FTTH, it is suitable for small building with only 1-4 users . PLC ,Planar lightwave circuit splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to realize optical signal power splitting. Fibercan provides whole series of 1xN and 2xN splitter products that are tailored for specific applications. All products meet GR-1209-CORE and GR-1221-CORE requirements. Features  Low Insertion loss                            Low PDL  Compact Design   Good channel-to-channel uniformity  Wide Operating Wavelength:       From 1260nm to 1650nm  Wide Operating Temperature:       From -40℃ to 85℃  High Reliability and StabilityApplications  FTTX Systems                              PON Networks  CATV Links  Optical Signal DistributionCompliance  Telcordia GR-1209-CORE  Telcordia GR-1221-CORE  RoHS Specifications Table 1– 1×N PLCSplitter Parameters 1×2 1×4 1×8 1×16 1×32 1×64 Operating Wavelength (nm)  1260~1
