Contact SupplierConsider our name, if seeking for high quality products that are prepared using the best grade material and modern technology. Our associates procure it from the reliable names after complete quality satisfaction. Designed and developed using the best quality material, we pack them meticulously so as to ensure hassle free deliveries. Also, we make sure that only premium material is used for packaging.
Details
Applications:
Salient Features:
Pumped Liquids:
Clean, thin non-aggressive, non-explosive, clear, cold, fresh water without abrasives.
Power Range | 15 HP - 60 HP with 8" motor, 75 HP - 150 HP with 10" motor |
---|---|
Version | 350 - 415V, 50Hz in 3Ph |
Speed | 2880 Rpm |
Flow Rate | 25-75 lps with 8" and 10" motor |
Total Head Range | 10-100 meters with 8" motor, 25-210 meters with 10" motor |
Outlet size in inches | 5" & 6" |
Degree of Protection | IP 58 |
Degree of Protection | CCW, CW in 3 Ph |
Maximum outer diameter | 240 mm |
Type of duty | S1 (Continuous) |
Thurst Load | 10 to 20 HP-3500 lbs, 25 to 60 HP- 10000 lbs,75 to 150 HP |
PART NAME | MATERIAL |
---|---|
Shaft Seal | Nitrile Rubber |
Stator Shell | Stainless steel |
Bushes | LTB4 / LTB5 |
Thrust Assembly | SS 420 and Graphite Carbon |
Upper Housing / Lower housing / Motor Base | Cast Iron |
Shaft | SS 410 / EN 9 |
PART NAME | MATERIAL |
---|---|
Impeller | Non Corrosive Stainless Steel |
Diffuser Chamber | Cast Iron {FG 200} |
Sleeve / Bush | SS 410 with Chrome Plated / NBR |
Suction Housing | Cast Iron |
Pump Shaft | SS 410 |
Coupling | SS 410 |
NRV Housing | Cast Iron {FG 200} |
Pump Inlet Housing | SS 202 |
Cable Guard | SS 202 |
